| Ref | Part Number | Description |
|---|
| 1 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 1 |
717-3070 |
SHAFT-HYDRO PINION Not Available Price: |
| 1 |
94-9959 |
BARREL ASM Price: $290.19 |
| 2 |
32152-10 |
LOCKNUT Price: $0.81 |
| 2 |
532440452 |
SHIELD.PNT.SIDE.OUTER.LH.ORANG This part replaces 532162952. Price: $17.99 |
| 2 |
741-0371 |
BEARING ASSY, PINION SHAFT REAR CONE Not Available Price: |
| 3 |
532008393 |
STAKE PIN TI Price: $19.99 |
| 3 |
741-0370 |
ROLLER BEARING CUP Not Available Price: |
| 3 |
94-8142 |
HYD CYLINDER ASM This part replaces 94-9961. Price: $802.19 |
| 4 |
717-3123 |
SHIM Not Available Price: |
| 4 |
812000035 |
RING, KLIP Price: $3.99 |
| 5 |
595901601 |
GSPW Bolts This part replaces 532180847. Price: $2.99 |
| 5 |
710-0844 |
HEX SCREW 7/16-14 x 1.75 LG Not Available Price: |
| 6 |
532008394 |
SPRING TI Price: $7.99 |
| 6 |
936-0141 |
Spr. Wash. 7/16" I.D. This part replaces 736-0141. Price: $6.01 |
| 7 |
532008392 |
BRACKET.LATCH.STAKE.3.20.BLACK Price: $4.99 |
| 7 |
717-3204 |
HOUSING ASSY, REAR Not Available Price: |
| 8 |
532109230 |
SPRING CRT Price: $4.99 |
| 8 |
727-3025 |
Plug, Breather Price: Call Us |
| 9 |
532442662 |
SHIELD.PNT.TINE.CRT17.ORANGE This part replaces 532125014. Price: $44.99 |
| 9 |
727-3028 |
DIP STICK TUBE Not Available Price: |
| 9 |
94-9963 |
RING-RETAINING Price: $40.71 |
| 10 |
595901501 |
Bolts This part replaces 872140508. Price: $3.99 |
| 10 |
903-0911P |
DIPSTICK Not Available This part replaces 703-0911. Price: |
| 10 |
94-8142 |
HYD CYLINDER ASM This part replaces 94-9962. Price: $802.19 |
| 11 |
596436301 |
Nuts This part replaces 873220500. Price: $2.99 |
| 11 |
717-3097 |
SHIM, BEARING RETAINER, .004 Not Available Price: |
| 12 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 12 |
717-3098 |
SHIM, BEARING RETAINER, .007 Not Available Price: |
| 12 |
94-8142 |
HYD CYLINDER ASM This part replaces 94-9960. Price: $802.19 |
| 13 |
717-3099 |
Shim, Bearing Retainer, .0149 Price: $32.65 |
| 13 |
872110510 |
BOLT.CARRIAGE.5/16-18 Price: $4.99 |
| 14 |
584459301 |
BRACKET.TINE.SHIELD.BLACK This part replaces 532124343. Price: $32.99 |
| 14 |
717-3100 |
SHIM .028 Not Available Price: |
| 15 |
532440450 |
SHIELD.SIDE OUTER.RH.ORANGE This part replaces 532162953. Price: $17.99 |
| 15 |
741-0400 |
ROLLER CUP Not Available Price: |
| 16 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873900400. Price: $3.99 |
| 16 |
717-3203 |
RETAINER Not Available Price: |
| 17 |
716-0138 |
RETAINING RING Not Available Price: |
| 18 |
717-3126 |
GEAR-REDUCTION Not Available Price: |
| 18 |
872040410 |
BOLT Price: $3.99 |
| 19 |
532102701 |
GRIP CRT Price: $9.99 |
| 19 |
715-0146 |
DOWEL PIN 3/8 x 5/8 Not Available Price: |
| 20 |
717-3202 |
HOUSING ASSY, ADAPTER W/CUP Not Available Price: |
| 20 |
873220600 |
NUT.HEX.3/8-16UNC Price: $4.99 |
| 21 |
531154801 |
SERVICE KIT STAKE STAKE.DEPTH. This part replaces 532102156. Price: $8.99 |
| 22 |
736-0226 |
Washer, .438 X .875 X .064 Price: $3.64 |
| 22 |
874930632 |
BOLT.375-16 Price: $5.99 |
| 23 |
532004440 |
HINGE CRT Price: $3.99 |
| 23 |
710-0850 |
HEX SCREW 7/16-14X2.5 Not Available Price: |
| 24 |
596133401 |
Bolts This part replaces 872140404. Price: $1.99 |
| 24 |
741-04548 |
Cup Bearing This part replaces 741-0372. Price: $7.72 |
| 25 |
532006712 |
VINYL CAP This part replaces 532124717. Price: $3.99 |
| 25 |
741-04549 |
Cone Bearing This part replaces 741-0373. Price: $17.28 |
| 26 |
532109227 |
PAD IDLER TI Price: $3.99 |
| 26 |
717-3127 |
RETAINER RING Not Available Price: |
| 27 |
532440448 |
SHIELD.LEVELING.17".ORANGE This part replaces 532125016. Price: $69.99 |
| 28 |
532120588 |
PIN.HINGE.TILLER Price: $6.99 |
| 29 |
585414301 |
KIT.TILLER.SIDE.SHIELD.BLACK This part replaces 532125013. Price: $37.99 |
| 32 |
532050675 |
NUT.HEX..25-20.UNC This part replaces 873220400. Price: $2.99 |
