| Ref | Part Number | Description |
|---|
| 1 |
32104-95 |
SCREW-HWH Price: $0.41 |
| 2 |
33-0300 |
DISCONTINUED Price: Call Us |
| 2 |
530042088 |
Spring-Muffler Price: $1.99 |
| 3 |
27-4910-01 |
PTO LEVER WA This part replaces 27-4910. Price: $214.21 |
| 3 |
530071391 |
Kit-Spark Arrestor Price: $7.99 |
| 4 |
21-1880 |
GRIP-HANDLE Price: $11.67 |
| 4 |
530015953 |
Screw-Cylinder Price: $1.99 |
| 5 |
32104-116 |
SCREW-HWHTF Price: $0.55 |
| 5 |
503235112 |
Spark Plug This part replaces 952030201. Price: $5.99 |
| 6 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 6 |
530012416 |
Cylinder This part replaces 530069757. Price: $17.99 |
| 7 |
251-269 |
BEARING Price: $19.20 |
| 7 |
530069913 |
Gasket-Cylind./Carb. Price: $4.99 |
| 8 |
32121-31 |
PIN-SPRING Price: $0.26 |
| 8 |
530069994 |
Carb. Adapter Kit This part replaces 530049301. Price: $3.99 |
| 9 |
3-6514 |
THRUST WASHER Price: $1.74 |
| 9 |
530016014 |
Screw Price: $1.99 |
| 10 |
283-42 |
PIN-CLEVIS Price: $40.05 |
| 10 |
530069913 |
Gasket-Carb. Price: $4.99 |
| 11 |
27-4940 |
ENGAGE ARM WA Price: $209.84 |
| 12 |
3230-16 |
SCREW-CARR Price: $1.79 |
| 12 |
530038747 |
Choke Plate Mounting Price: $1.99 |
| 13 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 13 |
530038686 |
Shutter-Choke Price: $1.99 |
| 14 |
251-253 |
BEARING Price: $22.84 |
| 14 |
530052431 |
Air Box Price: $1.99 |
| 15 |
323-8 |
SCREW-HH Price: $1.20 |
| 15 |
530015887 |
Screw Price: $1.99 |
| 16 |
251-255 |
FLANGE Price: $15.34 |
| 16 |
530036569 |
Plate - Filter Support Price: $1.99 |
| 17 |
3218-3 |
NUT-JAM Price: $0.25 |
| 17 |
530036575 |
Foam-Air Filter Price: $1.99 |
| 18 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 18 |
530036568 |
Cover-Air Filter Price: $1.99 |
| 19 |
27-8410 |
PTO BRAKE BRKT WA *BO Price: $205.83 |
| 19 |
530015880 |
Screw Price: $1.99 |
| 20 |
27-8450 |
DISCONTINUED Price: Call Us |
| 20 |
530015852 |
Spacer-Choke Price: $1.99 |
| 21 |
27-9220 |
COMP SPRING *O Price: $25.06 |
| 21 |
530015254 |
Washer Price: $1.99 |
| 22 |
33-0890 |
DISCONTINUED Price: Call Us |
| 23 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 23 |
530053565 |
Piston Ring Price: $1.28 |
| 24 |
3296-45 |
NUT-HEX Price: $3.79 |
| 24 |
530015162 |
Retainer-Piston Pin Price: $1.99 |
| 25 |
41-9150 |
V-BELT, TORQUE TEAM This part replaces 27-4630. Price: $33.98 |
| 25 |
530069615 |
Assy-Connecting Rod Price: $14.99 |
| 26 |
323-18 |
SCREW-HH Price: $0.82 |
| 26 |
530069913 |
Gasket-Cylinder Price: $4.99 |
| 27 |
29-4730 |
WASHER-FLAT Price: $13.10 |
| 27 |
530036145 |
Spacer-Module Price: $1.99 |
| 28 |
27-4530 |
DISCONTINUED Price: Call Us |
| 28 |
530055160 |
Ignition Module Price: $34.99 |
| 29 |
3257-5 |
KEY-WOODRUFF Price: $5.13 |
| 29 |
530015954 |
Screw Price: $1.99 |
| 30 |
28-5640 |
SPECIAL WASHER Price: $3.58 |
| 30 |
581425901 |
SWITCH, GROUND WIRE This part replaces 530014662. Price: $1.99 |
| 31 |
302-40 |
FITTING-GREASE, 90 DEG Price: $1.70 |
| 31 |
530014663 |
Assy-Leadwire Price: $5.99 |
| 32 |
27-4980 |
DISCONTINUED Price: Call Us |
| 33 |
3217-6 |
NUT-HEX Price: $1.19 |
| 33 |
530015650 |
Screw-Nose Cone Price: $1.99 |
| 34 |
28-9050 |
DISCONTINUED Price: Call Us |
| 34 |
530016124 |
Nut-Nose Cone Price: $1.99 |
| 35 |
251-268 |
BEARING Price: $73.04 |
| 35 |
530071356 |
Kit-On/Off Switch Price: $4.99 |
| 36 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 36 |
530027569 |
Handle-Starter Price: $1.99 |
| 37 |
321-6 |
SCREW-HH Price: $0.25 |
| 37 |
530069232 |
Kit - Rope Price: $3.99 |
| 38 |
251-77 |
COLLAR-LOCK, BEARING Price: $10.22 |
| 38 |
530016080 |
Screw Price: $1.99 |
| 39 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 39 |
530038604 |
Coupling-Drive Price: $1.99 |
| 40 |
3217-7 |
NUT-HEX Price: $0.28 |
| 40 |
530015941 |
Retain. Ring-C'shaft Price: $1.99 |
| 41 |
28-8950 |
DISCONTINUED Price: Call Us |
| 41 |
530032124 |
Outer Bearing Price: $4.99 |
| 42 |
3256-41 |
WASHER Price: $1.18 |
| 42 |
530019179 |
C'case Seal Price: $2.99 |
| 43 |
27-7900 |
SCREW-ADJUSTING Price: $21.70 |
| 43 |
530015945 |
Retainer Ring-C'case Price: $1.99 |
| 44 |
44-9350 |
DISCONTINUED This part replaces 27-4850. Price: Call Us |
| 44 |
530032125 |
Inner Bearing Price: $11.99 |
| 45 |
3296-33 |
NUT-LOCK, NI Price: $2.39 |
| 45 |
530069685 |
Assy.-Fan Hsg/Shroud Price: $22.99 |
| 46 |
27-6650 |
BRG RETAINER Price: $23.44 |
| 46 |
530015934 |
Screw Price: $1.99 |
| 47 |
27-6970 |
BEARING STUD Price: $23.97 |
| 47 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 48 |
321-3 |
SCREW-HH Price: $0.28 |
| 49 |
21-0400-01 |
SPRING-COMPRESSION This part replaces 21-0400. Price: $20.88 |
| 50 |
3296-5 |
NUT-HEX Price: $3.09 |
| 50 |
530054083 |
Assy-Crankshaft Price: $5.99 |
| 51 |
3220-3 |
NUT-HJ Price: $0.28 |
| 52 |
3245-1 |
SCREW-SET, HSH Price: $0.54 |
| 53 |
282-1 |
DISCONTINUED Price: Call Us |
| 53 |
545221701 |
FLYWHEEL ASSY This part replaces 530069886. Price: $8.99 |
| 54 |
3272-5 |
PIN-COTTER Price: $1.39 |
| 54 |
530015828 |
Washer-Flat Price: $1.99 |
| 55 |
530015775 |
Screw Price: $1.99 |
| 56 |
530027523 |
Retainer-Can Price: $2.99 |
| 58 |
545008010 |
STARTER SPRING This part replaces 530042085. Price: $3.99 |
| 59 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 61 |
530015886 |
Screw Price: $1.99 |
| 62 |
530016131 |
Washer Price: $1.99 |
| 63 |
530014347 |
Assy-Fuel Cap Price: $4.99 |
| 64 |
530095646 |
Assy-Fuel Pickup Price: $2.99 |
| 65 |
530069247 |
Kit-Fuel Line (Small) Price: $3.99 |
| 66 |
530069216 |
Kit-Fuel Line (Large) Price: $3.99 |
