| Ref | Part Number | Description |
|---|
| 1 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 2 |
3296-49 |
NUT-LOCK, NI Price: $4.93 |
| 3 |
86-1480 |
WASHER Price: $4.82 |
| 4 |
84-0780-01 |
PULLEY-SPINDLE Price: $290.34 |
| 5 |
253-154 |
SEAL-OIL Price: $5.48 |
| 6 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 7 |
69-1530 |
HOUSING-SPINDLE Price: $227.62 |
| 8 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 9 |
95-4387 |
SPINDLE SHAFT ASM - CTR Price: $155.61 |
| 10 |
138-6416 |
SPACER-SPINDLE, SHAFT This part replaces 92-9800. Price: $18.44 |
| 11 |
86-0010-03 |
BLADE-19" This part replaces 86-0010. Price: $32.86 |
| 12 |
72-9361 |
CUP-SCALP, ANTI Price: $39.78 |
| 14 |
92-5816 |
BOLT-BLADE Price: $4.93 |
| 505897601 |
506897601 |
NUT This part replaces 505897601. Price: $3.99 |
| 506532701 |
506532701 |
PULLEY Price: $39.99 |
| 506535603 |
506535603 |
SPRING Price: $4.99 |
| 506597401 |
506597401 |
BOLT Price: $5.99 |
| 506597501 |
506597501 |
WASHER Price: $6.99 |
| 506789901 |
506789901 |
LINK Price: $89.99 |
| 506813801 |
506813801 |
PLATE Price: $5.99 |
| 506814905 |
506814905 |
ROD Price: $18.36 |
| 506826801 |
506826801 |
BUSHING Price: $14.99 |
| 506837601 |
506837601 |
SPRING Price: $27.99 |
| 506837701 |
506837701 |
SCREW Price: $8.99 |
| 506868702 |
506868702 |
Pipe Price: $135.34 |
| 506869601 |
506869601 |
BEARING Price: $8.99 |
| 506895801 |
506895801 |
BOLT Price: $6.99 |
| 506897601 |
506897601 |
NUT Price: $3.99 |
| 506941304 |
506941304 |
Rod Price: $21.24 |
| 506951701 |
506951701 |
LINK Price: $39.99 |
| 506963001 |
506963001 |
DECK ROLLER, FRONT Price: $54.99 |
| 506963701 |
506963701 |
BRACKET Price: $5.99 |
| 506972601 |
535471001 |
FRAME This part replaces 506972601. Price: $379.99 |
| 506974601 |
506974601 |
PIN Price: $19.99 |
| 506974801 |
506974801 |
PULLEY Price: $44.99 |
| 506975001 |
506975001 |
Guide Price: $9.25 |
| 506976301 |
506976301 |
ARM Price: $37.99 |
| 506976801 |
594020601 |
Springs This part replaces 506976801. Price: $14.99 |
| 506978101 |
506978101 |
PIPE Price: $169.99 |
| 506978501 |
506978501 |
Frame Price: $155.35 |
| 506979101 |
506979101 |
Washer Price: $5.40 |
| 506979601 |
506979601 |
WHEEL Price: $19.99 |
| 506980001 |
506980001 |
SHAFT Price: $17.99 |
| 506982501 |
506982501 |
Washer Price: $6.01 |
| 506982801 |
506982801 |
BRACKET Price: $6.99 |
| 506997901 |
506997901 |
LINK Price: $84.99 |
| 721680251 |
721680251 |
R-CLIP Price: $4.99 |
| 721861701 |
721861701 |
BOLT Price: $8.99 |
| 722783902 |
722783902 |
Rivet Price: $1.99 |
| 725245751 |
725245751 |
SCREW Price: $4.99 |
| 725246151 |
725246151 |
BOLT Price: $4.99 |
| 725246251 |
725246251 |
SCREW Price: $4.99 |
| 725249571 |
725249571 |
SCREW Price: $6.99 |
| 731232051 |
731232001 |
Nut This part replaces 731232051. Price: $3.99 |
| 732211801 |
732211801 |
LOCKNUT M8 Price: $3.99 |
| 732212051 |
732212001 |
NUT This part replaces 732212051. Price: $3.99 |
| 732252201 |
732252201 |
Nut Price: $2.65 |
| 734116441 |
734116441 |
SPACER Price: $3.99 |
| 734117201 |
596134901 |
GSPH This part replaces 734117201. Price: $2.99 |
| 734117771 |
734117771 |
BUSHING Price: $3.99 |
| 734118201 |
734118201 |
WASHER Price: $4.99 |
| 735311520 |
735311520 |
RETAINING RING Price: $2.99 |
| 735311700 |
735311700 |
RETAINING RING SGA 15 Price: $2.99 |
