| Ref | Part Number | Description |
|---|
| 1 |
127-3189 |
GASKET KIT Price: $835.82 |
| 1 |
532166627 |
STEERING WHEEL Price: $64.99 |
| 2 |
127-3126 |
GASKET-HEAD, CYLINDER Price: $178.72 |
| 2 |
532193542 |
AXLE.ASM.LT.CAST.LGHTWGHT This part replaces 532184706. Price: $119.99 |
| 3 |
127-3106 |
GASKET-COVER Price: $49.95 |
| 3 |
596873901 |
KIT SPINDLE ASM.PNT.LH.15 This part replaces 532169840. Price: $14.99 |
| 4 |
127-2986 |
SEAL-STEM, VALVE Price: $6.38 |
| 4 |
596873801 |
KIT SPINDLE ASM.PNT.RH.15" This part replaces 532169839. Price: $27.99 |
| 5 |
127-3027 |
SEAL-STEM, VALVE Price: $6.79 |
| 5 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 6 |
127-3021 |
GASKET-INJECTOR Price: $4.54 |
| 6 |
532121748 |
WASHER Price: $3.99 |
| 7 |
127-3107 |
GASKET-MANIFOLD, INTAKE Price: $21.63 |
| 8 |
127-3032 |
O RING-SENSOR, PRESSURE Price: $18.19 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
127-3033 |
O-RING Price: $13.39 |
| 10 |
127-3034 |
GASKET-COLLECTOR Price: $9.66 |
| 10 |
532175121 |
DRAGLINK.15".TIRES.2001 Price: $59.99 |
| 11 |
127-3037 |
GASKET-THROTTLE Price: $2.87 |
| 11 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 12 |
127-3108 |
GASKET-MANIFOLD, EXHAUST Price: $14.96 |
| 12 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 13 |
121-3058 |
GASKET-EXHAUST This part replaces 127-3019. Price: $19.54 |
| 13 |
532136518 |
TUBE, PIVOT AXLE Price: $7.99 |
| 14 |
127-2987 |
GASKET-SILENCER Price: $13.97 |
| 15 |
127-3043 |
GASKET-COOLER, E G R Price: $3.64 |
| 15 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532145212. Price: $3.99 |
| 16 |
127-3046 |
GASKET-E G R Price: $4.88 |
| 17 |
127-3016 |
GASKET Price: $3.83 |
| 17 |
532177883 |
SHAFT ASM STRG Price: $104.99 |
| 18 |
127-3050 |
GASKET-INTAKE VALVE, E G R Price: $5.09 |
| 19 |
127-3051 |
GASKET-OUT VALVE, E G R Price: $4.47 |
| 20 |
127-3162 |
GASKET-D P F Price: $19.60 |
| 21 |
127-3056 |
GASKET-SENSOR Price: $2.23 |
| 22 |
125-7070 |
GASKET Price: $4.75 |
| 23 |
125-7071 |
GASKET Price: $7.59 |
| 24 |
127-3069 |
GASKET-IDLE, SHAFT B Price: $4.14 |
| 25 |
127-3004 |
GASKET Price: $2.73 |
| 26 |
125-6909 |
O-RING Price: $2.55 |
| 27 |
127-2973 |
O-RING Price: $3.16 |
| 28 |
125-7022 |
GASKET Price: $7.07 |
| 29 |
125-7024 |
GASKET Price: $3.16 |
| 29 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 30 |
125-7047 |
GASKET Price: $5.13 |
| 31 |
125-7048 |
O-RING Price: $2.87 |
| 32 |
125-6979 |
GASKET Price: $2.55 |
| 32 |
532171888 |
TIE ROD Price: $59.99 |
| 33 |
125-7110 |
GASKET Price: $3.76 |
| 33 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 819111216. Price: $2.99 |
| 34 |
125-7026 |
GASKET Price: $2.90 |
| 34 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 35 |
125-6978 |
GASKET Price: $2.00 |
| 35 |
873540500 |
NUT, CROWNLOCK Price: $3.99 |
| 36 |
127-3074 |
O-RING Price: $29.78 |
| 36 |
532145207 |
BUSHING STRG 3/4 Price: $4.99 |
| 37 |
125-7174 |
WASHER-SEAL Price: $5.45 |
| 37 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 38 |
125-7175 |
WASHER-SEAL Price: $6.16 |
| 38 |
532172092 |
INSERT.CAP.STRG.WH (3 2) (L B) This part replaces 532166626. Price: $12.99 |
| 39 |
125-7176 |
WASHER-SEAL Price: $7.31 |
| 39 |
819182411 |
Washer 9/16 ID x 1 1/2 OD 11 Ga. Zin Price: $4.99 |
| 40 |
127-3166 |
WASHER-SEAL Price: $6.77 |
| 40 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 41 |
125-7177 |
WASHER-SEAL Price: $6.86 |
| 41 |
532159945 |
STEERING WHEEL ADAPTOR Price: $6.99 |
| 42 |
125-7192 |
GASKET Price: $1.14 |
| 43 |
125-7193 |
GASKET Price: $1.28 |
| 43 |
532121749 |
WASHER Price: $2.99 |
| 44 |
127-3174 |
GASKET Price: $1.28 |
| 45 |
93-0418 |
O-RING Price: $7.29 |
| 46 |
125-7197 |
O-RING Price: $2.55 |
| 46 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 47 |
125-7198 |
O-RING Price: $7.26 |
| 48 |
127-3176 |
O-RING Price: $2.87 |
| 49 |
127-3000 |
HONE Price: $654.34 |
| 65 |
532414736 |
SPACER.BRACE.AXLE This part replaces 532160367. Price: $5.99 |
| 67 |
872110618 |
BOLT CARRIAGE Price: $4.99 |
| 68 |
531167401 |
SERVICE KIT BRACE.AXLE.1 This part replaces 532169827. Price: $19.99 |
| 71 |
531167801 |
SERVICE KIT STEERING ASM This part replaces 532175146. Price: $139.99 |
| 73 |
532160135 |
EXT.STEERING.PREM.BLACK This part replaces 532177593. Price: $4.99 |
| 82 |
531170201 |
SERVICE.KIT BRACKET This part replaces 532169835. Price: $19.99 |
| 87 |
532173966 |
WASHER, FLAT .781 X 1 1/2" Price: $4.99 |
| 88 |
532175118 |
BOLT, SHOULDER 7/16-20 Price: $4.99 |
| 91 |
532175553 |
CLIP.STEERING Price: $9.99 |
| 95 |
532188967 |
WASHER.HARDENED Price: $3.99 |
