| Ref | Part Number | Description |
|---|
| 0 |
632786A |
CARBURETOR This part replaces 632786. Price: $95.43 |
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532144927. Price: $149.99 |
| 1 |
640035 |
SHAFT & LEV Price: $7.17 |
| 1A |
36288 |
BUSHING Price: $1.22 |
| 2 |
640036 |
SPRING Price: $1.20 |
| 2 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE Price: $3.99 |
| 3 |
596582301 |
Washers This part replaces 819091016. Price: $2.99 |
| 4 |
596029801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040400. Price: $2.99 |
| 5 |
640037 |
WASHER Price: $1.20 |
| 6 |
532050675 |
NUT.HEX..25-20.UNC This part replaces 873220400. Price: $2.99 |
| 6 |
640038 |
SHUTTER Price: $1.42 |
| 7 |
532007697 |
PLASTIC TUBE Price: $6.23 |
| 7 |
650506 |
SCREW Price: $0.87 |
| 8 |
532007603 |
TRAY.BATTERY This part replaces 532124886. Price: $5.99 |
| 9 |
532109596 |
HOSE CLAMP T Price: $3.99 |
| 10 |
532150177 |
BATTERY TIEDOWN KIT This part replaces 532145211. Price: $8.99 |
| 10 |
640044 |
SHAFT & LEV Price: $1.55 |
| 11 |
532150109 |
BATTERY HOLDDOWN FRONT MOUNT Price: $4.99 |
| 12 |
532150177 |
BATTERY TIEDOWN KIT This part replaces 532145769. Price: $8.99 |
| 13 |
640037 |
WASHER Price: $1.20 |
| 14 |
640066 |
SHUTTER Price: $2.60 |
| 15 |
632785 |
SPRING Price: $1.20 |
| 16 |
532176138 |
SWITCH INTERLOOK PUSH-IN This part replaces 532153664. Price: $19.99 |
| 17 |
651025 |
SCREW Price: $1.18 |
| 18 |
630766 |
SPRING Price: $1.25 |
| 19 |
596029801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810090400. Price: $2.99 |
| 20 |
532050675 |
NUT.HEX..25-20.UNC This part replaces 873350400. Price: $2.99 |
| 21 |
532136850 |
HARNESS LIGHT SOCKET Price: $15.99 |
| 22 |
532004152 |
LIGHTBULB Price: $3.99 |
| 24 |
532004799 |
BATTERY CABLE This part replaces 532124780. Price: $8.99 |
| 25 |
532146148 |
CABLE BATTERY 6 GA 22" W/16W Price: $11.99 |
| 25 |
640039B |
FLOAT BOWL This part replaces 640039A. Price: $12.66 |
| 26 |
532108824 |
FUSE HYT Price: $4.99 |
| 27 |
632544A |
FLOAT SHAFT This part replaces 632544. Price: $2.61 |
| 28 |
532145491 |
CABLE GROUND 6 GA 21" 90T BLK Price: $6.99 |
| 28 |
632543 |
FLOAT Price: $6.73 |
| 29 |
532421062 |
SWITCH.SNAPMOUNT.NC This part replaces 532121305. Price: $12.99 |
| 29 |
640047 |
GASKET Price: $2.60 |
| 30 |
532140301 |
SWITCH.IGNITION.4.POSITION Price: $32.99 |
| 30 |
632709 |
INLET NEEDLE Price: $4.91 |
| 31 |
532124211 |
NUT IGNITION Price: $4.99 |
| 32 |
532141226 |
COVER SWITCH KEY Price: $4.99 |
| 32 |
640041 |
SCREW Price: $1.25 |
| 33 |
27110A |
GASKET This part replaces 640042. Price: $1.45 |
| 33 |
532122147 |
KEY.MOLDED.GENERIC Price: $5.99 |
| 36 |
640043 |
NOZZLE Price: $4.95 |
| 37 |
632547 |
O RING Price: $1.49 |
| 37A |
632547 |
O RING Price: $1.49 |
| 38 |
632545 |
SPRING Price: $0.87 |
| 38A |
36918 |
SPRING Price: $1.18 |
| 39 |
640039B |
FLOAT BOWL This part replaces 640048. Price: $12.66 |
| 40 |
532156443 |
IGN HARNESS Price: $86.87 |
| 40 |
640040 |
FUEL JET Price: $1.25 |
| 41 |
596437001 |
Screws This part replaces 871110408. Price: $2.99 |
| 42 |
532154336 |
COVER.TERMINAL.RED This part replaces 532131563. Price: $4.99 |
| 43 |
532146154 |
KIT SOLENOID .95 This part replaces 532145673. Price: $19.99 |
| 44 |
873640400 |
Nut Keps Hex 1/4-20 Unc Price: $2.99 |
| 45 |
532122822 |
AMMETER Price: $17.99 |
| 46 |
532169642 |
KIT.HOURMETER.SNAP-IN This part replaces 532110940. Price: $109.99 |
| 47 |
817011008 |
Screw 10-24 x 1/2 Black Price: $2.38 |
| 50 |
582107601 |
SWITCH.PTO.8TERMINAL.STD.BLK This part replaces 532154959. Price: $24.99 |
| 51 |
532140405 |
FRAME RETAINING RING Price: $3.99 |
| 55 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
