| Ref | Part Number | Description |
|---|
| 1 |
591117901 |
SERVICE KIT SVC.WELDMENT.42F This part replaces 587939001. Price: $899.99 |
| 2 |
539131898 |
MANDREL ASM, CAST IRON Price: $69.99 |
| 3 |
532187690 |
WASHER.SPACER.MANDREL Price: $3.99 |
| 5 |
596134801 |
Nuts Price: $1.00 |
| 7 |
532193003 |
BOLT.WASHER.ASM.7/16-2 Price: $6.99 |
| 8 |
532176066 |
NOSE ROLLER 48" Price: $11.99 |
| 9 |
594092501 |
Rods Price: $5.99 |
| 10 |
127-0495 |
STARTER ASM Price: $920.85 |
| 10 |
532194208 |
PIN.COTTER.5/16.BOW TI Price: $2.99 |
| 12 |
587354701 |
SPRING.42.FCS.DEFLECTOR Price: $5.99 |
| 13 |
595297001 |
Rods Price: $4.99 |
| 14 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 17 |
596135701 |
GSPW Nuts Price: $2.99 |
| 20 |
100-2181 |
STARTER YOKE ASM Price: $102.34 |
| 24 |
594944401 |
NUT HEXAGON FLANGE 5/16-18 ST This part replaces 539112899. Price: $5.99 |
| 26 |
532178515 |
WASHER Price: $5.99 |
| 27 |
532196104 |
PULLEY.IDLER.MWR.STATI.LH Price: $37.99 |
| 28 |
586874002 |
ARM.42"FCS.CLUTCHING.X431 Price: $17.99 |
| 29 |
596337801 |
Bolts Price: $4.99 |
| 30 |
100-2222 |
HOLDER ASM Price: $23.90 |
| 30 |
532196106 |
PULLEY.IDLER.2006 Price: $34.99 |
| 34 |
596322601 |
Nuts Price: $2.99 |
| 35 |
127-0415 |
SPRING-BRUSH Price: $4.65 |
| 40 |
100-2182 |
ARMATURE ASM Price: $204.81 |
| 40 |
589527301 |
WHEEL.GAUGE.RALLY Price: $8.99 |
| 41 |
596434404 |
Bolts Price: $4.99 |
| 42 |
536050602 |
LINK FIXED MOWER DRAWBAR BLACK This part replaces 587140502. Price: $5.99 |
| 43 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 44 |
532196539 |
BOLT.SHOULDER Price: $5.99 |
| 45 |
98-9412 |
BEARING-BALL Price: $14.99 |
| 46 |
587270101 |
BELT.42.FCS.TRACTOR.DECK.DRIVE Price: $44.99 |
| 47 |
595901601 |
GSPW Bolts Price: $2.99 |
| 47 |
98-9411 |
BEARING-BALL Price: $14.99 |
| 50 |
100-2185 |
STARTER CLUTCH ASM Price: $148.04 |
| 51 |
532199791 |
PULLEY MANDREL 5.0" Price: $22.99 |
| 52 |
588438301 |
SCREW.7/16-14 X 2.125.WASHER Price: $5.99 |
| 53 |
532415598 |
PORT.WASHOUT Price: $6.99 |
| 55 |
596240801 |
GSPW Bolts Price: $3.99 |
| 56 |
587358401 |
SPRING.EXTN.42.FCS.TR.DECK.DRV Price: $6.99 |
| 57 |
596039201 |
GSPW Hardware Price: $2.99 |
| 60 |
127-0490 |
STARTER HOUSING ASM Price: $198.30 |
| 61 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 Price: $3.99 |
| 65 |
532110452 |
NUT PUSH M Price: $2.99 |
| 66 |
587305701 |
DEFLECTOR.ASM.42.FCS.ORANGE Price: $69.99 |
| 67 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 68 |
532198468 |
KEEPER.BELT.IDLER.54"T Price: $7.99 |
| 69 |
586936805 |
COVER.42".MANDREL.FCS.PNT.498 Price: $7.99 |
| 70 |
100-2183 |
BEARING Price: $2.78 |
| 75 |
582683203 |
BUMPER.42CC.TRIM.SIDE.ASSY.HUS Price: $9.99 |
| 78 |
501808302 |
BRACKET.PNT.GA-WHEEL.FCS.42.RH Price: $19.99 |
| 80 |
127-0449 |
FRAME ASM Price: $122.82 |
| 81 |
582360501 |
BUSHING.NOSE.ROLLER Price: $3.99 |
| 82 |
596134901 |
GSPH Price: $2.99 |
| 84 |
532170165 |
SHOULDER BOLT 5/16-18TT Price: $3.99 |
| 90 |
100-2213 |
COVER Price: $5.38 |
| 100 |
100-2223 |
BEARING ASM Price: $19.21 |
| 105 |
127-0414 |
BEARING Price: $4.84 |
| 110 |
100-2187 |
STARTER SHAFT ASM Price: $40.93 |
| 120 |
100-2220 |
GEAR Price: $24.46 |
| 130 |
100-2221 |
GEAR Price: $66.83 |
| 135 |
98-7750 |
SPRING-BRUSH Price: $2.38 |
| 140 |
100-2218 |
LEVER Price: $7.56 |
| 150 |
127-0448 |
SWITCH-MAGNETIC Price: $250.65 |
| 160 |
100-2219 |
RING-SNAP Price: $9.60 |
| 165 |
112-2833 |
GEAR-PINION Price: $123.77 |
| 170 |
100-2212 |
RING-SNAP Price: $5.84 |
| 180 |
100-2216 |
COLLAR Price: $14.55 |
| 190 |
100-2224 |
WASHER-PLAIN Price: $5.80 |
| 200 |
100-2225 |
WASHER-PLAIN Price: $2.44 |
| 210 |
100-2226 |
WASHER-PLAIN Price: $2.44 |
| 220 |
100-2227 |
PLATE Price: $14.26 |
| 230 |
99-8371 |
NUT-HEX Price: $3.75 |
| 240 |
100-1813 |
NUT Price: $2.05 |
| 250 |
100-2210 |
BOLT-THROUGH Price: $3.71 |
