| Ref | Part Number | Description |
|---|
| 1 |
105-7350 |
PLATFORM ASM Price: $2,911.29 |
| 1 |
138057 |
KNOB INF 3/8-16 Price: Call Us |
| 2 |
110807X |
NUT T Price: Call Us |
| 2 |
3290-355 |
PIN-HAIR Price: $2.09 |
| 3 |
110729X |
ROD LIFT LT Price: Call Us |
| 3 |
283-83 |
PIN-CLEVIS This part replaces 93-5343. Price: $9.52 |
| 4 |
100-3060-03 |
SEAT PLATE ASM Price: $378.52 |
| 4 |
76020308 |
SUB= 3145 Price: Call Us |
| 5 |
240-5 |
GROMMET Price: $13.66 |
| 5 |
2876H |
SPRING T Price: Call Us |
| 6 |
19131016 |
WASHER Price: Call Us |
| 6 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 7 |
104-7050 |
TUBE-MANUAL Price: $8.76 |
| 7 |
72140608 |
SUB= 72110608 Price: Call Us |
| 8 |
19151216 |
WASHER Price: Call Us |
| 8 |
2412-133 |
CLAMP-R Price: $3.19 |
| 9 |
100-4928 |
BELT-SEAT Price: $280.73 |
| 9 |
110810X |
TRUNION LT Price: Call Us |
| 10 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 11 |
109413X |
GRIP Price: Call Us |
| 11 |
3212-4 |
SCREW-HH Price: $2.73 |
| 12 |
122364X |
SUB= 125925X Price: Call Us |
| 12 |
93-5366 |
SHAFT-LATCH Price: $34.55 |
| 13 |
121002X |
SUB= 123096X Price: Call Us |
| 13 |
3234-4 |
SCREW-HHF Price: $0.50 |
| 14 |
110739X |
WASHER T Price: Call Us |
| 14 |
93-5363 |
LATCH ASM Price: $171.01 |
| 15 |
73980600 |
NUT SPECIAL T Price: Call Us |
| 15 |
93-5367 |
SPRING-TORSION Price: $30.35 |
| 16 |
4939M |
SUB= 85902 Price: Call Us |
| 16 |
93-5338 |
ROD-PROP Price: $124.99 |
| 17 |
121006X |
LEVER ROD LT Price: Call Us |
| 17 |
3234-42 |
SCREW-HHF Price: $1.10 |
| 18 |
3234-29 |
SCREW-HHF Price: $1.84 |
| 18 |
4921H |
SPRING.RETAINER Price: Call Us |
| 19 |
19171516 |
WASHER T Price: Call Us |
| 19 |
3272-5 |
PIN-COTTER Price: $1.39 |
| 20 |
110029X |
LIFT LINK LT Price: Call Us |
| 20 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 21 |
100-3149-03 |
BRACKET-BULKHEAD Price: $29.55 |
| 21 |
131926 |
SUB= 532131926 Price: Call Us |
| 22 |
110448X |
PIVOT PIN T Price: Call Us |
| 22 |
32144-67 |
SCREW Price: $2.87 |
| 23 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 23 |
110447X |
SUB= 132793 Price: Call Us |
| 24 |
69-8970 |
SPACER Price: $9.57 |
| 24 |
73710700 |
NUT LOCK YTH Price: Call Us |
| 25 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 25 |
12000037 |
KLIP RING Price: Call Us |
| 26 |
240-4 |
GROMMET-RUBBER Price: $9.91 |
| 26 |
73680600 |
SUB= 73690600 Price: Call Us |
| 27 |
121252X |
UPSTOP Price: Call Us |
| 27 |
69-8940 |
WASHER Price: $1.76 |
| 28 |
121598X |
RH SUSP ARM ASM Price: Call Us |
| 28 |
340-70 |
NUT-LOCK Price: $2.10 |
| 29 |
100-5500-03 |
SUPPORT Price: $27.31 |
| 29 |
9135R |
SPRING H Price: Call Us |
| 30 |
106308X |
SUB= 130171 Price: Call Us |
| 30 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 31 |
124526X |
SUB= 125925X Price: Call Us |
| 31 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 32 |
73220800 |
NUT Price: Call Us |
| 33 |
121599X |
LH SUSP ARM ASM Price: Call Us |
| 34 |
100-3045-01 |
COVER-TUBES Price: $39.02 |
| 34 |
12000022 |
E-RING Price: Call Us |
| 35 |
32144-14 |
SCREW-HWHTF Price: $4.29 |
| 35 |
73360700 |
NUT Price: Call Us |
| 36 |
105-7373-01 |
BRACKET-BULKHEAD, LH Price: $21.85 |
| 36 |
105-7489-01 |
BRACKET-BULKHEAD, RH Price: $20.84 |
| 37 |
19292016 |
WASHER Price: Call Us |
| 37 |
340-2 |
FITTING-STRAIGHT Price: $11.43 |
| 38 |
73350600 |
NUT Price: Call Us |
| 38 |
98-9742 |
VALVE-CONTROL, FLOW Price: $158.79 |
| 39 |
123934X |
HEIGHT INDICATOR Price: Call Us |
| 39 |
340-110 |
FITTING-SWIVEL, 90 DEG Price: $49.98 |
| 40 |
340-68 |
FITTING-TEE, BULKHEAD Price: $36.00 |
| 41 |
19112410 |
WASHER Price: Call Us |
| 41 |
340-115 |
FITTING-TEE, SWIVEL NUT Price: $56.09 |
| 42 |
10040500 |
LOCKWASHER Price: Call Us |
