| Ref | Part Number | Description |
|---|
| 1 |
99-1598 |
V-BELT Price: $18.59 |
| 2 |
138-3235 |
CAP-END This part replaces 42-3520. Price: $2.29 |
| 3 |
237-153 |
O-RING Price: $2.29 |
| 4 |
63-8701 |
PIVOT ARM ASM Price: $32.82 |
| 5 |
65-4740 |
WASHER-THRUST, KEYED Price: $2.17 |
| 6 |
65-2720 |
RING-RETAINING,CLIP Price: $0.99 |
| 7 |
65-4710 |
RING-FRICTION Price: $2.17 |
| 8 |
139-6643 |
KEY-ROCKING, R.H. This part replaces 66-6040. Price: $5.46 |
| 9 |
139-6644 |
KEY-ROCKING, L.H. This part replaces 66-6050. Price: $5.46 |
| 10 |
16-0029 |
WHEEL AND TIRE ASM Price: $28.44 |
| 10 |
98-7135 |
WHEEL TIRE ASM (SP) Price: $25.16 |
| 11 |
114-3468 |
SCREW-SHOULDER This part replaces 27-6232. Price: $3.15 |
| 11 |
92-1057 |
BOLT-SHOULDER Price: $3.05 |
| 12 |
74-1671 |
SPACER-COVER, WHEEL Price: $1.00 |
| 13 |
74-1660 |
COVER-WHEEL Price: $5.45 |
| 14 |
65-4720 |
SPRING-COMPRESSION Price: $1.08 |
| 15 |
65-4750 |
GEAR-PINION Price: $8.74 |
| 16 |
65-4760 |
WASHER-CLUTCH Price: $1.08 |
| 17 |
65-4730 |
WASHER-ARM, PIVOT Price: $2.17 |
| 18 |
3296-6 |
NUT-LOCK Price: $1.49 |
| 18 |
603773 |
LOCKNUT Price: $2.09 |
| 19 |
63-8721 |
SPRING ARM ASM Price: $12.03 |
| 20 |
32144-85 |
SCREW-HWH Price: $1.59 |
