| Ref | Part Number | Description |
|---|
| 2 |
353-481 |
LIFT CHECK ASM Price: $338.44 |
| 2 |
532180095 |
DECAL.ENG.25HP.KAWA.HSQV.XP Price: $40.99 |
| 3 |
237-54 |
O-RING Price: $1.97 |
| 3 |
532181660 |
RH HOOD DECAL Price: $51.29 |
| 4 |
353-306 |
WASHER-BACKUP Price: $9.12 |
| 4 |
532181661 |
LH HOOD DECAL Price: $51.29 |
| 5 |
353-305 |
O-RING Price: $10.91 |
| 5 |
532180091 |
DECAL HOOD SIDES Price: $2.99 |
| 6 |
581579501 |
DECAL.MOWER.WARN.KEEP.HAND.AWY This part replaces 532170563. Price: $3.99 |
| 7 |
353-302 |
O-RING Price: $10.13 |
| 7 |
581708378 |
KIT.AUGER.HOUSING.404929X668 This part replaces 532189041. Price: $229.99 |
| 8 |
353-303 |
WASHER-BACKUP Price: $9.06 |
| 9 |
532176822 |
DECAL, FENDER Price: $12.99 |
| 10 |
353-853 |
BOLT Price: $39.87 |
| 10 |
532157140 |
DECAL FENDER DANGER Price: $12.99 |
| 11 |
353-668 |
PLATE-COVER Price: $508.66 |
| 11 |
532181253 |
DECAL, FOOTREST Price: $46.29 |
| 12 |
532181066 |
DECAL, FINAL Price: $17.68 |
| 13 |
353-550 |
PLUG-HYD, HH Price: $10.71 |
| 13 |
532175291 |
DECAL V-BELT SCHEMATIC Price: $3.99 |
| 14 |
353-848 |
O-RING Price: $0.89 |
| 14 |
532178502 |
DECAL CLUTCH/BRAKE Price: $7.99 |
| 15 |
353-957 |
CUP-SEAL Price: $16.26 |
| 15 |
532170564 |
DECAL.WHEEL.STEERING.HUSQ.PERM Price: $5.99 |
| 16 |
353-958 |
WASHER Price: $13.57 |
| 17 |
532182854 |
DECAL, SADDLE BRAKE PARKING Price: $19.46 |
| 18 |
92-2547 |
SEAL-RETAINER Price: $15.10 |
| 19 |
353-733 |
SPACER-BONNET Price: $41.01 |
| 20 |
353-417 |
COLLAR-STOP Price: $10.31 |
| 21 |
353-831 |
SPRING Price: $13.22 |
| 22 |
353-529 |
PLATE-RETAINER, SEAL Price: $15.07 |
| 23 |
532106202 |
REFLECTOR-TAIL YT Price: $3.99 |
| 23 |
92-3148 |
SPRING-TRACTION Price: $13.84 |
| 24 |
353-808 |
COLLAR-SPRING Price: $27.44 |
| 24 |
532145005 |
DECAL BTRY SYMBOLS Price: $3.99 |
| 24 |
581724801 |
DECAL.BYPASS.FENDER.CRD/LT/YT This part replaces 532166960. Price: $3.99 |
| 24 |
581724901 |
DECAL.TRACTOR.6MIL.H/ADJUST This part replaces 532138311. Price: $9.99 |
| 25 |
353-830 |
O-RING Price: $1.41 |
| 26 |
94-4248 |
COLLAR-SPOOL This part replaces 353-829. Price: $58.22 |
| 27 |
68-4240 |
BONNET ASSEMBLY This part replaces 354-26. Price: $42.76 |
| 28 |
354-28 |
SCREW-HS Price: $8.35 |
| 29 |
353-851 |
BODY-RELIEF Price: $180.95 |
| 30 |
353-392 |
RING-PISTON Price: $13.94 |
| 31 |
353-531 |
POPPET AND RING ASM Price: $229.51 |
| 32 |
353-328 |
SHIM (.040) Price: $3.53 |
| 33 |
353-329 |
SHIM (.020) Price: $2.10 |
| 34 |
353-330 |
SHIM (.010) Price: $3.60 |
| 35 |
353-398 |
SPRING Price: $30.09 |
| 36 |
353-334 |
CAP-RELIEF Price: $55.48 |
| 37 |
52-5900 |
SCREW Price: $26.40 |
| 38 |
353-847 |
BONNET Price: $129.59 |
| 39 |
353-849 |
SLEEVE Price: $46.19 |
| 40 |
353-846 |
SPUD Price: $118.09 |
| 41 |
353-845 |
SLEEVE-DETENT Price: $79.50 |
| 42 |
353-730 |
SPRING Price: $18.22 |
| 43 |
353-731 |
BALL Price: $12.95 |
| 44 |
353-398 |
SPRING This part replaces 353-855. Price: $30.09 |
| 45 |
3274-52 |
SCREW-HSH Price: $3.19 |
| 46 |
353-575 |
BOOT Price: $58.68 |
| 47 |
93-3651 |
RETAINER-BOOT Price: $31.38 |
| 51 |
52-5860 |
COLLAR-SPOOL Price: $13.37 |
| 52 |
354-122 |
DISC-SEAL Price: $6.92 |
| 54 |
353-953 |
PLUG ASM Price: $182.79 |
| 55 |
353-844 |
PLUG Price: $75.53 |
| 56 |
353-850 |
O-RING Price: $1.17 |
| 57 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 58 |
3274-84 |
SCREW-HSH Price: $2.51 |
| 59 |
38-0410 |
NUT-HEX Price: $5.77 |
| 60 |
83-1890 |
SWITCH-BALL Price: $63.08 |
| 61 |
354-129 |
ANTICAVITATION CHECK ASM This part replaces 353-483. Price: $152.63 |
| 62 |
353-484 |
RETURN-BALL, CHECK Price: $139.05 |
| 63 |
353-737 |
BALL-CHECK Price: $14.19 |
| 64 |
92-2546 |
WIPER-SEAL Price: $4.56 |
| 532184761 |
MANUAL, |
OWNER'S (ENGLISH) Price: $10.46 532184761 |
