| Ref | Part Number | Description |
|---|
| 1 |
117-0655-03 |
BRACKET-PUMP Price: $298.43 |
| 1 |
532401042 |
SEAT.XG090.BLK.KB/BLT.NO-LOG This part replaces 532130875. Price: $149.99 |
| 2 |
531152401 |
SERVICE KIT BRACKET SEAT PIVOT This part replaces 532140551. Price: $8.99 |
| 3 |
136-2254 |
PUMP - 364, LS KIT This part replaces 117-0713. Price: $5,279.52 |
| 3 |
871110616 |
BOLT, HEX 3/8-16X1 Price: $3.99 |
| 4 |
819131610 |
WASHER PM Price: $4.99 |
| 5 |
532145006 |
PUSH CLIP Price: $2.99 |
| 6 |
139-3093 |
AGITATION HOSE ASM This part replaces 132-4309. Price: $414.66 |
| 6 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 7 |
110-5331 |
SPRING-COMPRESSION Price: $22.18 |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $5.99 |
| 8 |
117-8040-03 |
PLATE-MOUNT, MOTOR Price: $29.58 |
| 8 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 9 |
117-8045 |
COUPLER Price: $61.81 |
| 9 |
596140201 |
Washers This part replaces 819131614. Price: $2.99 |
| 10 |
532195530 |
PAN.ASM.SEAT.1SLOT This part replaces 532174894. Price: $17.99 |
| 11 |
100-8635 |
FORK Price: $4.91 |
| 13 |
100-6116 |
SCREW-HHF Price: $6.41 |
| 13 |
532121248 |
BUSHING Price: $4.99 |
| 14 |
110-5057 |
CAPSCREW-HHF Price: $2.71 |
| 14 |
872050412 |
BOLT.ROUND.HEAD.SQUARE.NECK Price: $4.99 |
| 15 |
108-3745 |
NUT-HHF, WHIZ Price: $1.15 |
| 15 |
532134300 |
SPACER SPLIT 28X.96 Price: $3.99 |
| 16 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 16 |
532121250 |
SPRING Price: $3.99 |
| 17 |
3241-7 |
SCREW-SQH Price: $3.39 |
| 17 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 532123976. Price: $3.99 |
| 18 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 19 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 21 |
120-0628-03 |
GUARD-SHAFT, PUMP Price: $22.59 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532171852. Price: $2.99 |
| 22 |
117-0706 |
HYD MOTOR ASM Price: $793.55 |
| 22 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 23 |
871110814 |
BOLT.HEX.BLACK Price: $8.99 |
| 24 |
106-1990 |
KEY-WOODRUFF Price: $3.81 |
| 24 |
819171912 |
WASHER Price: $3.99 |
| 25 |
532127018 |
BOLT,SHOULD Price: $4.99 |
| 26 |
810040800 |
LOCKWASHER Price: $5.99 |
| 27 |
322-14 |
SCREW-HH Price: $1.01 |
| 28 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 29 |
3234-29 |
SCREW-HHF Price: $1.84 |
| 32 |
136-0376-03 |
BRACKET-VALVE, AGITATION Price: $33.11 |
| 33 |
107-3073 |
U-BOLT Price: $14.49 |
| 34 |
33113-012 |
SCREW-HH Price: $0.71 |
| 35 |
132-4303-03 |
MOUNT-VALVE, BYPASS Price: $12.29 |
| 36 |
132-4302 |
MOUNT-VALVE Price: $38.41 |
| 37 |
131-0249 |
ON/OFF 2-WAY VALVE KIT Price: $220.85 |
| 38 |
131-0264 |
AGITATION THROTTLING HANDLE KIT Price: $28.04 |
| 39 |
132-4310 |
AGIATION SUPPLY HOSE ASM Price: $133.74 |
| 41 |
127-9829 |
CLAMP/GASKET KIT Price: $40.32 |
| 42 |
127-9815 |
FITTING-CAP Price: $6.53 |
| 45 |
104-8301 |
NUT-HF, NI Price: $1.09 |
