| Ref | Part Number | Description |
|---|
| 1 |
127-3071 |
WATER PUMP ASM Price: $827.54 |
| 1 |
532142986 |
HOUSING, LOWER Price: $166.25 |
| 2 |
532142987 |
HOUSING.UPPER.70122.HYDRO-GEAR Price: $138.99 |
| 3 |
125-6998 |
GASKET Price: $12.33 |
| 3 |
532142932 |
SEAL.LIP.H-G.(9008000-0128) Price: $9.99 |
| 4 |
125-6999 |
PLATE Price: $58.91 |
| 4 |
532142928 |
RING RETAINING 2003016 Price: $4.99 |
| 5 |
532142933 |
RING.RETAINING.(2003052) Price: $4.99 |
| 6 |
532142934 |
BALL BEARING Price: $49.99 |
| 7 |
532142935 |
CRADLE BEARING Price: $17.99 |
| 8 |
532150771 |
BEARING, THRUST 50551 Price: $29.99 |
| 9 |
127-3017 |
JOINT Price: $71.31 |
| 9 |
532142937 |
SWASHPLATE (2003087) Price: $163.99 |
| 10 |
125-7123 |
PLUG Price: $9.86 |
| 11 |
127-3175 |
PLUG Price: $2.87 |
| 12 |
125-7195 |
PLUG Price: $2.71 |
| 13 |
125-7234 |
SCREW Price: $2.32 |
| 13 |
532169898 |
KIT CYLINDER #70331 This part replaces 532142938. Price: $119.99 |
| 14 |
125-7047 |
GASKET Price: $5.13 |
| 14 |
532142939 |
TRUNNION ARM Price: $179.99 |
| 15 |
125-6986 |
JOINT Price: $24.66 |
| 15 |
532142940 |
LIP SEAL Price: $4.99 |
| 16 |
125-7048 |
O-RING Price: $2.87 |
| 17 |
125-6978 |
GASKET Price: $2.00 |
| 17 |
532142941 |
SLOT GUIDE Price: $7.99 |
| 18 |
125-7192 |
GASKET Price: $1.14 |
| 18 |
532150772 |
SHAFT, MOTOR Price: $182.99 |
| 19 |
532150773 |
BEARING, THRUST 50552 Price: $44.99 |
| 19 |
93-0362 |
BOLT Price: $3.89 |
| 20 |
125-7214 |
BOLT Price: $3.77 |
| 21 |
125-7219 |
BOLT Price: $4.58 |
| 22 |
125-7222 |
BOLT Price: $4.99 |
| 23 |
125-7039 |
V-PULLEY Price: $23.56 |
| 23 |
532142944 |
BLOCK, CYL ASSY Price: $168.73 |
| 24 |
127-2998 |
V-BELT Price: $20.88 |
| 24 |
532142945 |
LIP SEAL Price: $3.57 |
| 25 |
125-7206 |
BOLT Price: $1.97 |
| 25 |
532142946 |
BYPASS ACTUATOR Price: $18.99 |
| 26 |
125-7029 |
THERMOSTAT Price: $56.77 |
| 26 |
532169051 |
CENTER SECTION 70250 This part replaces 532150774. Price: $379.99 |
| 27 |
125-7026 |
GASKET Price: $2.90 |
| 27 |
532142948 |
LIP SEAL Price: $7.99 |
| 28 |
125-7034 |
COVER Price: $78.09 |
| 28 |
532142949 |
RETAINING RING Price: $4.99 |
| 29 |
125-7110 |
GASKET Price: $3.76 |
| 29 |
532142950 |
WASHER Price: $3.99 |
| 30 |
125-7594 |
BOLT Price: $3.00 |
| 30 |
532150787 |
PLATE Price: $2.42 |
| 31 |
125-6953 |
PLUG Price: $7.59 |
| 32 |
125-7124 |
SENSOR-THERMOSTAT, CW Price: $96.15 |
| 33 |
125-6979 |
GASKET Price: $2.55 |
| 34 |
125-7176 |
WASHER-SEAL Price: $7.31 |
| 34 |
532169893 |
FILTER. 50990 This part replaces 532142951. Price: $109.99 |
| 35 |
127-3017 |
JOINT Price: $71.31 |
| 35 |
532142952 |
BYPASS ARM Price: $20.99 |
| 36 |
127-3072 |
WATER IN PIPE ASM Price: $51.67 |
| 36 |
532142953 |
RETAINING RING 44870 Price: $4.99 |
| 37 |
532122660 |
ARM BRAKE ACTUATO This part replaces 532142954. Price: $12.99 |
| 38 |
127-3020 |
CLIP-HOSE Price: $2.92 |
| 38 |
532142955 |
ACTUATING PIN 44891 Price: $8.99 |
| 39 |
532150777 |
BOLT 5/16-24 X 1-3/4 Price: $5.99 |
| 40 |
127-3115 |
WATER OUT PIPE ASM Price: $21.26 |
| 40 |
532150778 |
LOCKNUT, HEX 5/16-24 Price: $4.99 |
| 41 |
127-3020 |
CLIP-HOSE Price: $2.92 |
| 41 |
532142958 |
BRAKE ROTOR 70135 HYDRO-GEAR Price: $84.99 |
| 43 |
127-3116 |
WATER OUT PIPE ASM Price: $47.67 |
| 44 |
127-3020 |
CLIP-HOSE Price: $2.92 |
| 44 |
532142990 |
DIFFERENTIAL ASSEMBLY Price: $274.75 |
| 47 |
127-3117 |
PIPE-OUT, CW Price: Call Us |
| 52 |
532142991 |
WASHER.HYDRO-GEAR 44875 Price: $5.99 |
| 53 |
532142961 |
SEAL.HYDRO.53901 Price: $8.99 |
| 56 |
532142963 |
SHAFT.INPUT.50005 Price: $129.99 |
| 58 |
532142964 |
BOLT #44876 Price: $4.99 |
| 59 |
532142965 |
PIN Price: $8.99 |
| 62 |
532142966 |
CONTROL ARM 50254 Price: $27.99 |
| 63 |
532142967 |
DAMPENER PUCK Price: $5.99 |
| 64 |
532142920 |
SCREW.SET.50018 Price: $5.99 |
| 68 |
532142969 |
SPRING HELICAL COMP 50277 Price: $6.99 |
| 69 |
532144610 |
STUD 5/16-24 50284 Price: $7.99 |
| 92 |
532142977 |
SPRING 2003014 Price: $3.99 |
| 93 |
532142978 |
WASHER Price: $5.99 |
| 98 |
532142993 |
BEARING SLV 50137 Price: $11.99 |
| 99 |
532169054 |
SEAL LIP.75X1X.158 50941 This part replaces 532142976. Price: $17.99 |
| 113 |
532142578 |
VENT CAP 70109 This part replaces 532142917. Price: $37.99 |
| 114 |
532142918 |
O-RING KIT 70110 Price: $22.99 |
| 119 |
584282801 |
SPACER .32X.59X.50 50278 This part replaces 532142980. Price: $5.99 |
| 134 |
584281701 |
NUT CASTLE 5/16-24 PL 44142 This part replaces 532144607. Price: $4.99 |
| 135 |
532122656 |
PIN COTTER This part replaces 532144608. Price: $5.46 |
| 139 |
532150775 |
SPRING, COMPRESSION 50431 Price: $4.99 |
| 140 |
532150776 |
NUT, HEX 5/16-24 Price: $2.99 |
