| Ref | Part Number | Description |
|---|
| 1 |
530016386 |
Screw Price: $5.99 |
| 1 |
98-9590 |
NUT-CAP Price: $3.86 |
| 2 |
530058573 |
Assy-Shroud/H'shield Price: $14.99 |
| 2 |
98-9547 |
CAM-FUEL Price: $87.63 |
| 3 |
530071486 |
O-Ring-C'case (kit) Price: $5.99 |
| 3 |
98-9548 |
WASHER Price: $3.49 |
| 4 |
530028802 |
Assy-Crankshaft Price: $21.92 |
| 4 |
98-9669 |
GEAR-PUMP, INJECTION Price: $86.00 |
| 5 |
98-9350 |
BOLT Price: $0.98 |
| 6 |
530015941 |
Ring-Retainer-C'shaft Price: $1.99 |
| 6 |
98-9511 |
STOPPER-FUEL, CAMSHAFT Price: $5.18 |
| 7 |
530054115 |
Assy-Flywheel This part replaces 530071487. Price: $27.99 |
| 7 |
98-9383 |
DISCONTINUED Price: Call Us |
| 8 |
530015828 |
Washer-Flat Price: $1.99 |
| 8 |
98-9595 |
KEY-WOODRUFF Price: $2.04 |
| 9 |
530055729 |
Spacer-Flywheel Price: $7.99 |
| 9 |
98-9459 |
CAMSHAFT-FUEL Price: $159.71 |
| 10 |
530015496 |
Screw Price: $1.99 |
| 10 |
98-9382 |
BEARING-BALL Price: $23.27 |
| 11 |
530055681 |
Plate-Baffle Price: $2.99 |
| 11 |
98-9657 |
CIRCLIP-SHAFT, GOVERNOR Price: $4.48 |
| 12 |
530015882 |
Screw Price: $1.99 |
| 12 |
98-9565 |
SCREW-SET Price: $2.66 |
| 13 |
98-9644 |
GOVERNOR SHAFT ASM Price: $527.54 |
| 14 |
545024810 |
Kit-Clutch-Fan/Housing Price: $17.99 |
| 15 |
530027569 |
Handle-Starter Price: $1.99 |
| 16 |
530069232 |
Kit-Rope Price: $3.99 |
| 17 |
530019182 |
Grommet-Ignition Module Price: $1.99 |
| 18 |
530016386 |
Screw-(f/hsg to shrd) Price: $5.99 |
| 19 |
545008010 |
STARTER SPRING This part replaces 530042085. Price: $3.99 |
| 20 |
530016357 |
Screw Price: $1.99 |
| 21 |
530054137 |
Ignition Module Price: $30.99 |
| 22 |
530012510 |
Assy-Crankcase Price: $11.99 |
| 23 |
530055728 |
Bearing-Outer Price: $6.99 |
| 24 |
530019264 |
Seal-Crankcase Price: $2.99 |
| 25 |
738210101 |
BEARING BALL 6001 This part replaces 530032125. Price: $8.99 |
| 26 |
530015934 |
Screw Price: $1.99 |
| 27 |
530071486 |
Seal-Cylinder (kit) Price: $5.99 |
| 29 |
530049817 |
CONNECTING ROD ASSY This part replaces 530069945. Price: $6.99 |
| 30 |
530071833 |
Kit-Piston (Incl. 31 & 32) Price: $22.99 |
| 31 |
530015162 |
Retainer-Piston Pin Price: $1.99 |
| 32 |
545154001 |
RING PISTON This part replaces 530055120. Price: $1.99 |
| 33 |
530071486 |
Gasket-Carb. Adapt.(kit) Price: $5.99 |
| 34 |
530057634 |
Adapter-Carburetor Price: $8.99 |
| 35 |
530016309 |
Screw Price: $1.99 |
| 36 |
530071633 |
Kit-Carburetor Ass'y. (C1U-W13A) Price: $31.99 |
| 37 |
530071718 |
Kit-Choke Lever Price: $8.99 |
| 38 |
530055680 |
Air Box Price: $2.99 |
| 39 |
530016429 |
Screw Price: $1.99 |
| 40 |
530047932 |
Air Filter Foam Price: $1.99 |
| 41 |
530055679 |
Air Filter Cover Price: $1.99 |
| 42 |
530015957 |
Screw Price: $1.99 |
| 43 |
530015123 |
Washer This part replaces 530015158. Price: $1.99 |
| 44 |
530071486 |
Gasket-Carburetor(kit) Price: $5.99 |
| 45 |
530055547 |
Assy-Throttle Cable Price: $5.99 |
| 46 |
952030249 |
Spark Plug(RCJ-6Y) Price: Call Us |
| 47 |
530012500 |
Cylinder Price: $12.99 |
| 48 |
530015953 |
Screw Price: $1.99 |
| 49 |
530071486 |
Gasket-Muffler (kit) Price: $5.99 |
| 51 |
530016338 |
Bolt-Muffler Price: $1.99 |
| 52 |
530071544 |
Kit-Spark Arrestor Price: $6.99 |
| 53 |
530015241 |
Screw Price: $1.99 |
| 54 |
530095992 |
Assy-Pick-up Price: $5.99 |
| 55 |
530069247 |
Kit-Fuel Line(small) Price: $3.69 |
| 56 |
530069216 |
Kit-Fuel Line(large) Price: $3.99 |
| 57 |
530023877 |
Fitting-Fuel Line Price: $1.99 |
| 58 |
530016103 |
Clip-Retainer Price: $1.99 |
