| Ref | Part Number | Description |
|---|
| 1 |
127-3023 |
CASE-GEAR Price: $644.39 |
| 1 |
532401042 |
SEAT.XG090.BLK.KB/BLT.NO-LOG This part replaces 532140838. Price: $149.99 |
| 2 |
125-6995 |
PIN Price: $5.45 |
| 2 |
531152401 |
SERVICE KIT BRACKET SEAT PIVOT This part replaces 532140551. Price: $8.99 |
| 3 |
125-6972 |
COVER-FILLER Price: $10.14 |
| 3 |
596564401 |
Bolts This part replaces 874760616. Price: $3.99 |
| 4 |
125-7107 |
PIPE Price: $8.10 |
| 4 |
819131610 |
WASHER PM Price: $4.99 |
| 5 |
125-6909 |
O-RING Price: $2.55 |
| 5 |
532145006 |
PUSH CLIP Price: $2.99 |
| 6 |
127-2973 |
O-RING Price: $3.16 |
| 6 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 7 |
125-7197 |
O-RING Price: $2.55 |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $5.99 |
| 8 |
125-7214 |
BOLT Price: $3.77 |
| 8 |
817000616 |
SCREW 3/8-16X1 This part replaces 817490616. Price: $5.99 |
| 9 |
127-3024 |
GEARCASE COVER ASM Price: $475.19 |
| 9 |
596140201 |
Washers This part replaces 819131614. Price: $2.99 |
| 10 |
532195530 |
PAN.ASM.SEAT.1SLOT This part replaces 532155925. Price: $17.99 |
| 11 |
125-6944 |
SEAL-OIL Price: $31.03 |
| 11 |
532166369 |
KNOB.SEAT.ADJ.WINGNUT This part replaces 532120068. Price: $6.99 |
| 12 |
125-6977 |
COVER Price: $8.10 |
| 13 |
125-7174 |
WASHER-SEAL Price: $5.45 |
| 13 |
532121248 |
BUSHING Price: $4.99 |
| 14 |
125-7214 |
BOLT Price: $3.77 |
| 14 |
872050412 |
BOLT.ROUND.HEAD.SQUARE.NECK Price: $4.99 |
| 15 |
125-7217 |
BOLT Price: $4.58 |
| 15 |
532134300 |
SPACER SPLIT 28X.96 Price: $3.99 |
| 16 |
125-7218 |
BOLT Price: $3.48 |
| 16 |
532121250 |
SPRING Price: $3.99 |
| 17 |
125-7222 |
BOLT Price: $4.99 |
| 17 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 532123976. Price: $3.99 |
| 18 |
532124238 |
CAP SPRING Price: $4.99 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532153236. Price: $2.99 |
| 22 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 24 |
819171912 |
WASHER Price: $3.99 |
| 25 |
532127018 |
BOLT,SHOULD Price: $4.99 |
