| Ref | Part Number | Description |
|---|
| 1 |
3234-25 |
SCREW-HHF Price: $7.69 |
| 1 |
532439740 |
WHEEL.STEER.HUSQ.SR.498.OVMLD Price: $69.99 |
| 2 |
532413591 |
AXLE.SVC.ASM CAST IRON.TEX This part replaces 532195968. Price: $119.99 |
| 2 |
80-6990 |
WASHER-HARDENED Price: $3.06 |
| 3 |
32128-43 |
NUT-FLANGE Price: $0.94 |
| 4 |
596873601 |
SPINDLE.WELDED.LH.15"TEX.X431 This part replaces 532403087. Price: $14.99 |
| 4 |
94-5033-03 |
BRACKET-SUPPORT, CYLINDER This part replaces 94-5033. Price: $182.59 |
| 5 |
538691201 |
SPINDLE.WLDMT.RH.15INTIRE.X431 This part replaces 532403088. Price: $19.99 |
| 5 |
92-7905 |
SWITCH AND BRACKET ASM Price: $293.34 |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 7 |
3254-9 |
WASHER-LOCK, INTERNAL Price: $0.25 |
| 7 |
532121748 |
WASHER Price: $3.99 |
| 8 |
3249-3 |
SCREW-PRH Price: $0.34 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
283-6 |
PIN-CLEVIS Price: $1.70 |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 10 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 11 |
282-4 |
SHACKLE Price: $32.98 |
| 12 |
61-3830 |
CHAIN Price: $14.52 |
| 13 |
532121749 |
WASHER Price: $2.99 |
| 13 |
94-5010 |
PIN-ACTUATOR, SWITCH Price: $101.45 |
| 14 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 14 |
94-5011 |
SPRING-COMPRESSION Price: $18.13 |
| 15 |
3272-4 |
PIN-COTTER Price: $0.25 |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 16 |
587738904 |
KIT.SRVC.STEERINGSHAFT.2HISHFT This part replaces 587016002. Price: $34.99 |
| 16 |
72-4190 |
PIN-GUIDE, CYLINDER Price: $79.12 |
| 17 |
84-8440 |
BUSHING Price: $49.87 |
| 18 |
321-43 |
CAPSCREW Price: $0.41 |
| 19 |
531169101 |
SERVICE KIT PLATE PLATE.STEER. This part replaces 532194729. Price: $19.99 |
| 19 |
61-2450 |
HUB-LIFT V Price: $106.24 |
| 21 |
340-86 |
FITTING-TEE Price: $35.23 |
| 21 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 586840201. Price: $7.99 |
| 22 |
587738901 |
KIT.SRVC.STEERINGSHAFT.LWRBSHG This part replaces 585029802. Price: $14.99 |
| 22 |
94-5031 |
HYD CYLINDER ASM Price: $830.71 |
| 23 |
283-78 |
PIN-CLEVIS Price: $9.25 |
| 24 |
93-6733-03 |
BRACKET-MOUNT, VALVE This part replaces 93-6733. Price: $15.62 |
| 25 |
93-6718 |
BLOCK-VALVE Price: $2,070.41 |
| 26 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 26 |
532439743 |
INSERT.CAP.WHL.STRG.HUSQ.PREM Price: $8.99 |
| 27 |
596933401 |
Washers This part replaces 819211616. Price: $2.99 |
| 27 |
93-6904 |
SPACER-TUBE, SPLIT Price: $1.07 |
| 28 |
32105-1 |
SCREW-SHH Price: $3.19 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 29 |
3255-17 |
WASHER-LOCK, EXT Price: $0.29 |
| 30 |
3256-14 |
WASHER-FLAT Price: $0.39 |
| 31 |
340-2 |
FITTING-STRAIGHT Price: $11.43 |
| 32 |
93-6935 |
DISCONTINUED Price: Call Us |
| 33 |
340-4 |
FITTING-STRAIGHT Price: $11.58 |
| 34 |
93-6800 |
HOSE-HYD Price: $89.80 |
| 35 |
532194732 |
GEAR.SECTOR.PLATE.DDL. Price: $27.99 |
| 35 |
94-5009 |
HOSE ASM Price: $102.32 |
| 36 |
94-5008 |
HOSE ASM Price: $102.26 |
| 37 |
94-5007 |
DISCONTINUED Price: Call Us |
| 38 |
94-5006 |
HOSE ASM Price: $85.73 |
| 39 |
237-22 |
O-RING Price: $2.43 |
| 40 |
237-79 |
O-RING Price: $5.46 |
| 41 |
237-42 |
O-RING Price: $2.78 |
| 42 |
237-22 |
O-RING Price: $2.43 |
| 43 |
94-3424 |
BRACKET-MOUNT, SWITCH Price: $15.36 |
| 45 |
587016401 |
WASHER.3/8ID.2-3/8OD.12GA.PLTD Price: $2.99 |
| 50 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 53 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 57 |
532407465 |
BRACKET.UPSTOP.TEX Price: $5.99 |
| 58 |
532194747 |
BOLT.SHOULDER.SECTOR.P Price: $7.99 |
| 60 |
583612801 |
NUT.FLANGE.LOCK.5/8-11 This part replaces 873971000. Price: $3.99 |
| 61 |
597047802 |
Links This part replaces 532194740. Price: $11.99 |
| 62 |
597047902 |
Links This part replaces 532194741. Price: $11.99 |
| 63 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 64 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $4.99 |
| 66 |
871020748 |
BOLT HEX FGHD 7/16-14 X 3 SERR Price: $4.99 |
| 67 |
529496302 |
BUSHING, AXLE This part replaces 532194737. Price: $2.99 |
| 68 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 69 |
532199162 |
WASHER.1.5X.505X.118 Price: $4.99 |
| 70 |
585338802 |
BRACKET FRONT DECK SUSPENSION This part replaces 532196197. Price: $14.99 |
| 75 |
587738906 |
KIT.SRVC.STEERINGSHAFT.PINION This part replaces 580683701. Price: $4.99 |
| 76 |
580683601 |
SCREW HEAD SOCKET LRVB Price: $2.99 |
| 122 |
583576601 |
CAP.GEAR.SECTOR.TEX This part replaces 532444962. Price: $4.99 |
