| Ref | Part Number | Description |
|---|
| 1 |
115-5304 |
CAP-FUEL This part replaces 93-7170. Price: $26.87 |
| 1 |
530016153 |
Screw Price: $1.99 |
| 2 |
92-7186 |
TANK-FUEL Price: $333.26 |
| 3 |
240-11 |
BUSHING-FLANGE Price: $5.32 |
| 3 |
530069247 |
Kit-Fuel Line (Small) Price: $3.69 |
| 4 |
95-0576-03 |
BASE-TANK, FUEL Price: $196.80 |
| 5 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 5 |
530015780 |
Screw Price: $1.99 |
| 6 |
3250-36 |
SCREW-PPH Price: $2.41 |
| 6 |
530095646 |
Assy-Fuel Pick-up Price: $2.69 |
| 7 |
2412-36 |
CLAMP-HOSE Price: $1.28 |
| 7 |
530047442 |
Strap-Ground Price: $1.99 |
| 8 |
110-8151 |
HOSE-FUEL, FORMED This part replaces 92-7152. Price: $18.95 |
| 8 |
530039198 |
Ignition Module Price: $29.99 |
| 9 |
530015814 |
Screw Price: $1.49 |
| 9 |
92-7160 |
CLIP Price: $13.03 |
| 10 |
32103-12 |
NUT-WING Price: $1.15 |
| 10 |
530052296 |
Assy-Wire Harness Price: $4.99 |
| 11 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 11 |
530037793 |
Foam- Air Filter Price: $1.99 |
| 12 |
530016101 |
Nut Price: $1.99 |
| 12 |
92-5018-03 |
CLAMP-BATTERY Price: $21.92 |
| 13 |
323-6 |
SCREW-HH Price: $0.66 |
| 13 |
530035526 |
Grommet-Carb Adjust Price: Call Us |
| 14 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 14 |
530054144 |
Seal-Carb Adapter Price: $2.99 |
| 15 |
104-8162 |
BATTERY-DRY Price: $114.99 |
| 15 |
530055698 |
Reflector-Heat Price: $1.99 |
| 16 |
100-6435 |
POST-BATTERY This part replaces 56-7720. Price: $15.91 |
| 16 |
503235111 |
BPMR7A NGK SPARK PLUG This part replaces 952030150. Price: $3.69 |
| 17 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 17 |
530016136 |
Clip-High Tension Lead Price: $1.99 |
| 18 |
322-3 |
SCREW-HH Price: $0.79 |
| 18 |
530012550 |
Cylinder Price: $17.99 |
| 19 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 19 |
530016351 |
Screw-Outlet cover Price: $1.99 |
| 20 |
2412-73 |
CLAMP-R Price: $2.56 |
| 20 |
530054883 |
Cover - Outlet Price: Call Us |
| 21 |
3274-69 |
SCREW-HSBH Price: $0.43 |
| 22 |
109-0294 |
HOSE-FUEL This part replaces 95-0618. Price: $6.29 |
| 22 |
530057480 |
Air Filter Housing Price: $4.99 |
| 23 |
2412-98 |
CLAMP-HOSE Price: $1.39 |
| 24 |
530069608 |
Gasket-Carb. (kit) Price: $5.99 |
| 24 |
83-1390 |
VALVE-SHUT-OFF, FUEL Price: $55.01 |
| 25 |
240-9 |
GROMMET Price: $3.25 |
| 25 |
530016386 |
Screw Price: $5.99 |
| 26 |
530049700 |
Carb. Adapter Price: $3.99 |
| 26 |
86-7640-01 |
BOX-LITTER Price: $165.59 |
| 27 |
530016187 |
Screw Price: $1.99 |
| 27 |
86-7450 |
CABLE-GROUND Price: $23.53 |
| 28 |
530069608 |
Gasket- Adaptor(kit) Price: $5.99 |
| 28 |
63-8410 |
WASHER Price: $1.76 |
| 29 |
93-6668 |
DECAL-BATTERY Price: $18.99 |
| 30 |
545160401 |
Ring-Piston This part replaces 530038729. Price: $2.99 |
| 31 |
530015697 |
Retainer-Piston Pin Price: $1.99 |
| 33 |
530031163 |
Scrench This part replaces 530031135. Price: $4.99 |
| 34 |
530056363 |
Assy-Seal & Bearing Price: $11.99 |
| 35 |
530037935 |
Cap-Crankcase Price: $8.99 |
| 36 |
530047062 |
Assy-Crankshaft Price: $72.99 |
| 37 |
530054885 |
Backplate Price: $5.99 |
| 38 |
530054880 |
Guide-Outlet Price: $5.99 |
| 39 |
530069608 |
Gasket-Muffler(kit) Price: $5.99 |
| 41 |
530016338 |
Bolt-Muffler Price: $1.99 |
| 42 |
530055586 |
Cover-Bolt Price: $0.99 |
| 43 |
574266401 |
NUT 10MM BRASS This part replaces 530016359. Price: $1.99 |
