| Ref | Part Number | Description |
|---|
| 1 |
40-6230 |
SPRING Price: $37.99 |
| 1 |
596973202 |
Decks This part replaces 582877602. Price: $999.99 |
| 2 |
586918102 |
BLADE.42.FCS.BAGGING.BLADE. This part replaces 586918101. Price: $27.99 |
| 3 |
32128-20 |
NUT-HF Price: $0.99 |
| 3 |
587270001 |
BELT.42.FCS.ZTR.DECK.DRIVE Price: $64.99 |
| 4 |
43-8480 |
DECAL-DANGER Price: $6.49 |
| 4 |
532196106 |
PULLEY.IDLER.2006 Price: $34.99 |
| 5 |
3296-5 |
NUT-HEX Price: $3.09 |
| 5 |
532196104 |
PULLEY.IDLER.MWR.STATI.LH Price: $37.99 |
| 6 |
532199791 |
PULLEY MANDREL 5.0" Price: $22.99 |
| 6 |
66-6380 |
DECAL-DANGER Price: $8.97 |
| 7 |
29-5590-03 |
BRACKET-PIVOT This part replaces 29-5590. Price: $23.25 |
| 7 |
586874002 |
ARM.42"FCS.CLUTCHING.X431 Price: $17.99 |
| 8 |
536050602 |
LINK FIXED MOWER DRAWBAR BLACK This part replaces 587140502. Price: $5.99 |
| 8 |
66-1340 |
DECAL-DANGER, THROWN OBJECT Price: $9.07 |
| 9 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 9 |
586936802 |
COVER.42".MANDREL.FCS X668 Price: $7.99 |
| 10 |
587305701 |
DEFLECTOR.ASM.42.FCS.ORANGE Price: $69.99 |
| 11 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 11 |
532198468 |
KEEPER.BELT.IDLER.54"T Price: $7.99 |
| 12 |
3256-27 |
WASHER-FLAT Price: $0.47 |
| 12 |
588610902 |
LINK.RZ.FRONT.WELDMENT.E-DIP Price: $44.99 |
| 13 |
3296-33 |
NUT-LOCK, NI Price: $2.39 |
| 13 |
532415598 |
PORT.WASHOUT Price: $6.99 |
| 14 |
28-9060 |
PLATE-IDLER Price: $137.75 |
| 14 |
595297001 |
Rods This part replaces 532131491. Price: $4.99 |
| 15 |
5-1077 |
KEY-SQUARE Price: $6.18 |
| 15 |
594092501 |
Rods This part replaces 532179127. Price: $5.99 |
| 16 |
586918002 |
BRACKET.42".FCS.DBLE.HINGEX668 Price: $17.99 |
| 16 |
99-1297 |
IDLER ARM ASM This part replaces 27-8580. Price: $133.94 |
| 17 |
532176066 |
NOSE ROLLER 48" Price: $11.99 |
| 17 |
65-5940 |
PULLEY-IDLER Price: $35.61 |
| 18 |
593842101 |
Bushings This part replaces 532195263. Price: $4.99 |
| 18 |
7-0081 |
WASHER-FLAT Price: $0.89 |
| 19 |
36-1740 |
ROLLER-DECK Price: $37.03 |
| 19 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 20 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 20 |
539131898 |
MANDREL ASM, CAST IRON Price: $69.99 |
| 21 |
40-0340 |
SHAFT-ROLLER, REAR Price: $29.99 |
| 21 |
532110485 |
BEARING Price: $11.99 |
| 22 |
27-1160 |
V-BELT Price: $51.80 |
| 22 |
597023501 |
MANDRELS This part replaces 532187291. Price: $24.99 |
| 23 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 23 |
587354701 |
SPRING.42.FCS.DEFLECTOR Price: $5.99 |
| 24 |
32146-20 |
NUT-HEX Price: $3.23 |
| 24 |
532197251 |
SPRING.MOWER.DRIVE.ELECTRIC Price: $9.99 |
| 25 |
582683201 |
BUMPER.42.CLEARCUT.TRIMSDE.ASM Price: $9.99 |
| 25 |
7-4150 |
WASHER Price: $1.19 |
| 26 |
27-0970-03 |
PULLEY ASM This part replaces 27-0970. Price: $51.99 |
| 26 |
582360501 |
BUSHING.NOSE.ROLLER Price: $3.99 |
| 27 |
253-139 |
SEAL-OIL Price: $12.45 |
| 27 |
532110452 |
NUT PUSH M Price: $2.99 |
| 28 |
46-8530 |
BEARING ASM Price: $93.99 |
| 28 |
596337801 |
Bolts This part replaces 872140620. Price: $4.99 |
| 29 |
3231-22 |
SCREW-CARR Price: $0.72 |
| 29 |
596039401 |
BOLT ROUND HEAD SQUARE NECK BO This part replaces 872110505. Price: $2.99 |
| 30 |
27-7680-03 |
RING-DECK SUPPORT This part replaces 27-7680. Price: $70.99 |
| 30 |
532193003 |
BOLT.WASHER.ASM.7/16-2 Price: $6.99 |
| 31 |
532196539 |
BOLT.SHOULDER Price: $5.99 |
| 31 |
68-8340 |
DECAL-TORQUE Price: $19.99 |
| 32 |
596240801 |
GSPW Bolts This part replaces 539115574. Price: $3.99 |
| 32 |
61-4160 |
HOUSING-SPINDLE Price: $131.00 |
| 33 |
32128-21 |
NUT-HF Price: $0.39 |
| 33 |
532170165 |
SHOULDER BOLT 5/16-18TT Price: $3.99 |
| 34 |
27-0920 |
SHAFT Price: $158.07 |
| 34 |
588438301 |
SCREW.7/16-14 X 2.125.WASHER Price: $5.99 |
| 35 |
27-0990-03 |
BLADE-18 INCH This part replaces 27-0990. Price: $18.94 |
| 35 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 Price: $3.99 |
| 36 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 36 |
72-9361 |
CUP-SCALP, ANTI Price: $39.78 |
| 37 |
3253-27 |
WASHER-LOCK Price: $2.24 |
| 37 |
596134801 |
Nuts This part replaces 532400234. Price: $1.00 |
| 38 |
44-2200 |
SCREW-BLADE Price: $4.04 |
| 38 |
596039201 |
GSPW Hardware This part replaces 539990585. Price: $2.99 |
| 39 |
27-0950 |
SPACER Price: $29.99 |
| 39 |
873610700 |
NUT.ASF.HEX.7/16 This part replaces 873360700. Price: $5.99 |
| 40 |
589464902 |
NUT.LIFT LNK.7/16-2 This part replaces 532175994. Price: $3.99 |
| 40 |
72-9210 |
DISCONTINUED Price: Call Us |
| 41 |
40-6400 |
SHAFT-ROLLER Price: $38.99 |
| 41 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 42 |
57-0690 |
PIN-SPECIAL Price: $3.66 |
| 42 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 43 |
29-4820 |
ROLLER Price: $14.88 |
| 43 |
595901901 |
Nuts This part replaces 539119124. Price: $2.99 |
| 44 |
3211-8 |
SCREW-HH Price: $3.50 |
| 44 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 45 |
594944401 |
NUT HEXAGON FLANGE 5/16-18 ST This part replaces 539112899. Price: $5.99 |
| 45 |
65-5950 |
BUSHING-PULLEY Price: $4.44 |
| 46 |
3230-23 |
SCREW-CARR Price: $0.89 |
| 46 |
532187690 |
WASHER.SPACER.MANDREL Price: $3.99 |
| 47 |
3211-15 |
SCREW-HH Price: $7.99 |
| 48 |
13-3949 |
DEFLECTOR ASM Price: $214.07 |
| 49 |
67-5360 |
DECAL-DANGER Price: $14.99 |
