| Ref | Part Number | Description |
|---|
| 1 |
131-1236 |
LEFT DECK ASM Price: $2,679.48 |
| 1 |
532159460 |
WIRE ASM INNER W/ PLUNGER LT Price: $22.99 |
| 2 |
112-1479 |
SKID-BUMPER, DECK Price: $95.09 |
| 2 |
529845601 |
SERVICE KIT SHAFT ASM RH HANDL This part replaces 532159471. Price: $49.99 |
| 3 |
3296-45 |
NUT-HEX Price: $3.79 |
| 3 |
532105767 |
PIN GROOVE. Price: $4.99 |
| 4 |
131-1233-01 |
PLATE-STIFFENER Price: $87.83 |
| 4 |
812000002 |
RETAINING RING LT Price: $3.99 |
| 5 |
3296-56 |
NUT-LOCK, NI Price: $2.09 |
| 5 |
819211621 |
WASHER Price: $4.99 |
| 6 |
132-9421 |
PULLEY-IDLER, FLAT Price: $41.10 |
| 6 |
532120183 |
BEARING.NYLON Price: $5.99 |
| 7 |
100-3102 |
WASHER-FLAT Price: $3.70 |
| 7 |
532125631 |
GRIP HANDLE Price: $6.99 |
| 8 |
108-8076 |
V-BELT, DECK Price: $29.86 |
| 8 |
532125925 |
PLUNGER BUTTON KIT This part replaces 532124526. Price: $5.99 |
| 9 |
3234-42 |
SCREW-HHF Price: $1.10 |
| 10 |
139-1039 |
LOW DRIVEN SPINDLE ASM This part replaces 119-4776. Price: $589.65 |
| 11 |
32108-103 |
SCREW-FH Price: $0.68 |
| 11 |
532165828 |
LIFT LINK, LH This part replaces 532165829. Price: $17.99 |
| 12 |
532165830 |
LINK ASSY. This part replaces 532165831. Price: $9.99 |
| 12 |
69-9290 |
PAD-BUMPER Price: $9.52 |
| 13 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 13 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
| 14 |
104-2250-01 |
SKID-SIDE Price: $116.02 |
| 15 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 16 |
131-1244 |
PLATE-SPINDLE Price: $62.97 |
| 16 |
596433401 |
Nuts This part replaces 873350800. Price: $2.99 |
| 17 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 17 |
532175689 |
TRUNNION Price: $3.99 |
| 18 |
3290-343 |
PIN-HAIR Price: $0.76 |
| 18 |
596135601 |
GSPW NUTS This part replaces 873800800. Price: $3.99 |
| 19 |
132-6150-01 |
BRACKET-CASTER Price: $155.45 |
| 19 |
531165801 |
SERVICE KIT ARM ARM.REAR.SUSPE This part replaces 532139868. Price: $11.99 |
| 20 |
104-3579 |
DECAL-HOC Price: $23.95 |
| 20 |
532194209 |
PIN.COTTER.7/16.BOW TI. Price: $2.99 |
| 21 |
120-5587 |
PIN-CLEVIS Price: $10.38 |
| 22 |
104-7524 |
SHIM Price: $5.30 |
| 23 |
132-6157-01 |
BRACKET-FORK Price: $59.18 |
| 23 |
532110807 |
NUT T Price: $3.99 |
| 24 |
3231-33 |
SCREW-CARR Price: $4.29 |
| 24 |
819131016 |
WASHER Price: $2.99 |
| 25 |
3233-2 |
SCREW-CARR Price: $1.49 |
| 25 |
532002876 |
SPRING This part replaces 532124874. Price: $3.99 |
| 26 |
106-2047 |
ROD-TENSION Price: $9.83 |
| 26 |
596029401 |
GSPW Retainers This part replaces 532169484. Price: $3.99 |
| 27 |
3231-22 |
SCREW-CARR Price: $0.72 |
| 27 |
532126971 |
ROD ADJ LIFT Price: $5.99 |
| 28 |
104-0858 |
BOLT-SHOULDER Price: $4.69 |
| 28 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 873350600. Price: $4.99 |
| 29 |
532138057 |
KNOB INF 3/8-16 Price: $6.99 |
| 29 |
920242 |
WASHER-FLAT This part replaces 9202424. Price: $5.19 |
| 30 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 30 |
532150233 |
TRUNNION Price: $9.99 |
| 31 |
325-7 |
SCREW-HH Price: $1.53 |
| 31 |
532169865 |
BEARING.PIVOT.LIFT Price: $5.99 |
| 32 |
32120-72 |
RING-SNAP Price: $2.09 |
| 32 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 33 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 34 |
110-6128 |
IDLER ARM ASM Price: Call Us |
| 35 |
32128-14 |
NUT-HF Price: $0.41 |
| 36 |
532155097 |
POINTER, HEIGHT INDICATOR(2 2) Price: $4.99 |
| 36 |
68-0090 |
SCREW-ADJUSTING Price: $7.49 |
| 37 |
139-1728 |
BOLT-HH FT This part replaces 9114524. Price: $1.29 |
| 37 |
532123935 |
PLUG,HOLE Price: $4.99 |
| 38 |
107938 |
SPRING-EXTENSION Price: $9.99 |
| 38 |
593337601 |
Screws This part replaces 817060516. Price: $3.99 |
| 39 |
32128-26 |
NUT-FLANGE Price: $5.89 |
| 40 |
819112410 |
WASHER Price: $3.99 |
| 40 |
9136144 |
SCREW-HWHTF Price: $6.29 |
| 41 |
532123934 |
HEIGHT INDICATOR Price: $2.99 |
| 41 |
70-1160 |
WASHER Price: $3.59 |
| 49 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532145212. Price: $3.99 |
| 50 |
532110452 |
NUT PUSH M Price: $2.99 |
