| Ref | Part Number | Description |
|---|
| 1 |
59-5230 |
Chute Assembly (Incl. Ref. #2 3) Price: $468.56 |
| 1 |
601000398 |
HOOD,EURO H-19 LT MOLD/OR NLA Price: $230.56 |
| 2 |
3290-409 |
RIVET Price: $0.34 |
| 2 |
601000099 |
BOLT, .500X .375 HHSH 5/1 Price: $11.99 |
| 3 |
56-4630 |
Deflector Price: Call Us |
| 3 |
601000059 |
NUT, 5/16-18 REGHEXCTRLK Price: $5.99 |
| 4 |
601001903 |
HOOD KIT This part replaces 601000304. Price: $283.99 |
| 4 |
82-5510 |
DECAL-WARNING This part replaces 43-1110. Price: $7.09 |
| 5 |
56-4780-03 |
IMPELLER ASM This part replaces 56-4780. Price: $926.99 |
| 5 |
601000465 |
ASSY FOOT PAD LH ERO W/AD Price: $31.73 |
| 6 |
3234-14 |
SCREW-HHF Price: $0.61 |
| 6 |
601000712 |
PF SHIELD-GAS TANK EURO BLACK Price: $30.99 |
| 7 |
59-5070-03 |
MTG PLATE ASM This part replaces 59-5070. Price: $328.99 |
| 7 |
601000114 |
SCREW, .25X.75X.75HHWAPLA Price: $3.99 |
| 8 |
601000271 |
FUEL SENSOR Price: $58.99 |
| 8 |
601000272 |
ASSY GAS TANK 1.5 GAL W/S Price: $129.99 |
| 8 |
74-0910-03 |
BRACKET This part replaces 59-4980. Price: $63.99 |
| 9 |
59-5050 |
LH BRACKET ASM, WELDED Price: $122.99 |
| 9 |
601000049 |
CAP, FUEL -2.5 THROAT Price: $22.21 |
| 10 |
59-5140-03 |
BLOWER MT ASM This part replaces 59-5140. Price: $186.99 |
| 10 |
601000814 |
Bracket, Hood L. H. Price: Call Us |
| 11 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 11 |
601000597 |
SCREW, 5/16-18X.75WDFLLK Price: $1.99 |
| 12 |
601000815 |
Bracket, Hood R. H. Price: Call Us |
| 12 |
62-6520 |
KNOB Price: $7.79 |
| 13 |
3257-40 |
KEY Price: $7.99 |
| 13 |
601000400 |
PF AXLE,ASSY FRONT WELD This part replaces 601000816. Price: $92.99 |
| 14 |
53-4530-03 |
GEAR BOX ASM This part replaces 53-4530. Price: $1,650.99 |
| 14 |
601000073 |
SCREW, 5/16-18X .75 HHC This part replaces 601000006. Price: $2.99 |
| 15 |
59-5150-01 |
GEARBOX COVER This part replaces 59-5150. Price: $41.91 |
| 15 |
601000651 |
GREASE ZERK FITTING Price: $2.99 |
| 16 |
3255-17 |
WASHER-LOCK, EXT Price: $0.29 |
| 16 |
601000147 |
BEARING SPINDLE FR W/HOLE Price: $7.23 |
| 17 |
3290-134 |
SCREW Price: $0.27 |
| 17 |
601000525 |
RING, RETEX .57X.05TRU513 Price: $1.99 |
| 18 |
323-7 |
SCREW-HH Price: $0.65 |
| 18 |
601002407 |
NUT 3/8-16 This part replaces 601000060. Price: $3.99 |
| 19 |
601000817 |
SPINDLE RH Price: $7.99 |
| 19 |
74-0910-03 |
BRACKET This part replaces 59-5000. Price: $63.99 |
| 20 |
32152-1 |
NUT-LOCK, CONE Price: $1.49 |
| 20 |
601000015 |
WASHER, REGSPTLK.393X.68X Price: $1.66 |
| 21 |
3218-3 |
NUT-JAM Price: $0.25 |
| 21 |
601000010 |
NUT, 3/8-24 REGHEX Price: $1.66 |
| 22 |
59-5090 |
RH BRACKET ASM, WELDED Price: $129.99 |
| 22 |
601000506 |
ARM This part replaces 601000148. Price: $6.77 |
| 23 |
322-3 |
SCREW-HH Price: $0.79 |
| 23 |
601000670 |
WASHER, FLAT .391X1.0OX. Price: $2.53 |
| 24 |
44-5460-03 |
LH PLT BRKT This part replaces 44-5460. Price: $16.99 |
| 24 |
601000119 |
TIE ROD .625DIA GRND ENGA Price: $55.99 |
| 25 |
3230-1 |
BOLT-CARR Price: $1.49 |
| 25 |
601000818 |
SPINDLE LH Price: $10.99 |
| 26 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 26 |
601000077 |
SCREW Price: $4.40 |
| 27 |
3296-44 |
NUT-LOCK, NI Price: $2.46 |
| 27 |
601000708 |
PF BRACKET FRONT AXLE SUPT Price: $26.99 |
| 28 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 28 |
601000037 |
SCREW, 3/8-16X3.00 HHC Price: $1.99 |
| 29 |
601002313 |
This part replaces 601000098. Price: $2.94 |
| 29 |
63-9710 |
SPACER-BEARING Price: $10.24 |
| 30 |
321-3 |
SCREW-HH Price: $0.28 |
| 30 |
601000867 |
NUT HX WD FL LK 5/16-18 THD This part replaces 601000595. Price: $1.99 |
| 31 |
13-0269 |
BLOWER HOUSING ASM Price: $579.99 |
| 31 |
601000645 |
WASHER, FLAT .755X1.31X. Price: $1.99 |
| 32 |
37-6730 |
CUP-BEARING Price: $15.84 |
| 32 |
601000096 |
VALVE STEM Price: $4.99 |
| 32 |
601000458 |
BEARING, FL1.38ODX.753ID Price: $4.99 |
| 32 |
601000819 |
WHEEL W/BEARING Price: Call Us |
| 33 |
38-7820 |
BEARING-BALL Price: $13.99 |
| 33 |
601000181 |
LINK, ASSY .625DIA DRAG L Price: $69.99 |
| 34 |
601000048 |
NUT, 3/8-24 REGHEXJAM Price: $5.99 |
| 34 |
63-9700-03 |
PLATE-COVER This part replaces 63-9700. Price: $18.43 |
| 35 |
43-0940 |
SPACER Price: $1.25 |
| 36 |
3235-22 |
SCREW-HH, LOCK Price: $2.59 |
| 36 |
601000294 |
CLIP,HUBCAP TINN #C25467- Price: $1.58 |
| 37 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 37 |
601000464 |
ASSY FOOT PAD RH ERO W/AD Price: $31.99 |
| 38 |
43-0960-03 |
BRACKET-CHUTE This part replaces 43-0960. Price: $18.26 |
| 38 |
601000700 |
PF DASH SHORT LOWER LT GR Price: $100.99 |
| 39 |
601000544 |
SCREW, 5/16-18X .37 WAHHT Price: $1.99 |
| 40 |
601001445 |
SCREW This part replaces 601000668. Price: $4.99 |
| 41 |
601000247 |
COVER,SECTOR BOLT PLAS GR Price: $5.47 |
| 42 |
601000192 |
BUSHING STR SHFT UPPER Price: $2.13 |
| 43 |
601000759 |
DASH UPPER This part replaces 601000820. Price: $39.99 |
| 44 |
601000190 |
WHEEL,STEER 14"LONG 4WS L Price: $61.99 |
| 45 |
601000548 |
PIN, SPRING.250DIAX2.00LG Price: $6.99 |
| 46 |
601000274 |
SCREW Price: $3.99 |
| 47 |
601000024 |
SCREW, 1/4-20X .63 HHC Price: $1.99 |
| 48 |
601000018 |
WASHER, FLAT .281X .63X. Price: $1.99 |
| 49 |
601002318 |
RP NUT This part replaces 601000062. Price: $9.99 |
| 50 |
601000149 |
SHAFT, STEERING EURO LT S Price: $32.99 |
| 51 |
601000164 |
PIN DOWEL STR ERO LT Price: $7.99 |
| 52 |
601000151 |
PINION STEERING Price: $22.99 |
| 53 |
601000163 |
BEARING FLANGE 0.5 BORE Price: $14.33 |
| 54 |
601000821 |
Screw, 5/16-24x .75 Sq. Price: Call Us |
| 55 |
601000109 |
WASHER, FLAT .504X .75X. Price: $1.66 |
| 56 |
601000089 |
RING, RET E .39X.04TRU513 Price: $0.51 |
| 57 |
601000623 |
BALL JOINT 3/8 THD SHORT Price: $15.07 |
| 58 |
601000406 |
FASTENER, RATCHET GRE Price: $5.99 |
| 59 |
601000307 |
PLUG,FRONT AXLE 1.938DIAX Price: $2.99 |
| 60 |
601000879 |
BUMPER/HOOD This part replaces 601000822. Price: $5.06 |
| 61 |
601000739 |
EDGING WIDE BLACK-BULK LENGTH This part replaces 601000556. Price: $13.99 |
| 62 |
601000302 |
GRILL, G-16 LT MOLD/GREY Price: $110.99 |
| 63 |
601000122 |
GUIDE, BELT, RIDER Price: $13.14 |
| 64 |
601000417 |
SCREW, #4-24X .50 PHPNHIL Price: $1.99 |
| 65 |
601000303 |
CLIP, TINNERMAN VER II HO Price: $4.98 |
| 66 |
601000519 |
SCREW, 5/16-18X .50 WAHHT Price: $1.99 |
| 67 |
601000113 |
SCREW, #10 X .50 HHTAPPS Price: $1.99 |
| 68 |
601000823 |
NUT 5/16-24 HXWDFLLK Price: $3.99 |
| 69 |
601000397 |
DECAL REFLECTOR VERII HOO Price: $4.99 |
| 70 |
601000591 |
SCREW, 5/16-18X.75 HXWDFL Price: $1.12 |
| 71 |
601000057 |
WASHER, REGINTLK.320X.61X Price: $1.99 |
