| Ref | Part Number | Description |
|---|
| 1 |
48-8970 |
DISCONTINUED Price: Call Us |
| 2 |
11-5519 |
DISCONTINUED Price: Call Us |
| 3 |
48-8880 |
PIN-DOWEL Price: $1.70 |
| 4 |
48-8990 |
DISCONTINUED X-REF Price: Call Us |
| 5 |
76-3580 |
SPACER-BEDBAR AND SIDEPLATE This part replaces 48-9240. Price: $0.68 |
| 6 |
48-8160 |
DISCONTINUED Price: Call Us |
| 7 |
256-277 |
DISCONTINUED Price: Call Us |
| 8 |
48-9190 |
SHOULDER BOLT Price: $19.88 |
| 9 |
48-9010 |
DISCONTINUED Price: Call Us |
| 10 |
59-6140 |
BEARING This part replaces 48-8860. Price: $92.24 |
| 11 |
93-1414 |
SEAL-GREASE This part replaces 253-145. Price: $7.54 |
| 12 |
302-40 |
FITTING-GREASE, 90 DEG Price: $1.70 |
| 13 |
32151-71 |
RING-RETAINING, INTERNAL Price: $2.10 |
| 14 |
48-9250 |
DISCONTINUED Price: Call Us |
| 15 |
256-252 |
BEARING-FLANGE Price: $5.35 |
| 16 |
48-9020 |
BOLT-SHOULDER Price: $16.08 |
| 17 |
3290-440 |
WASHER-BELLEVILLE Price: $7.46 |
| 18 |
3296-28 |
NUT-LOCK, NI Price: $0.61 |
| 19 |
48-9030 |
DISCONTINUED Price: Call Us |
| 20 |
48-9170 |
DISCONTINUED Price: Call Us |
| 21 |
3219-20 |
NUT-HEX, LH This part replaces 48-9710. Price: $1.15 |
| 22 |
48-9220 |
WASHER-PLAIN Price: $0.87 |
| 23 |
119-4162 |
SCREW-CARR This part replaces 3231-25. Price: $1.73 |
| 24 |
32128-21 |
NUT-HF Price: $0.39 |
| 25 |
48-9230 |
DISCONTINUED Price: Call Us |
| 40 |
47-7140 |
PULLEY-DRIVEN Price: $290.32 |
| 41 |
3257-3 |
KEY-WOODRUFF Price: $0.99 |
| 42 |
48-9180 |
DISCONTINUED Price: Call Us |
| 43 |
32121-50 |
PIN-SPRING Price: $1.21 |
| 44 |
3234-12 |
SCREW-HHF Price: $0.61 |
| 45 |
46-6770 |
DISCONTINUED Price: Call Us |
| 46 |
48-9050 |
SHIELD-PLATE, DRIVE Price: $15.38 |
| 47 |
7-4650 |
WASHER-PLAIN This part replaces 48-9060. Price: $0.41 |
| 48 |
324-6 |
SCREW-HH Price: $0.81 |
| 49 |
3256-4 |
WASHER-FLAT Price: $0.28 |
| 50 |
3296-48 |
NUT-LOCK, NI Price: $0.37 |
| 51 |
47-7150 |
PULLEY-DRIVE Price: $259.16 |
| 52 |
3246-17 |
SETSCREW-HSH This part replaces 48-7480. Price: $0.47 |
| 53 |
47-7160 |
BELT Price: $26.00 |
| 54 |
48-9080 |
DISCONTINUED Price: Call Us |
| 55 |
47-7170 |
GASKET-COVER Price: $22.96 |
| 56 |
3234-14 |
SCREW-HHF Price: $0.61 |
| 57 |
47-7180 |
DISCONTINUED Price: Call Us |
| 58 |
8-3990 |
REAR ROLLER ASM Price: $352.13 |
| 59 |
48-9090 |
DISCONTINUED Price: Call Us |
| 60 |
3-4010 |
BUSHING ASM Price: $14.71 |
| 62 |
3231-22 |
SCREW-CARR Price: $0.72 |
| 64 |
5-4527 |
WASHER-THRUST Price: $3.00 |
| 65 |
48-9100 |
DISCONTINUED Price: Call Us |
| 71 |
48-9200 |
DISCONTINUED Price: Call Us |
| 74 |
48-9120 |
RH SKID WA *R Price: $184.40 |
| 77 |
48-9140 |
DISCONTINUED Price: Call Us |
| 78 |
110-3986 |
SCREW This part replaces 48-8870. Price: $1.03 |
