| Ref | Part Number | Description |
|---|
| 1 |
92-6564 |
DECAL-4 MATIC Price: $41.48 |
| 2 |
532137352 |
MUFFLER.LT.BRIGGS.14HP.IC/OHV Price: $39.99 |
| 2 |
76-8700 |
PANEL - CONSOLE GAGE Price: $82.40 |
| 3 |
218-447 |
WASHER-LOCK Price: $3.79 |
| 4 |
218-446 |
NUT-HEX Price: $6.09 |
| 5 |
62-7770 |
KEY-IGNITION Price: $4.39 |
| 6 |
3254-20 |
WASHER-LOCK, INT Price: $1.29 |
| 7 |
3218-19 |
NUT-HJ This part replaces 218-500. Price: $0.54 |
| 8 |
66-2960 |
WARNING LAMP CLUSTER Price: $210.90 |
| 9 |
582540301 |
KEEPER.BELT.ENG.3.25"2BOLT This part replaces 584911601. Price: $8.99 |
| 9 |
76-9060 |
GAUGE-TEMPERATURE Price: $110.89 |
| 10 |
66-2940 |
GAUGE-FUEL Price: $178.34 |
| 11 |
120-2244 |
HOURMETER This part replaces 66-2950. Price: $48.06 |
| 12 |
32144-4 |
SCREW-HWH Price: $1.29 |
| 12 |
586729001 |
PULLEY.ENGINE Price: $27.99 |
| 13 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 14 |
69-4780 |
CLAMP-GAUGE Price: $73.28 |
| 15 |
32144-19 |
SCREW-SHWH Price: $0.89 |
| 15 |
581289901 |
FUEL.TANK.ASM.NON-EPA Price: $44.99 |
| 16 |
32105-12 |
SCREW Price: $2.19 |
| 17 |
138-1911 |
PTO SWITCH KIT This part replaces 85-4980. Price: $320.00 |
| 18 |
32128-33 |
NUT-HF Price: $0.25 |
| 18 |
581075501 |
CAP.2.25'.VENTED.RATCHET.EPA This part replaces 532430220. Price: $22.99 |
| 19 |
3274-31 |
SCREW-HSBH This part replaces 3274-68. Price: $0.89 |
| 20 |
27-2360 |
SWITCH Price: $46.56 |
| 20 |
532176636 |
CONTROL.TH/CK.C.BLACK This part replaces 532183897. Price: $27.99 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 21 |
82-3750-03 |
COVER-CONSOLE This part replaces 82-3750. Price: $183.31 |
| 22 |
77-3620 |
KNOB-RETAINER Price: $15.13 |
| 23 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 28 |
587044820 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532137040. Price: $9.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 79 |
596134201 |
Screws This part replaces 532192334. Price: $2.99 |
| 84 |
817060620 |
SCREW.3/8-16 Price: $5.99 |
| 85 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532173937. Price: $2.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 96 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 97 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 122 |
532421922 |
EXTENSION DRAIN OIL Price: $24.99 |
