| Ref | Part Number | Description |
|---|
| 1 |
461929 |
Lever Assembly, Deck Level Price: Call Us |
| 2 |
481764 |
Link, Deck Lift Price: Call Us |
| 3 |
481765 |
Rod End, Female - 1/2-20 RH Price: Call Us |
| 4 |
481766 |
Rod End, Female - 1/2-20 LH Price: Call Us |
| 5 |
04020-27 |
Nut, Jam 1/2-20 RH Price: Call Us |
| 6 |
04020-28 |
Nut, Jam 1/2-20 LH Price: Call Us |
| 7 |
04021-09 |
Nut, 3/8-16 Elastic Stop Price: Call Us |
| 8 |
482429 |
Slide Weldment, Height Adjustment Price: Call Us |
| 9 |
43391 |
Spacer, Decklift Pedal Price: Call Us |
| 10 |
43487 |
Pin, Decklift Price: Call Us |
| 11 |
43526 |
Swivel Joint, LH Price: Call Us |
| 12 |
43527 |
Swivel Joint, RH Price: Call Us |
| 13 |
45904 |
Bellcrank Weldment, LH Rear Price: Call Us |
| 14 |
45905 |
Bellcrank Weldment, RH Rear Price: Call Us |
| 15 |
04021-05 |
Locknut, 3/8-16 Center Lock Price: Call Us |
| 16 |
422381 |
Guide, Short Price: Call Us |
| 17 |
423509 |
Guide, Long Price: Call Us |
| 18 |
422346 |
Lockplate, Decklift Price: Call Us |
| 20 |
48100-14 |
Bushing, .502" ID. Price: Call Us |
| 21 |
481428 |
Grip, Deck Latch Price: Call Us |
| 23 |
424504 |
Foot Pedal, Height Adjustment Price: Call Us |
| 24 |
04020-09 |
Nut, Hex 5/8-11 Price: Call Us |
| 25 |
04019-03 |
Nut, Hex Serrated Flange 5/16-18 Price: Call Us |
| 26 |
04040-09 |
Flatwasher, 5/8" (.656 x 1.312 x .095") Price: Call Us |
| 27 |
04041-14 |
Flatwasher, 1" (1.062 x 1.50 x .048") Price: Call Us |
| 28 |
48114-04 |
Grease Fitting Price: Call Us |
| 29 |
04061-07 |
Cotter Pin, 3/16 x 1" Price: Call Us |
| 30 |
04030-07 |
Lockwasher, 5/8" Spring Price: Call Us |
| 31 |
04004-44 |
Stud, 5/8-11 x 22.0" Price: Call Us |
| 32 |
04067-09 |
Ring Pin, 1/2 x 3.06" Price: Call Us |
| 33 |
04050-08 |
Ring, Retaining 1" External "E" Price: Call Us |
| 34 |
04021-07 |
Nut, Hex Elastic Stop 1/2-13 Price: Call Us |
| 35 |
04108-04 |
Capscrew, 5/8-11 x 1-1/2" This part replaces 04105-01. Price: Call Us |
| 36 |
423463 |
Bracket, Cutting Height Adjustment Price: Call Us |
| 37 |
04014-03 |
Screw, Cap 5/16-18 x 3" FHHS Price: Call Us |
| 38 |
481547 |
Lanyard, Deck Height Pin Price: Call Us |
| 39 |
48540 |
Chain Price: Call Us |
| 40 |
04001-20 |
Bolt, Hex Head 3/8-16 x 1-1/2" B&S 32BV Price: Call Us |
| 41 |
04019-04 |
Nut, Hex Serrated Flange 3/8-16 Price: Call Us |
| 42 |
04050-10 |
Ring, Retaining 1/2" External "E" Price: Call Us |
| 43 |
04001-74 |
Bolt, Hex Head 1/2-13 x 3" Price: Call Us |
| 44 |
04003-04 |
Bolt, Carriage 5/16-18 x 1" Price: Call Us |
