| Ref | Part Number | Description |
|---|
| 1 |
532411423 |
KIT.LEVER.CONTROL.RH.AUGER This part replaces 532407649. Price: $22.99 |
| 2 |
42-8000 |
INJ PUMP Price: $2,367.11 |
| 2 |
532405783 |
LEVER-TRACTION DRIVE CONTROL This part replaces 532407648. Price: $11.99 |
| 3 |
42-9830 |
DISCONTINUED Price: Call Us |
| 4 |
42-8100 |
COLLAR MM 304916 Price: $28.56 |
| 4 |
532178888 |
BUSHING, FLANGE Price: $3.99 |
| 5 |
532169675 |
SPRING RETAINER Price: $4.99 |
| 6 |
817060408 |
SCREW Price: $4.99 |
| 7 |
532178652 |
ROD.INTERLOCK Price: $9.99 |
| 8 |
532429098 |
ARM.IMPELLER.ROD.SNOW This part replaces 532199576. Price: $3.99 |
| 8 |
56-0750 |
CLAMP This part replaces 42-8160. Price: $15.09 |
| 9 |
532196334 |
ARM.TRACTION.ROD.YZ. This part replaces 532199575. Price: $3.99 |
| 10 |
33113-025 |
SCREW-HH This part replaces 43-2600. Price: $1.97 |
| 10 |
532196619 |
PANEL.CONTROL This part replaces 532199531. Price: $19.99 |
| 11 |
42-8140 |
PIPE ASY. Price: $95.38 |
| 11 |
596582201 |
Bolts This part replaces 874780524. Price: $2.99 |
| 12 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 874780512. Price: $3.99 |
| 13 |
532414517 |
TUBE.HANDLE.PLOW.LH.PNT This part replaces 532415236. Price: $28.99 |
| 13 |
56-0760 |
CLAMP This part replaces 42-8170. Price: $7.97 |
| 14 |
33114-020 |
SCREW-HH This part replaces 43-0110. Price: $0.28 |
| 14 |
532414516 |
TUBE.HANDLE.PLOW.RH.PNT This part replaces 532415237. Price: $29.99 |
| 15 |
42-8010 |
ADJ SHIM MM 409040 Price: $13.75 |
| 15 |
532751153 |
NUT.LOCK.5/16-18 Price: $2.99 |
| 16 |
281-1 |
PLUG-PIPE, SQH Price: $4.56 |
| 16 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 17 |
42-7090 |
SEALING CAP Price: $27.82 |
| 17 |
532178899 |
KNOB.HANDLE.3/8.TRI-POINT.BLAC Price: $4.99 |
| 18 |
42-7050 |
OIL GA GUIDE Price: $21.44 |
| 18 |
532180480 |
ROD.ASM.IMPELLER Price: $24.99 |
| 19 |
43-2710 |
O-RING Price: $6.47 |
| 19 |
532180481 |
ROD.ASM.TRACTION. Price: $22.99 |
| 20 |
72-6950 |
OIL LEVEL GUAGE RETAIN. This part replaces 43-2900. Price: $33.80 |
| 21 |
42-7160 |
PIN Price: $4.51 |
| 22 |
42-7270 |
OIL GAUGE Price: $39.93 |
| 22 |
872120618 |
BOLT 3/8-16 X 2-1/4 Price: $5.99 |
| 23 |
42-9660 |
WASHER Price: $2.50 |
| 23 |
532184087 |
TUBE.LOWER.HANDLE.24.BLACK Price: $59.99 |
| 24 |
532180447 |
SLEEVE, SPRING Price: $5.99 |
| 25 |
42-7410 |
DISCONTINUED Price: Call Us |
| 25 |
532180926 |
SPRING, TRACTION DRIVE Price: $5.99 |
| 26 |
532178669 |
SPRING, AUGER CONTROL Price: $7.99 |
| 27 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 28 |
532412680 |
SPACER CONTROL LEVER Price: $2.99 |
| 30 |
532183346 |
PANEL.CONSOLE.HEADLIGHTS Price: $29.99 |
| 31 |
3253-4 |
WASHER-LOCK This part replaces 42-9850. Price: $0.25 |
| 31 |
532175262 |
SCREW, HEX HD TAPPING #10-24 1 Price: $3.99 |
| 32 |
33114-016 |
SCREW-HH This part replaces 42-9230. Price: $0.27 |
| 32 |
594975601 |
Screws This part replaces 532184471. Price: $1.99 |
| 33 |
42-8180 |
FUEL RETURN ASM Price: $39.29 |
| 33 |
532196335 |
LATCH.INTERLOCK.YELLOW This part replaces 532199577. Price: $11.99 |
| 34 |
2412-79 |
CLAMP-HOSE Price: $1.63 |
| 34 |
532401369 |
BOLT SHOULDER Price: $2.99 |
| 35 |
42-8190 |
JOINT MM 100088 Price: $13.50 |
| 35 |
873850400 |
This part replaces 532068038. Price: $2.51 |
| 36 |
532443215 |
SPRING.TORSION.LEVER This part replaces 532178831. Price: $3.99 |
| 36 |
67-2390 |
PLUG This part replaces 42-7210. Price: $5.06 |
| 37 |
42-7290 |
GASKET-PLUG This part replaces 42-8880. Price: $7.56 |
| 37 |
532193885 |
SPRING LATCH Price: $3.99 |
| 38 |
67-2520 |
PLUG This part replaces 42-8870. Price: $5.65 |
| 39 |
42-8930 |
SPRING MM 407142 Price: $16.42 |
| 39 |
532178668 |
BEZEL.HEADLIGHT.BLACK Price: $5.99 |
| 40 |
67-2500 |
PLUNGER This part replaces 42-8860. Price: $22.88 |
| 41 |
92-1978 |
OIL PRESSURE SWITCH This part replaces 42-9060. Price: $63.87 |
| 42 |
42-9030 |
FILTER-OIL Price: $10.31 |
| 42 |
532196336 |
LEVER.INTERLOCK This part replaces 532199578. Price: $2.99 |
| 43 |
42-9480 |
DISCONTINUED Price: Call Us |
| 43 |
532199638 |
ROD.LATCH.INTERLOCK Price: $7.99 |
| 44 |
42-8920 |
DISCONTINUED Price: Call Us |
| 44 |
532196338 |
ROD.ASM INTERLOCK Price: $5.99 |
| 45 |
42-8910 |
PUMP ROTOR Price: $416.87 |
| 45 |
532700279 |
RETAINER CLIP Price: $2.99 |
| 46 |
42-8940 |
O-RING Price: $28.65 |
| 46 |
532057079 |
THRUST WASHER Price: $1.99 |
| 47 |
42-7030 |
DISCONTINUED Price: Call Us |
| 47 |
532196943 |
BRKT.PANEL.RH.INT Price: $8.99 |
| 48 |
42-8900 |
PUMP BODY MM 409201 Price: $249.04 |
| 48 |
532196944 |
BRKT.PANEL.LH.INT Price: $8.99 |
| 49 |
42-8950 |
BODY GASKET MM 407124 Price: $13.24 |
| 50 |
42-7180 |
DISCONTINUED Price: Call Us |
| 51 |
42-7170 |
PLUG-40 MM MF665511 Price: $11.46 |
| 52 |
42-7200 |
KNOCK BSHG MS 471110 Price: $10.16 |
| 53 |
93-3409 |
BEARING This part replaces 42-7820. Price: $33.38 |
| 54 |
42-7840 |
SUNK KEY Price: $9.67 |
| 55 |
42-7810 |
DISCONTINUED Price: Call Us |
| 56 |
42-7790 |
IDLER GEAR Price: $383.30 |
| 57 |
42-7780 |
DISCONTINUED Price: Call Us |
| 58 |
42-7730 |
DISCONTINUED Price: Call Us |
| 59 |
72-4280 |
CAM SHAFT Price: $839.96 |
| 62 |
48-7880 |
NUT-HEX This part replaces 43-5970. Price: $0.25 |
| 63 |
43-5920 |
WASHER-LOCK, SPRING Price: $0.25 |
| 64 |
33014-00 |
NUT-HEX This part replaces 42-9580. Price: $0.25 |
| 65 |
43-0370 |
DISCONTINUED Price: Call Us |
| 66 |
43-0380 |
DISCONTINUED Price: Call Us |
| 67 |
112-1359 |
ALTERNATOR This part replaces 43-0390. Price: $469.33 |
| 68 |
43-1900 |
BOLT MD 017625 Price: $17.40 |
| 69 |
54-8660 |
WASHER Price: $2.23 |
| 70 |
67-4660 |
BOLT-FLANGE This part replaces 54-8650. Price: $2.64 |
| 71 |
43-0400 |
GEN BRACE MM 409463 Price: $68.06 |
| 72 |
42-7190 |
DISCONTINUED Price: Call Us |
| 73 |
42-9820 |
DISCONTINUED Price: Call Us |
