| Ref | Part Number | Description |
|---|
| 1 |
603Z05328A |
IDLER BRACKET ASSEMBLY Price: $58.19 |
| 4 |
703-08570-0637 |
TRANSMISSION MOUNTING BRACKET Price: $11.15 |
| 8 |
710-0176 |
HEX SCREW 5/16-18 x 2.75 Price: $3.89 |
| 9 |
710-0395 |
HEX SCREW 5/16-18 x 2.25 GR5 Price: $4.08 |
| 10 |
710-0514 |
SCREW 3/8-16 x 1 GR5 Price: $3.78 |
| 11 |
710-0599 |
SCREW 1/4-20 X.500 Price: $3.86 |
| 12 |
710-0604A |
SCREW 5/16-18 x .625 Price: $3.96 |
| 13 |
710-3119 |
SCREW 3/8-16 x .75 GR 5 Price: $5.91 |
| 14 |
712-04063 |
FLANGE LOCK NUT 5/16-18 Price: $3.56 |
| 15 |
712-04065 |
NUT Price: $3.68 |
| 16 |
712-0459 |
FLANGE LOCK NUT Price: $4.39 |
| 17 |
714-04040 |
BOW TIE COTTER PIN 1/4-5/16 Price: $1.28 |
| 18 |
732-05559 |
EXTENSION SPRING .75 DIA x 5.87 Price: $12.77 |
| 19 |
736-0227 |
WASHER:FLAT: .390 x 1.50 x .134 This part replaces 936-0227. Price: $5.78 |
| 20 |
736-0371 |
FLAT WASHER Price: $3.94 |
| 21 |
738-04162C |
SHOULDER SPACER Price: $12.76 |
| 22 |
738-05222 |
SUPPORT TUBE ROD Price: $13.03 |
| 23 |
946-05331 |
PARK BRAKE CABLE Price: $38.49 |
| 24 |
747-06074 |
IDLER SPRING HOOK This part replaces 747-06074A. Price: $20.19 |
| 25 |
747-06886 |
HYDRO BYPASS ROD Price: $9.14 |
| 26 |
750-06607 |
SUPPORT TUBE Price: $13.24 |
| 27 |
954-05336 |
DRIVE BELT A X 62.24 Price: $49.01 |
