| Ref | Part Number | Description |
|---|
| 1 |
5-0743-03 |
SPRING-MOWER This part replaces 5-0743. Price: $188.53 |
| 1 |
522023801 |
PULLEY - 6.57 Price: $37.99 |
| 2 |
539130563 |
MOUNT-ROLLER, REAR RH 72" Price: $11.99 |
| 2 |
62-7240 |
DISCONTINUED Price: Call Us |
| 3 |
539114823 |
CAP, VINYL Price: $2.99 |
| 3 |
62-7300 |
CHAIN Price: $9.30 |
| 4 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 4 |
539103295 |
IDLER BUSHING Price: $12.99 |
| 5 |
282-4 |
SHACKLE Price: $32.98 |
| 5 |
539103257 |
IDLER PULLEY Price: $49.99 |
| 6 |
283-6 |
PIN-CLEVIS Price: $1.70 |
| 6 |
596770301 |
Washers This part replaces 539103303. Price: $4.99 |
| 7 |
505290102 |
COVER - BELT, 36 PAINTED Price: $199.99 |
| 7 |
92-1818-01 |
ARM-SPRING, TENSION This part replaces 92-1818. Price: $13.39 |
| 8 |
323-7 |
SCREW-HH Price: $0.65 |
| 8 |
596433701 |
GSPW Washers This part replaces 539990517. Price: $2.99 |
| 9 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 9 |
596240901 |
GSPW Nuts This part replaces 539976979. Price: $2.99 |
| 10 |
3256-45 |
WASHER-FLAT Price: $0.28 |
| 10 |
539108507 |
HCS 3/8-16 X 7/8 GR 5 ZD Price: $2.99 |
| 11 |
539101341 |
HCS 3/8C X 3 Price: $4.99 |
| 11 |
83-7900 |
DISCONTINUED Price: Call Us |
| 12 |
539110655 |
SPRING Price: $11.99 |
| 12 |
76-0370 |
BOLT ASSY Price: $26.50 |
| 13 |
3272-13 |
PIN-COTTER Price: $0.25 |
| 13 |
539108450 |
TOP DUST CAP Price: $4.99 |
| 14 |
283-40 |
PIN-CLEVIS Price: $2.85 |
| 14 |
596917301 |
Washers This part replaces 539111897. Price: $4.99 |
| 15 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 15 |
505247401 |
BELT - DECK 36 (103 L) Price: $99.99 |
| 16 |
505290402 |
WEDGE - PAINTED Price: $44.99 |
| 17 |
125-5196 |
BUSHING This part replaces 3-0348. Price: $6.00 |
| 18 |
539132581 |
HINGE, BIN Price: $19.99 |
| 18 |
62-7250 |
VINYL SLEEVE Price: $32.91 |
| 19 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 19 |
539132579 |
BASE HINGE - PAINTED Price: $22.99 |
| 20 |
283-1 |
PIN-CLEVIS Price: $1.63 |
| 20 |
596582301 |
Washers This part replaces 539990055. Price: $2.99 |
| 21 |
18-2970 |
CLIP-FUEL LINE Price: $8.67 |
| 21 |
596230901 |
Screws This part replaces 539990580. Price: $2.99 |
| 22 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 22 |
510126701 |
LATCH, SHORT WING Price: $22.99 |
| 23 |
322-4 |
SCREW-HH Price: $0.35 |
| 23 |
539130391 |
ARM-IDLER W/BRG Price: $37.99 |
| 24 |
55-4300 |
DECAL-WARNING Price: $13.99 |
| 24 |
596581801 |
Bolts This part replaces 539130235. Price: $2.99 |
| 24 |
93-6696 |
DECAL-WARNING Price: $14.78 |
| 25 |
256-115 |
WASHER-THRUST Price: $1.90 |
| 25 |
510254502 |
SHIELD DUST This part replaces 510254501. Price: $3.99 |
| 26 |
539107042 |
HCS 3/8-16 X 1-1/2 Price: $2.99 |
| 26 |
92-1815 |
SHAFT-C.U. PIVOT Price: $59.70 |
| 27 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 27 |
596433501 |
NUT NUT.3/8-16.HEX.JAM.Z 3/8-1 This part replaces 539109332. Price: $2.99 |
| 28 |
3234-32 |
SCREW-HHF Price: $8.48 |
| 28 |
596583501 |
Washers This part replaces 539990613. Price: $2.99 |
| 29 |
16-1089 |
DISCONTINUED Price: Call Us |
| 29 |
539130242 |
BUSHING, IDLER Price: $2.99 |
| 30 |
302-60 |
FITTING-GREASE Price: $2.26 |
| 30 |
539103433 |
HCS 1/2C X 3 1/4 Price: $5.99 |
| 31 |
510206301 |
PIVOT, BEARING Price: $3.99 |
| 31 |
92-1812 |
SHAFT-PIVOT, LIFT Price: $51.90 |
| 32 |
283-75 |
PIN-CLEVIS Price: $1.56 |
| 32 |
596437501 |
Washers This part replaces 539102243. Price: $8.99 |
| 33 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 33 |
522023401 |
WASHER, 3/8 THICK Price: $2.99 |
| 34 |
596135601 |
GSPW NUTS This part replaces 539101331. Price: $3.99 |
| 34 |
94-6912 |
Shackle Price: Call Us |
| 35 |
32104-6 |
SCREW-HH, TAP Price: $3.19 |
| 36 |
322-26 |
SCREW-HH Price: $2.36 |
