| Ref | Part Number | Description |
|---|
| 1 |
32104-32 |
SCREW-HWH Price: $1.99 |
| 1 |
532159460 |
WIRE ASM INNER W/ PLUNGER LT Price: $22.99 |
| 2 |
529845601 |
SERVICE KIT SHAFT ASM RH HANDL This part replaces 532159471. Price: $49.99 |
| 2 |
74-9110 |
PAD-PEDAL, REVERSE Price: $13.49 |
| 3 |
120-8095 |
PEDAL Price: Call Us |
| 3 |
532105767 |
PIN GROOVE. Price: $4.99 |
| 4 |
32121-45 |
PIN-SPRING Price: $0.27 |
| 4 |
812000002 |
RETAINING RING LT Price: $3.99 |
| 5 |
74-9100 |
PAD-PEDAL, FORWARD Price: $27.08 |
| 5 |
819211621 |
WASHER Price: $4.99 |
| 6 |
117-9507 |
PEDAL-ACCELERATOR Price: $12.86 |
| 6 |
532120183 |
BEARING.NYLON Price: $5.99 |
| 7 |
323-29 |
SCREW-HH Price: $0.42 |
| 7 |
532125631 |
GRIP HANDLE Price: $6.99 |
| 8 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 8 |
532125925 |
PLUNGER BUTTON KIT This part replaces 532124526. Price: $5.99 |
| 9 |
3220-3 |
NUT-HJ Price: $0.28 |
| 10 |
2411-36 |
BEARING-END, ROD Price: $32.13 |
| 11 |
32121-6 |
PIN-ROLL, SLOTTED Price: $0.28 |
| 11 |
532145537 |
LIFT LINK LH This part replaces 532139865. Price: $22.99 |
| 12 |
322-2 |
SCREW-HH Price: $0.69 |
| 12 |
532145536 |
LIFT LINK RH This part replaces 532139866. Price: $22.99 |
| 13 |
256-236 |
BEARING-MOUNT, FLANGE Price: $27.99 |
| 13 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
| 14 |
32128-20 |
NUT-HF Price: $0.99 |
| 15 |
532173288 |
LINK.SUSPENSION.FRONT Price: $11.99 |
| 16 |
114-5608 |
SPACER-STANDOFF Price: $15.74 |
| 16 |
596433401 |
Nuts This part replaces 873350800. Price: $2.99 |
| 18 |
120-8088-0P |
HUB-TRACTION PEDAL PIVOT This part replaces 120-8088-03. Price: $69.27 |
| 18 |
596135601 |
GSPW NUTS This part replaces 873800800. Price: $3.99 |
| 19 |
115-4383 |
SHAFT-SPRING Price: $38.84 |
| 19 |
531165801 |
SERVICE KIT ARM ARM.REAR.SUSPE This part replaces 532139868. Price: $11.99 |
| 20 |
532003146 |
SPRING RETAINER This part replaces 532163552. Price: $2.99 |
| 21 |
32121-11 |
PIN-ROLL Price: $0.47 |
| 22 |
92-7608-03 |
BRACKET-SPRING Price: $16.86 |
| 23 |
532110807 |
NUT T Price: $3.99 |
| 23 |
92-7610 |
RETAINER-SPRING Price: $26.52 |
| 24 |
819131016 |
WASHER Price: $2.99 |
| 24 |
84-9100 |
SPRING Price: $11.99 |
| 25 |
3256-5 |
WASHER-FLAT Price: $0.27 |
| 25 |
532002876 |
SPRING This part replaces 532124874. Price: $3.99 |
| 26 |
596029401 |
GSPW Retainers This part replaces 532169484. Price: $3.99 |
| 27 |
532126971 |
ROD ADJ LIFT Price: $5.99 |
| 28 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 873350600. Price: $4.99 |
| 29 |
532138057 |
KNOB INF 3/8-16 Price: $6.99 |
| 30 |
532150233 |
TRUNNION Price: $9.99 |
| 31 |
532169865 |
BEARING.PIVOT.LIFT Price: $5.99 |
| 32 |
117-2718 |
DECAL-ARRESTER, SPARK Price: $5.95 |
| 32 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 33 |
120-8038 |
HUB ASM Price: $121.12 |
| 36 |
114-5609 |
SENSOR-POSITION Price: $371.51 |
| 36 |
532155097 |
POINTER, HEIGHT INDICATOR(2 2) Price: $4.99 |
| 37 |
114-5595 |
PLATE-CAPTURE Price: $5.99 |
| 37 |
532123935 |
PLUG,HOLE Price: $4.99 |
| 38 |
32105-21 |
SCREW-HH Price: $1.09 |
| 38 |
593337601 |
Screws This part replaces 817060516. Price: $3.99 |
| 40 |
120-8091 |
SHAFT-PIVOT, TRACTION Price: $33.82 |
| 40 |
819112410 |
WASHER Price: $3.99 |
| 41 |
32121-69 |
PIN-SPRING Price: $1.79 |
| 41 |
532155098 |
IND. HEIGHT STLT Price: $4.99 |
| 43 |
120-8089 |
PLATE-COVER, SENSOR Price: $3.38 |
| 44 |
121-3099 |
PLUG-PANEL, PLASTIC Price: $1.87 |
| 45 |
32121-78 |
PIN-ROLL Price: $3.09 |
| 46 |
3290-321 |
SCREW-HWH Price: $3.99 |
| 49 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532145212. Price: $3.99 |
| 50 |
532110452 |
NUT PUSH M Price: $2.99 |
