| Ref | Part Number | Description |
|---|
| 1 |
120-3801-03 |
FRAME-ARM, CONTROL Price: $445.78 |
| 1 |
532170690 |
TUBE HANDLE BAGGER This part replaces 532165249. Price: $7.14 |
| 2 |
120-6310 |
LCD DISPLAY ASM Price: $584.72 |
| 3 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 532123976. Price: $3.99 |
| 3 |
95-8999 |
SWITCH Price: $42.14 |
| 4 |
105-4232 |
SWITCH Price: $88.64 |
| 4 |
532169916 |
HANDLE.BAGGER.W/LVRS.BLK.CRD Price: $9.99 |
| 5 |
32144-86 |
SCREW-HWHTF Price: $1.29 |
| 5 |
874981024 |
SCREW.PAN.HEAD Price: $4.99 |
| 6 |
3230-23 |
SCREW-CARR Price: $0.89 |
| 6 |
532750029 |
SCREW This part replaces 874981032. Price: $4.99 |
| 7 |
125-1938 |
LATCH Price: $27.46 |
| 7 |
873401000 |
NUT Price: $6.99 |
| 8 |
120-5280 |
BRACKET-JOYSTICK Price: $203.76 |
| 8 |
532441543 |
COVER.PNT.BGR.CRD.WSLOTS.MS668 This part replaces 532181095. Price: $199.99 |
| 9 |
104-7201 |
NUT-HF Price: $0.69 |
| 9 |
872140418 |
Bolt Carriage 1/4-20 x 2.25d x Gr.5 Price: $7.99 |
| 10 |
3258-166 |
SCREW-PRH Price: $0.28 |
| 10 |
583110201 |
TUBE.SUPPORT.BAGGER.CRD This part replaces 532181282. Price: $59.99 |
| 11 |
532165719 |
BRACKET.SUPPORT.UPPER.BAG.CRD Price: $9.99 |
| 11 |
74-5950 |
LATCH-SWELL Price: $21.28 |
| 12 |
104-2065 |
SCREW-HWH Price: $0.28 |
| 12 |
583173701 |
BRKT.PIVOT.LH.CRD This part replaces 532188848. Price: $7.99 |
| 13 |
256-257 |
BUSHING-NYLINER Price: $3.19 |
| 13 |
874760612 |
BOLT Price: $3.99 |
| 14 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 14 |
596564404 |
Bolts This part replaces 874520636. Price: $2.99 |
| 15 |
108-7605 |
COVER-RH Price: $55.56 |
| 16 |
108-7604 |
COVER-LH Price: $55.56 |
| 16 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 17 |
233-42 |
KNOB Price: $12.88 |
| 17 |
595901601 |
GSPW Bolts This part replaces 872140506. Price: $2.99 |
| 18 |
93-5961 |
BOOT-LEVER Price: $56.35 |
| 19 |
112-9181 |
PLATE-BOOT Price: $4.90 |
| 19 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 20 |
161-7350 |
IGNITION SWITCH ASM This part replaces 106-5269. Price: $56.32 |
| 20 |
532188847 |
BRKT.PIVOT.RH.CRD Price: $7.99 |
| 21 |
121-5644 |
DECAL-CONTROL PANEL Price: $30.69 |
| 21 |
532406180 |
BAGGER.ASM.CRD.2007 Price: $129.99 |
| 22 |
120-4158 |
DECAL-CONSOLE, UPPER Price: $23.98 |
| 22 |
532165781 |
BRKT.SIDE.BAG.CRD Price: $2.99 |
| 23 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 24 |
532165783 |
TUBE.PIVOT.BAG.CRD.BLACK Price: $22.99 |
| 25 |
583211601 |
TUBE.FRONT.BAGGER.CRD This part replaces 532193705. Price: $84.99 |
| 27 |
99-8970 |
KEY-LATCH, HOOD Price: $15.13 |
| 28 |
3250-22 |
SCREW-PPH Price: $4.09 |
| 28 |
532165787 |
GRIP.HANDLE.BLACK Price: $5.99 |
| 29 |
114-0446 |
PANEL-ACCESS Price: $18.13 |
| 30 |
117-0169 |
DECAL-FUSES Price: $17.49 |
| 31 |
114-3321 |
CONTROLLER-TEC Price: $1,515.96 |
| 31 |
596029401 |
GSPW Retainers This part replaces 532169484. Price: $3.99 |
| 32 |
32144-87 |
SCREW-HWHTF Price: $0.49 |
| 32 |
532126875 |
RIVET,DRILLED Price: $2.99 |
| 33 |
108-7602 |
REST-ARM Price: $158.43 |
| 33 |
583448501 |
MULCHING.PLUG.92.CRD.NON-TEX This part replaces 532165571. Price: $19.99 |
| 34 |
110-8912 |
SEAL-FOAM Price: $2.23 |
| 34 |
532165570 |
HANDLE.MULCHER.92.CRD (2 2) Price: $44.99 |
| 35 |
110-5331 |
SPRING-COMPRESSION Price: $22.18 |
| 35 |
532165572 |
PIN Price: $12.99 |
| 36 |
283-88 |
PIN-CLEVIS Price: $5.77 |
| 36 |
596134901 |
GSPH This part replaces 819132012. Price: $2.99 |
| 37 |
32144-41 |
SCREW-TAPTITE Price: $4.79 |
| 37 |
532175401 |
Plug Support Bagger CRD Price: Call Us |
| 38 |
4-2390 |
WASHER-FLAT Price: $0.62 |
| 38 |
872010520 |
BOLT.5/16-18X2.5 Price: $4.99 |
| 39 |
110-5313-03 |
BRACKET-RETAINER Price: $35.01 |
| 39 |
532416257 |
SEAL.BAGGER.CRD This part replaces 532180985. Price: $29.99 |
| 40 |
283-73 |
PIN-CLEVIS Price: $0.95 |
| 41 |
322-7 |
SCREW-HH Price: $0.89 |
| 41 |
532169683 |
BRKT.VERT.ADJ.BAGGER.CRD Price: $4.99 |
| 42 |
110-5314 |
LATCH Price: $22.89 |
| 43 |
3272-1 |
PIN-COTTER Price: $0.25 |
| 43 |
532174083 |
PLUG, TUBING END Price: $5.99 |
| 44 |
110-8856 |
SPACER Price: $10.25 |
| 45 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 46 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 46 |
872110510 |
BOLT.CARRIAGE.5/16-18 Price: $4.99 |
| 47 |
133-2929 |
CONTROL-THROTTLE Price: $69.01 |
| 47 |
583211501 |
TUBE.UPPER.BAGGER.CRD This part replaces 532193704. Price: $279.99 |
| 48 |
3290-134 |
SCREW Price: $0.27 |
| 49 |
583208201 |
BAR.SPREADER.BAGGER.CRD This part replaces 532193305. Price: $12.99 |
| 50 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 51 |
529846601 |
SERVICE KIT LATCH.SPRING.BAGGE This part replaces 532199903. Price: $1.99 |
| 53 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 54 |
872110407 |
BOLT.CARRIAGE.1/4-20 X 7/8 This part replaces 872140406. Price: $3.99 |
