| Ref | Part Number | Description |
|---|
| 1 |
18-0800 |
RH REAR SIDE PLT WA *R Price: $246.19 |
| 1 |
530035017 |
Screw - Pump Cover Price: $0.99 |
| 2 |
18-2310 |
DISCONTINUED Price: Call Us |
| 2 |
530035154 |
WA - 79 Price: $3.33 |
| 2 |
530035191 |
WA - 149 (#35183) Price: $3.99 |
| 3 |
530035135 |
Diaphragm - Pump WA - 79 Only Price: $3.33 |
| 4 |
3296-42 |
NUT-LOCK, NI This part replaces 32146-17. Price: $0.28 |
| 4 |
530035156 |
Screw - Idle Adjustment Price: $1.99 |
| 5 |
18-2680 |
DISCONTINUED Price: Call Us |
| 5 |
504130906 |
GASKET This part replaces 530035164. Price: $1.99 |
| 5 |
530035009 |
WA - 79 Price: $1.99 |
| 6 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 7 |
18-3200 |
DISCONTINUED Price: Call Us |
| 7 |
504130807 |
PUMP DIAPHRAGM This part replaces 530035166. Price: $2.99 |
| 7 |
530035152 |
WA - 79 Price: $5.99 |
| 8 |
3290-56 |
DISCONTINUED Price: Call Us |
| 8 |
530035133 |
Valve - Throttle Price: $3.33 |
| 9 |
321-4 |
SCREW-HH Price: $0.99 |
| 9 |
530035007 |
Clip - Throttle Shaft Price: Call Us |
| 10 |
2412-10 |
CLAMP-R Price: $2.78 |
| 10 |
530035138 |
Spring - Throttle Return Price: Call Us |
| 11 |
3219-2 |
NUT-HEX Price: $0.37 |
| 12 |
5-2973 |
STUD Price: $26.12 |
| 12 |
530035132 |
Shaft Assembly - Throttle Price: Call Us |
| 13 |
5-2967 |
DISCONTINUED Price: Call Us |
| 13 |
530035023 |
Spring - Idle Needle Price: $0.99 |
| 14 |
530035141 |
Needle - Idle Price: $2.99 |
| 15 |
10-3150 |
DISCONTINUED Price: Call Us |
| 16 |
323-7 |
SCREW-HH Price: $0.65 |
| 17 |
2412-4 |
CLAMP-R Price: $4.22 |
| 18 |
530035036 |
Spring - Hi Speed Needle Price: Call Us |
| 18 |
603773 |
LOCKNUT This part replaces 32146-2. Price: $2.09 |
| 19 |
36-9440 |
DISCONTINUED Price: Call Us |
| 19 |
501782201 |
H-NEEDLE This part replaces 530035142. Price: $6.30 |
| 20 |
37-2730 |
DISCONTINUED Price: Call Us |
| 21 |
32104-6 |
SCREW-HH, TAP Price: $3.19 |
| 21 |
530035016 |
Screw - Metering Lever Pin Price: $2.99 |
| 22 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 22 |
501781301 |
GASKET This part replaces 530035147. Price: $0.45 |
| 23 |
323-5 |
SCREW-HH Price: $0.41 |
| 23 |
530035042 |
Plate - Circuit Price: $3.33 |
| 24 |
322-3 |
SCREW-HH Price: $0.79 |
| 25 |
32153-3 |
NUT-HEX, SIDE DEFORM This part replaces 32146-5. Price: $5.59 |
| 25 |
530035151 |
Gasket - Metering Diaphragm Price: $1.99 |
| 26 |
3290-321 |
SCREW-HWH Price: $3.99 |
| 26 |
503896701 |
DIAPHRAGM This part replaces 530035014. Price: $4.99 |
| 27 |
32128-17 |
NUT-LOCK, FLANGE Price: $0.25 |
| 27 |
530035153 |
Screw - Assembly - Metering Cover & Throttle Shaft Clip Price: $3.33 |
| 28 |
18-0850 |
DISCONTINUED Price: Call Us |
| 28 |
530035149 |
Cover - Metering Diaphragm Price: $3.33 |
| 29 |
3290-216 |
WASHER Price: $3.83 |
| 29 |
530035144 |
WA - 79 Price: $24.99 |
| 29 |
530035185 |
WA - 149 (35183) Price: $24.99 |
| 30 |
32146-13 |
NUT-HEX Price: $3.49 |
| 30 |
530035145 |
WA - 79 Price: $14.99 |
| 31 |
603773 |
LOCKNUT This part replaces 32146-2. Price: $2.09 |
| 32 |
325-20 |
SCREW-HH Price: $6.29 |
| 33 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 34 |
18-0790 |
LH REAR SIDE PLT WA *R Price: $246.19 |
| 35 |
218-214 |
DISCONTINUED Price: Call Us |
