| Ref | Part Number | Description |
|---|
| 1 |
38-9370 |
RH CASTOR ARM ASM Price: $946.82 |
| 1 |
530015880 |
Screw Price: $1.99 |
| 2 |
3241-7 |
SCREW-SQH This part replaces 324-12. Price: $3.39 |
| 2 |
530058982 |
Bolt-Muffler Price: $1.99 |
| 3 |
3256-5 |
WASHER-FLAT Price: $0.27 |
| 4 |
26-1890 |
DISCONTINUED Price: Call Us |
| 4 |
530015953 |
Screw-Cylinder Price: $1.99 |
| 5 |
3217-7 |
NUT-HEX Price: $0.28 |
| 5 |
952030249 |
Spark Plug (RCJ 6Y) Price: $3.99 |
| 6 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 6 |
530012541 |
Cylinder Price: $11.99 |
| 7 |
39-3330-01 |
PLATE-CLAMP, CASTOR ARM This part replaces 39-3330. Price: $36.10 |
| 7 |
530071750 |
Seal-Cylinder (kit) Price: $8.99 |
| 8 |
325-13 |
SCREW-HH Price: $3.57 |
| 8 |
545154001 |
RING PISTON This part replaces 530055120. Price: $1.99 |
| 9 |
39-3340-01 |
BRACKET-ARM CLAMP This part replaces 39-3340. Price: $101.90 |
| 9 |
530015162 |
Retainer-Piston Pin Price: $1.99 |
| 10 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 11 |
545145802 |
ASSY CRANKSHAFT This part replaces 530012579. Price: $17.99 |
| 11 |
8-0909 |
DISCONTINUED Price: Call Us |
| 12 |
93-9838-03 |
SHROUD-SHAFT, DRIVE This part replaces 26-2250. Price: $56.70 |
| 13 |
32104-82 |
SCREW-HHF Price: $0.95 |
| 13 |
530071750 |
Seal-Cyl/Carb.(kit) Price: $8.99 |
| 14 |
3256-25 |
WASHER-FLAT Price: $0.25 |
| 14 |
530057547 |
Adapter-Carb. Price: $7.99 |
| 15 |
26-7970 |
CAUTION DECAL (BLADE) Price: $14.83 |
| 15 |
530016441 |
Screw Price: $1.99 |
| 16 |
26-1900 |
DISCONTINUED Price: Call Us |
| 16 |
530071750 |
Gasket-Carb. (kit) Price: $8.99 |
| 17 |
3290-384 |
PIN-LYNCH Price: $18.43 |
| 18 |
26-1580 |
SPACER 1/2 IN Price: $9.91 |
| 18 |
530058709 |
Bulb - Purge Price: $4.99 |
| 19 |
545077501 |
Air Box Price: $7.99 |
| 19 |
94-1291 |
BUSHING This part replaces 28-9290. Price: $10.99 |
| 20 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 20 |
530016429 |
Screw Price: $1.99 |
| 21 |
38-9420 |
LH CASTOR ARM ASM Price: $993.47 |
| 21 |
530036575 |
Foam-Air Filter Price: $1.99 |
| 22 |
3-6781 |
WASHER-THRUST Price: $1.40 |
| 22 |
530057545 |
Cover-Air Box Price: $3.99 |
| 23 |
530035505 |
Ignition Module Price: $29.99 |
| 23 |
99-5690 |
CASTOR FORK ASM This part replaces 26-1560. Price: $183.50 |
| 24 |
3220-5 |
NUT-JAM Price: $0.65 |
| 24 |
530059758 |
Spacer-Flywheel Price: $4.99 |
| 25 |
21-3870 |
AXLE ASM Price: $14.07 |
| 25 |
530016357 |
Screw Price: $1.99 |
| 26 |
3254-4 |
WASHER-LOCK/INT Price: $0.34 |
| 26 |
545015601 |
Assy-Switch wire Price: $11.99 |
| 27 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 27 |
99-5693 |
BEARING RETAINER W/WASHER This part replaces 40-9390. Price: $18.61 |
| 28 |
21-1030 |
SPANNER BUSHING Price: $17.87 |
| 28 |
530054834 |
Handle-Starter Price: $1.99 |
| 29 |
530071798 |
Kit - Rope Price: $3.99 |
| 30 |
21-3860 |
WHEEL Price: $85.23 |
| 30 |
530055122 |
Assy-Clutch Price: $8.99 |
| 31 |
21-3850 |
ROLLER BRG W/46-8960 Price: $15.21 |
| 31 |
530094189 |
Washer-Clutch Price: $2.99 |
| 32 |
3233-1 |
SCREW-CARR Price: $1.42 |
| 32 |
545016004 |
Assy.-Fan Hsg Price: $17.99 |
| 33 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 33 |
545008014 |
KIT STARTER SPRING This part replaces 545054901. Price: $3.99 |
| 34 |
3217-9 |
NUT-HH Price: $0.37 |
| 34 |
545050407 |
Kit-Starter Pulley Price: $11.99 |
| 35 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 35 |
545080601 |
Baffle Price: $6.99 |
| 36 |
3217-8 |
NUT-HEX Price: $1.34 |
| 36 |
530015880 |
Screw Price: $1.99 |
| 37 |
325-22 |
SCREW-HH This part replaces 325-21. Price: $4.26 |
| 37 |
530016463 |
Washer-Clutch Flat Price: $1.99 |
| 38 |
3-6778 |
AXLE SLINGER Price: $1.98 |
| 38 |
530039243 |
Assy-Flywheel Price: $27.99 |
| 39 |
3-6777 |
WASHER Price: $1.98 |
| 40 |
530015941 |
Retain. Ring-C'shaft Price: $1.99 |
| 41 |
3-6775 |
WASHER Price: $1.21 |
| 41 |
530055728 |
Outer Bearing Price: $6.99 |
| 42 |
3-0139 |
DISCONTINUED X-REF Price: Call Us |
| 42 |
530019264 |
Seal-C'shaft Price: $2.99 |
| 43 |
46-6230 |
DISCONTINUED This part replaces 3-6774. Price: Call Us |
| 43 |
530032125 |
Inner Bearing Price: $11.99 |
| 44 |
3-6776 |
SPACER Price: $9.65 |
| 45 |
32146-13 |
NUT-HEX Price: $3.49 |
| 45 |
530049817 |
CONNECTING ROD ASSY This part replaces 530069945. Price: $6.99 |
| 46 |
26-1530-01 |
FORK-CASTOR This part replaces 26-1530. Price: $178.41 |
| 46 |
530071750 |
O-Ring-C'case (kit) Price: $8.99 |
| 47 |
3231-22 |
SCREW-CARR Price: $0.72 |
| 48 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 48 |
530016386 |
Screw Price: $5.99 |
| 49 |
3-1365 |
CHAIN This part replaces 21-3160. Price: $72.97 |
| 49 |
530057539 |
Shroud-Rear Price: $7.99 |
| 50 |
5-2942 |
SHACKLE Price: $16.99 |
| 50 |
530016445 |
Retainer-Tank Price: $1.99 |
| 52 |
530057973 |
Assy-Fuel Cap Price: $7.99 |
| 53 |
530069247 |
Kit-Fuel Line (Small) Price: $3.99 |
| 54 |
530069216 |
Kit-Fuel Line (Large) Price: $3.99 |
| 56 |
530071750 |
Kit-Engine Gasket Price: $8.99 |
| 58 |
545077301 |
Assy-Clutch Cover Price: $5.99 |
| 59 |
530016319 |
Screw-Align Price: $1.99 |
| 60 |
530015772 |
Screw Price: $1.99 |
| 61 |
530016381 |
Screw 12-24 Price: $2.99 |
| 62 |
530016382 |
Nut 12-24 Price: $2.99 |
