| Ref | Part Number | Description |
|---|
| 1 |
46-0330 |
NUT-LOCK Price: $0.60 |
| 2 |
74-6520 |
FLAT WASHER Price: $0.93 |
| 3 |
94-3162 |
STUD This part replaces 74-6530. Price: $30.04 |
| 4 |
74-6540 |
TAPPET-VALVE Price: $41.87 |
| 5 |
74-6550 |
CUP Price: $4.84 |
| 6 |
74-6560 |
SPRING-VALVE Price: $14.26 |
| 7 |
74-6570 |
CUP-VALVE SPRING, LOWER Price: $3.36 |
| 8 |
74-6580 |
INSERT-VALVE (1.65MM) Price: $44.94 |
| 8 |
74-6970 |
INSERT-VALVE (3.025MM) Price: $7.10 |
| 8 |
74-7220 |
INSERT-VALVE (3.925MM) Price: $11.14 |
| 9 |
74-7240 |
COLLAR-SPLIT Price: $5.39 |
| 10 |
74-7250 |
DISCONTINUED Price: Call Us |
| 11 |
74-7260 |
BOLT-HEAD Price: $17.07 |
| 12 |
74-7270 |
WASHER-FLAT Price: $3.60 |
| 13 |
74-7280 |
PLUG Price: $3.44 |
| 14 |
74-7840 |
PLUG Price: $2.02 |
| 15 |
2412-119 |
CLAMP-HOSE, WORM DRIVE Price: $1.83 |
| 17 |
3253-4 |
WASHER-LOCK This part replaces 68-9420. Price: $0.25 |
| 18 |
33114-025 |
SCREW-HH This part replaces 48-9460. Price: $0.70 |
| 19 |
74-7340 |
DISCONTINUED Price: Call Us |
| 20 |
74-7350 |
HOSE Price: $41.96 |
| 21 |
74-7360 |
COLLECTOR TUBE Price: $117.45 |
| 23 |
33114-016 |
SCREW-HH This part replaces 48-7700. Price: $0.27 |
| 24 |
74-7390 |
DISCONTINUED Price: Call Us |
| 25 |
74-7400 |
TUBE Price: $46.54 |
| 26 |
74-7410 |
PLUG Price: $6.57 |
| 27 |
74-7420 |
BALL Price: $1.11 |
| 28 |
74-7430 |
CHAMBER-TURBULENCE Price: $119.14 |
| 29 |
74-7450 |
DISCONTINUED Price: Call Us |
| 30 |
74-7480 |
VALVE-INTAKE Price: $55.79 |
| 31 |
74-7470 |
EXHAUST VALVE Price: $85.90 |
| 32 |
74-7490 |
INTAKE VALVE SEAT Price: $29.47 |
| 33 |
74-7510 |
DISCONTINUED Price: Call Us |
| 34 |
74-7530 |
SEE BUL #03-02 Price: Call Us |
| 35 |
74-7550 |
SCREW - CAP HEX HD Price: $0.66 |
| 36 |
74-7560 |
LOCKWASHER Price: $0.67 |
| 37 |
77-3890 |
BRACKET - HOOD STOP *B Price: $40.20 |
| 38 |
74-7580 |
PLATE Price: $14.96 |
| 39 |
74-7590 |
DISCONTINUED Price: Call Us |
| 40 |
74-7600 |
PLUG (BALL) Price: $6.93 |
| 41 |
92-7797 |
CYLINDER HEAD KIT This part replaces 74-7610. Price: $4,804.68 |
| 42 |
74-7620 |
PLUG Price: $26.15 |
| 43 |
74-7630 |
GASKET-COVER, VALVE Price: $30.06 |
| 44 |
74-7640 |
COVER-VALVE Price: $171.54 |
| 45 |
74-7650 |
WASHER-FLAT Price: $1.03 |
| 46 |
33113-025 |
SCREW-HH This part replaces 48-7640. Price: $1.97 |
| 480 |
601001609 |
PULLEY, V4L 8.40 OD Price: $36.06 |
| 482 |
601001507 |
SQUARE KEY Price: $2.85 |
| 483 |
601001446 |
WASHER Price: $1.99 |
| 484 |
601000107 |
NUT, 1/2-20 REGHXCTRLK Price: $3.99 |
| 485 |
601001610 |
SPACER, SLEV .676X1.00X.53 Price: $3.99 |
| 490 |
601001509 |
RETAINER Price: $2.03 |
| 491 |
601000565 |
BEARING, BALL Price: $16.99 |
| 493 |
601000073 |
SCREW, 5/16-18X .75 HHC Price: $2.99 |
| 495 |
601000019 |
WASHER, FLAT .344X .69X. Price: $2.99 |
| 497 |
601000023 |
WASHER, HVSPTLK .328X.60X Price: $2.99 |
| 499 |
601000012 |
NUT, 5/16-18 REGHEX Price: $5.99 |
| 500 |
601001510 |
HOUSING ASSY/24" - ST724 Price: $104.60 |
| 501 |
601001612 |
BRACKET & NUT ASSY Price: $7.26 |
| 504 |
601001512 |
SCREW Price: $2.53 |
| 505 |
601000015 |
WASHER, REGSPTLK.393X.68X Price: $1.66 |
| 506 |
601002407 |
NUT 3/8-16 This part replaces 601000060. Price: $3.99 |
| 508 |
601001742 |
STUD, BRAKE ARM Price: $8.07 |
| 510 |
601001846 |
BLADE, SCRAPER 27" Price: $42.99 |
| 511 |
601001411 |
BOLT Price: $6.99 |
| 512 |
601000019 |
WASHER, FLAT .344X .69X. Price: $2.99 |
| 513 |
601000023 |
WASHER, HVSPTLK .328X.60X This part replaces 601001744. Price: $2.99 |
| 514 |
601000012 |
NUT, 5/16-18 REGHEX Price: $5.99 |
| 520 |
601001872 |
AUGER, ASSY LH 25" Price: $86.64 |
| 521 |
601001873 |
AUGER, ASSY RH 25" Price: $78.04 |
| 522 |
601001456 |
BOLT, SHEAR 703057 Price: $8.99 |
| 523 |
601001517 |
SPACER Price: $4.99 |
| 524 |
601002318 |
RP NUT This part replaces 601000062. Price: $9.99 |
| 525 |
601001518 |
BEARING, AUGER SHAFT Price: $6.60 |
| 526 |
601001519 |
WASHER Price: $3.23 |
| 527 |
601000520 |
SCREW, 5/16-18X .75 WAHHT Price: $1.74 |
| 530 |
601001520 |
PLATE, AUGER HSNG LH Price: $52.99 |
| 531 |
601001521 |
PLATE, AUGER HSNG RH Price: $51.99 |
| 532 |
601001411 |
BOLT Price: $6.99 |
| 533 |
601000019 |
WASHER, FLAT .344X .69X. Price: $2.99 |
| 534 |
601000023 |
WASHER, HVSPTLK .328X.60X Price: $2.99 |
| 535 |
601000012 |
NUT, 5/16-18 REGHEX Price: $5.99 |
| 536 |
601000899 |
BOLT 5/16-18 X 1.00 Price: $1.58 |
| 540 |
601001745 |
SKID, HEIGHT ADJUST Price: $12.00 |
| 541 |
601001411 |
BOLT Price: $6.99 |
| 542 |
601000019 |
WASHER, FLAT .344X .69X. Price: $2.99 |
| 543 |
601000023 |
WASHER, HVSPTLK .328X.60X Price: $2.99 |
