| Ref | Part Number | Description |
|---|
| 1 |
31788 |
Cylinder Assembly (Incl. Nos. 2, 3, 4 29) Price: Call Us |
| 2 |
27652 |
Pin-Dowel Price: Call Us |
| 3 |
27642 |
Plug-Drain, Oil (SQH 1/4-18) Price: Call Us |
| 5 |
31467 |
Valve, Intake (Standard) Price: Call Us |
| 5 |
31468 |
Valve, Intake (1/32" oversize)(Incl. No. 9) Price: Call Us |
| 6 |
31469 |
Valve, Exhaust (Standard) Price: Call Us |
| 6 |
31470 |
Valve, Exhaust (1/32" oversize)(Incl. No. 9) Price: Call Us |
| 7 |
27882 |
Cap-Spring, Valve Price: Call Us |
| 8 |
27881 |
Spring-Valve Price: Call Us |
| 9 |
27883 |
Cap, Lower valve spring Price: Call Us |
| 9 |
30964 |
Cap, Lower Valve Spring (1/32" oversize) Price: Call Us |
| 10 |
20810 |
Pin, Valve spring retaining Price: Call Us |
| 11 |
32319 |
Crankshaft Assembly (Incl. Nos. 12 13) Price: Call Us |
| 12 |
29783 |
Pin, Groove Price: Call Us |
| 13 |
27884 |
Gear-Crankshaft Price: Call Us |
| 14 |
31794 |
Piston Pin Assembly (Incl. 2 of No. 16)(Standard) Price: Call Us |
| 14 |
31795 |
Piston Pin Assembly (Incl. 2 of No. 16)(.010 oversize) Price: Call Us |
| 14 |
31796 |
PISTON AND PIN ASSY (.020 OVERSIZE) Price: Call Us |
| 15 |
31853 |
RING SET, PISTON (STANDARD) Price: Call Us |
| 15 |
32055 |
Ring Set, Piston (.010 oversize) Price: Call Us |
| 15 |
32056 |
RING SET, PISTON (.020 OVERSIZE) Price: Call Us |
| 16 |
702895 |
DISCONTINUED This part replaces 27888. Price: Call Us |
| 17 |
31295A |
Rod Assembly (Incl. Nos. 18, 19 20) Price: Call Us |
| 18 |
21718 |
Bolt, Connecting Rod Price: Call Us |
| 19 |
26073 |
Washer Price: Call Us |
| 20 |
28264 |
Nut Price: Call Us |
| 21 |
32115 |
Camshaft Price: $2.00 |
| 22 |
27893 |
Lifter Valve Price: Call Us |
| 23 |
31451A |
Cover, Cylinder (Incl. nos. 24, 106, 146, 147 148) Price: Call Us |
| 25 |
31297 |
Dipstick, Oil (Incl. No. 161) Price: Call Us |
| 27 |
8303 |
Lockwasher Price: Call Us |
| 28 |
30564 |
Screw Price: Call Us |
| 29 |
31461 |
Bushing, Crankshaft Price: Call Us |
| 31 |
650489 |
Screw Price: Call Us |
| 33 |
30938A |
CYLINDER HEAD Price: Call Us |
| 34 |
30939 |
Cover, Cylinder head Price: Call Us |
| 35 |
26952 |
Screw Price: Call Us |
| 36 |
6023 |
Screw Price: Call Us |
| 37 |
21943 |
SPARK PLUG Price: Call Us |
| 39 |
28423 |
Body-Breather Price: Call Us |
| 40 |
28424 |
Element-Breather Price: Call Us |
| 41 |
28425 |
Cover-Valve Price: Call Us |
| 43 |
650128 |
Screw Price: Call Us |
| 44 |
27627 |
Tube-Breather Price: Call Us |
| 46 |
30195A |
Flange, Carburetor Price: Call Us |
| 48 |
30196 |
Screw Price: Call Us |
| 51 |
30319 |
Rivet, Split Price: Call Us |
| 52 |
31709 |
Lever, Governor Price: Call Us |
| 55 |
113633-03 |
PULLEY-IDLER, FLAT This part replaces 30205. Price: $78.32 |
| 56 |
31710 |
Link, Governor Lever-to-Throttle Price: Call Us |
| 57 |
31711 |
BRACKET ASSY, SPEED CONTROL Price: Call Us |
| 58 |
28569 |
SPRING, COMPRESSION Price: Call Us |
| 59 |
6674 |
Screw Price: Call Us |
| 60 |
31386 |
Spring, Governor Price: Call Us |
| 63 |
30699A |
ROD ASSY, Governor Price: Call Us |
| 64 |
29536 |
Baffle Blower Housing Price: Call Us |
| 65 |
650561 |
Screw (1/4-20x19/32) Price: Call Us |
| 66 |
32078 |
INSTRUCTION DECAL Price: Call Us |
| 68 |
8274 |
Lockwasher Price: Call Us |
| 69 |
29747 |
Screw Price: Call Us |
| 70 |
31293 |
Housing, Blower Price: Call Us |
| 71 |
650490 |
Washer Price: Call Us |
| 72 |
8116 |
Nut Price: Call Us |
| 73 |
30700 |
Yoke-Governor Price: Call Us |
| 74 |
650494 |
Screw (6-40x5/16) Price: Call Us |
| 76 |
29752 |
Nut and Lock Washer (1/4-28) Price: Call Us |
| 78 |
26460 |
Clamp-Line, Fuel Price: Call Us |
| 80 |
650572 |
Screw Price: Call Us |
| 84 |
30767 |
Spacer Price: Call Us |
| 85 |
31481 |
Washer Price: Call Us |
| 86 |
650513 |
Nut-Wing Price: Call Us |
| 87 |
30803 |
Bracket, Air Cleaner Price: Call Us |
| 88 |
28820 |
Screw (10-32 x 1/2) Price: Call Us |
| 89 |
30804 |
Element, Cleaner Price: Call Us |
| 90 |
30805 |
Cover, Air Cleaner Price: Call Us |
| 98 |
31697 |
Strap, Fuel Tank Price: Call Us |
| 100 |
29538 |
Base Engine Price: Call Us |
| 103 |
29633 |
Muffler Price: Call Us |
| 104 |
28443 |
Nut, Conduit Price: Call Us |
| 105 |
30209 |
EIbow, Street Price: Call Us |
| 106 |
31845 |
Shaft-Governor Price: Call Us |
| 107 |
30591 |
Gear Assy., Governor (Incl. No.132) Price: Call Us |
| 108 |
29193 |
Ring-Retaining Price: Call Us |
| 109 |
30588A |
Spool-Governor Price: Call Us |
| 110 |
30244 |
Nipple, Pipe Price: Call Us |
| 111 |
6202 |
Screw Price: Call Us |
| 112 |
31694 |
BRACKET, FUEL TANK Price: Call Us |
| 113 |
29715 |
Screw Price: Call Us |
| 114 |
31301 |
Tank Assembly, Fuel (Incl. No. 115) Price: Call Us |
| 115 |
27799 |
Cap, Fuel tank Price: Call Us |
| 116 |
29752 |
Nut and Lock Washer (1/4-28) Price: Call Us |
| 117 |
29683 |
Fitting Shut-off, Fuel Price: Call Us |
| 118 |
30705 |
Line-Fuel Price: Call Us |
| 119 |
29212 |
Screw Price: Call Us |
| 120 |
650128 |
Screw Price: Call Us |
| 121 |
30622 |
Emnsion, Blower Housing Price: Call Us |
| 122 |
30590A |
Washer-Flat Price: Call Us |
| 123 |
29642 |
Ring-Retaining Price: Call Us |
| 124 |
29716 |
Screw Price: Call Us |
| 125 |
31345 |
IDENTIFICATION PLATE Price: Call Us |
| 126 |
29309 |
DRIVE STUD Price: Call Us |
| 129 |
30884 |
Key, Flywheel Price: Call Us |
| 130 |
31843A |
Bracket, Governor Price: Call Us |
| 131 |
28763 |
Screw (10-32 x 35/64) Price: Call Us |
| 132 |
650548 |
Screw Price: Call Us |
| 133 |
650599 |
Screw Price: Call Us |
| 134 |
31793 |
BALLBEARING Price: Call Us |
| 135 |
31792 |
THRUSTWASHER Price: Call Us |
| 144 |
650542 |
Screw Price: Call Us |
| 145 |
31752 |
Decal Price: Call Us |
| 147 |
27183 |
Washer Fibre Price: Call Us |
| 148 |
650580 |
Nut Price: Call Us |
| 149 |
30747 |
Clip, Shorting Price: Call Us |
| 150 |
16645 |
Lockwasher Price: Call Us |
| 156 |
29826 |
Screw Price: Call Us |
| 157 |
30322 |
Nut-Lock Price: Call Us |
| 158 |
29216 |
Nut-Lock Price: Call Us |
| 161 |
29673 |
Gasket Price: Call Us |
| 162 |
29918 |
Washer-Lock Price: Call Us |
| 163 |
32125 |
Cup-Starter Price: Call Us |
| 164 |
590417 |
Screen, Air Price: Call Us |
| 165 |
29916 |
Clamp-Lever, Governor Price: Call Us |
| 166 |
610689 |
Magneto Price: Call Us |
| 167 |
631063A |
Carburetor Price: Call Us |
| 168 |
590420 |
Starter, Rewind Price: Call Us |
