| Ref | Part Number | Description |
|---|
| 1 |
32-4120 |
DISCONTINUED Price: Call Us |
| 1 |
462856 |
Deck Latch Weldment w/Grip Price: Call Us |
| 2 |
302-5 |
FITTING-GREASE This part replaces 21-6010. Price: $0.59 |
| 2 |
43668 |
Bushing, .502 O.D. Price: Call Us |
| 3 |
30-3970 |
DISCONTINUED Price: Call Us |
| 3 |
484191 |
Spring, Torsion - Lever Return Price: Call Us |
| 4 |
04021-07 |
HEX LOCKNUT, ELASTIC STOP, 1/2-13 Price: Call Us |
| 4 |
30-1460 |
DISCONTINUED Price: Call Us |
| 5 |
04040-13 |
Flat Washer, 1/2 (.562 x 1.375 x .109) Price: Call Us |
| 5 |
30-4770 |
DISCONTINUED Price: Call Us |
| 6 |
33-3090 |
BUSHING Price: $7.70 |
| 6 |
428108 |
Pivot, Deck Link Price: Call Us |
| 7 |
30-7720 |
DISCONTINUED Price: Call Us |
| 7 |
431018 |
Pivot, Deck Link Price: Call Us |
| 8 |
04001-153 |
Bolt, Hex Head 1/2-13 x 2-1/4" Price: Call Us |
| 8 |
325-11 |
SCREW-HH Price: $1.93 |
| 9 |
04001-20 |
Bolt, Hex Head 3/8-16 x 1-1/2" B&S 32BV Price: Call Us |
| 9 |
32128-23 |
NUT-HF Price: $1.51 |
| 10 |
30-7550 |
DISCONTINUED Price: Call Us |
| 10 |
48540 |
Footplate Price: Call Us |
| 11 |
04019-04 |
NUT, 3/8-16 SERRATED FLANGE HEX HEAD Price: Call Us |
| 11 |
32-3640 |
DISCONTINUED Price: Call Us |
| 12 |
3296-19 |
NUT-HEX This part replaces 32146-11. Price: $0.65 |
| 12 |
424504 |
Foot Pedal, Height Adjustment Price: Call Us |
| 13 |
04001-136 |
Bolt, Hex Head 3/8-16 x 1-1/2" Grade 8 Black Price: Call Us |
| 13 |
30-7560 |
DISCONTINUED Price: Call Us |
| 14 |
04021-05 |
Bolt, Hex Head 3/8-16 x 1" Ser. Flg. Price: Call Us |
| 14 |
32-5770 |
DISCONTINUED Price: Call Us |
| 15 |
32128-20 |
NUT-HF Price: $0.99 |
| 15 |
486474 |
Spring, Ext. Deck Lift Price: Call Us |
| 16 |
04030-07 |
Lockwasher, 5/8" Spring Price: Call Us |
| 16 |
322-3 |
SCREW-HH Price: $0.79 |
| 17 |
04108-04 |
Capscrew, 5/8-11 x 1-1/2" Price: Call Us |
| 17 |
31-6540 |
DISCONTINUED Price: Call Us |
| 18 |
31-4540 |
DISCONTINUED Price: Call Us |
| 18 |
43508 |
Spacer, Radiator Price: Call Us |
| 19 |
04001-72 |
Hex Head Bolt, 1/2-13 x 2" Price: Call Us |
| 19 |
32-3960 |
DISCONTINUED Price: Call Us |
| 20 |
30-0980 |
DISCONTINUED Price: Call Us |
| 20 |
482534 |
Linkage Assembly, Deck Lift Price: Call Us |
| 21 |
04050-18 |
Retaining Ring, 1/2" Ext. "E" Price: Call Us |
| 21 |
32-3790 |
DISCONTINUED Price: Call Us |
| 22 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 22 |
43487 |
Pin, Deck Lift Price: Call Us |
| 23 |
32104-76 |
SCREW-HWHTF Price: $2.29 |
| 23 |
462872 |
Slide, Height Adjust Price: Call Us |
| 24 |
32-3750 |
DISCONTINUED Price: Call Us |
| 24 |
453099 |
Weldment, Lower Cutting Height Price: Call Us |
| 25 |
31-1460 |
DISCONTINUED Price: Call Us |
| 25 |
428237 |
Adjustment Bracket, Cutting Height Upper Price: Call Us |
| 26 |
04006-02 |
Bolt, Hex Wshr Head 5/16-18 x 1-1/4" Price: Call Us |
| 26 |
3217-5 |
NUT-HEX Price: $0.25 |
| 27 |
04001-46 |
Bolt, Hex Head 3/8-16 x 2-1/4" - 61" Price: Call Us |
| 27 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 28 |
32-3910 |
DISCONTINUED Price: Call Us |
| 28 |
483345 |
Lanyard, Deck Height Pin Assembly Price: Call Us |
| 29 |
3256-2 |
WASHER-FLAT Price: $0.39 |
| 29 |
452744 |
LIFT BELLCRANK WLMT, LH REAR Price: Call Us |
| 30 |
3229-1 |
BOLT-CARR Price: $3.39 |
| 31 |
32-3890 |
DISCONTINUED Price: Call Us |
| 32 |
32128-14 |
NUT-HF Price: $0.41 |
| 33 |
32-3920 |
DISCONTINUED Price: Call Us |
| 34 |
32-3700 |
DISCONTINUED Price: Call Us |
| 35 |
32-3880 |
DISCONTINUED Price: Call Us |
| 36 |
30-7860 |
DISCONTINUED Price: Call Us |
| 37 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 38 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 39 |
3290-250 |
PIN-COTTER Price: $5.59 |
| 40 |
32-3710 |
DISCONTINUED Price: Call Us |
| 41 |
32103-2 |
NUT-WING Price: $0.68 |
| 42 |
325-18 |
SCREW-HH Price: $3.19 |
| 43 |
30-1670 |
DISCONTINUED Price: Call Us |
| 44 |
32-7810 |
DISCONTINUED Price: Call Us |
| 45 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 46 |
30-9880 |
DISCONTINUED Price: Call Us |
| 47 |
32128-28 |
NUT-HHF Price: $0.34 |
| 452745 |
LIFT |
BELLCRANK WLMT, RH REAR Price: Call Us 452745 |
| 481477 |
Mounting |
Bracket, Fuel Tank Price: Call Us 481477 |
| 485570 |
Slide, |
Height Adjustment Price: Call Us 485570 |
