| Ref | Part Number | Description |
|---|
| 1 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 1 |
532123760 |
MOWER HOUSING This part replaces 532121664. Price: $302.55 |
| 2 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 2 |
532121811 |
CVR DRIVE DECK Price: $74.99 |
| 3 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 4 |
112-0169 |
SEATBELT ASM-SERVICE This part replaces 21-4191. Price: $283.31 |
| 4 |
532007631 |
RUNNER LH This part replaces 532125074. Price: $14.99 |
| 5 |
104-4620 |
SEAT This part replaces 92-1180. Price: $273.15 |
| 5 |
596039401 |
BOLT ROUND HEAD SQUARE NECK BO This part replaces 872110505. Price: $2.99 |
| 6 |
323-4 |
SCREW-HH Price: $1.02 |
| 6 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 7 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 7 |
596436301 |
Nuts This part replaces 873220500. Price: $2.99 |
| 8 |
3212-4 |
SCREW-HH Price: $2.73 |
| 8 |
532136320 |
RUNNER RH This part replaces 532120449. Price: $8.99 |
| 9 |
3296-54 |
NUT-LOCK Price: $3.59 |
| 9 |
595901601 |
GSPW Bolts This part replaces 872140506. Price: $2.99 |
| 10 |
532124949 |
LOCKNUT Price: $3.99 |
| 10 |
75-4370-03 |
BRACKET-SEAT This part replaces 75-4370. Price: $20.93 |
| 11 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 819111116. Price: $2.99 |
| 11 |
92-8753 |
DISCONTINUED Price: Call Us |
| 12 |
3250-29 |
SCREW-PPH Price: $0.25 |
| 12 |
532136819 |
MANDREL ASM SEC 44/50 Price: $89.99 |
| 13 |
532121657 |
JACKSHAFT.PRIMARY This part replaces 532121617. Price: $89.99 |
| 13 |
92-8001 |
SENSOR-SWITCH, REED Price: $86.02 |
| 14 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 14 |
534200501 |
BOLT HEX PATCH 3/8-16X3/4 This part replaces 817490612. Price: $1.99 |
| 15 |
532121798 |
BLADE.50".STANDARD.LIFT Price: $19.99 |
| 15 |
75-4360-03 |
BRACKET-SUSPENSION, SEAT This part replaces 75-4360. Price: $17.81 |
| 16 |
74-0720 |
TUBE-MANUAL Price: $22.99 |
| 16 |
874610624 |
BOLT.3/8-24X1-1/2 Price: $4.99 |
| 17 |
2412-133 |
CLAMP-R Price: $3.19 |
| 17 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 18 |
322-3 |
SCREW-HH Price: $0.79 |
| 18 |
596134901 |
GSPH This part replaces 819132012. Price: $2.99 |
| 19 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 19 |
532674213 |
ARM ASSY This part replaces 532124685. Price: $11.99 |
| 20 |
532674308 |
BEARING This part replaces 532124702. Price: $13.60 |
| 20 |
75-3400 |
SHAFT-PIVOT, SEAT Price: $21.81 |
| 21 |
532674308 |
BEARING This part replaces 532007835. Price: $13.60 |
| 22 |
872110522 |
Bolt, Carriage 5/16-18 x 2-3/4 Price: $3.99 |
| 23 |
819111816 |
Washer 11/32 x 1-1/8 x 16 Gauge Price: $2.42 |
| 24 |
532102403 |
IDLER-FLAT T Price: $34.99 |
| 25 |
874930624 |
Bolt, Hex Head 3/8-16 UNC x 1-1/2 This part replaces 874760624. Price: $6.99 |
| 26 |
873220600 |
NUT.HEX.3/8-16UNC Price: $4.99 |
| 27 |
532104361 |
SPRING T Price: $3.65 |
| 28 |
595305701 |
Screws This part replaces 874780520. Price: $3.99 |
| 29 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 819111216. Price: $2.99 |
| 30 |
532008438 |
SPACER SPLIT LT Price: $3.99 |
| 32 |
532105448 |
GUAGE WHL BRKT GT Price: $10.51 |
| 33 |
532105449 |
GAUGE WHL BRKT GT Price: $10.51 |
| 34 |
872240606 |
Bolt, Carriage 3/8-16 x 3/4 Price: $2.99 |
| 35 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 36 |
532105453 |
GUAGE WHL BAR GT Price: $14.99 |
| 37 |
532139031 |
PIN.CLEVIS This part replaces 532005565. Price: $4.99 |
| 38 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
| 39 |
596434402 |
Bolts This part replaces 532134249. Price: $3.99 |
| 40 |
532105455 |
WHEEL.GAUGE.BLK.4.93 Price: $14.99 |
| 41 |
532105433 |
SUSP BRKT GT Price: $5.99 |
| 42 |
532110237 |
SPACER GT Price: $3.99 |
| 43 |
532105434 |
SUSP BRACE GT Price: $7.99 |
| 44 |
532109778 |
PLATE Price: $29.08 |
| 45 |
532109771 |
BRACKET NLA Price: $16.99 |
| 46 |
596436301 |
Nuts This part replaces 873350500. Price: $2.99 |
| 47 |
532003146 |
SPRING RETAINER This part replaces 532124660. Price: $2.99 |
| 48 |
532003703 |
V-BELT M Price: $54.99 |
| 49 |
596433401 |
Nuts This part replaces 873680800. Price: $2.99 |
| 50 |
874760622 |
Bolt, Hex 3/8-16 x 1-3/8 Price: $3.99 |
| 51 |
532105435 |
RELEASE PIN GT Price: $10.21 |
| 52 |
532003720 |
SPRING.COMPRESSION Price: $4.99 |
| 53 |
812000039 |
KLIP RING Price: $4.99 |
| 54 |
596040101 |
Washers This part replaces 819171612. Price: $2.99 |
| 55 |
532105440 |
CLEVIS PIN GT Price: $4.62 |
| 56 |
532105458 |
BRACKET T Price: $3.74 |
| 57 |
532109773 |
BRACKET T Price: $18.98 |
| 58 |
532110997 |
BRACKET T Price: $15.76 |
| 59 |
532120000 |
BRACKET T Price: $4.99 |
| 60 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 61 |
532109776 |
PIVOT PIN T Price: $8.99 |
| 62 |
819111016 |
Washer 11/32 x 5/8 x 16 Gauge Price: $5.99 |
| 63 |
532110509 |
SHIELD.DEFLECTOR.MOWER.50"BLK. Price: $27.99 |
| 64 |
532123713 |
SPRING TORSION This part replaces 532106734. Price: $6.99 |
| 65 |
531155201 |
SERVICE KIT BRACKET BRACKET This part replaces 532137607. Price: $2.99 |
| 66 |
532106735 |
ROD-HINGE T Price: $8.99 |
| 68 |
532110452 |
NUT PUSH M Price: $2.99 |
| 71 |
873220600 |
NUT.HEX.3/8-16UNC Price: $4.99 |
| 73 |
819171512 |
Washer 17/32 x 15/16 x 12 Gauge Price: $3.99 |
| 74 |
872240608 |
BOLT Price: $3.99 |
| 76 |
532110884 |
BELT-V.93.5.MOWER Price: $39.99 |
| 77 |
596040101 |
Washers This part replaces 819151610. Price: $2.99 |
| 79 |
596238701 |
Washers This part replaces 810030600. Price: $3.99 |
| 80 |
532109729 |
ROLLER T Price: $6.99 |
| 83 |
596029501 |
Pins This part replaces 876020412. Price: $2.99 |
| 84 |
596040101 |
Washers This part replaces 819151616. Price: $2.99 |
| 85 |
532120135 |
SPACER T Price: $2.42 |
| 93 |
532121352 |
BELT RETIANER Price: $3.00 |
