| Ref | Part Number | Description |
|---|
| 1 |
21-1880 |
GRIP-HANDLE Price: $11.67 |
| 1 |
510375601 |
HG_EZT, LT Price: $899.99 |
| 2 |
510375602 |
HG_EZT, RT Price: $899.99 |
| 2 |
84-8500-01 |
LEVER-PTO This part replaces 84-8500. Price: $107.85 |
| 3 |
593852803 |
Spacers This part replaces 510184101. Price: $11.99 |
| 3 |
72-4320 |
SWITCH-BALL Price: $90.18 |
| 4 |
237-30 |
O-RING Price: $2.50 |
| 4 |
580806502 |
SUPPORT.FRONT.TRANS.PNTX431 This part replaces 522460702. Price: $5.99 |
| 5 |
43-8610 |
GUIDE Price: $23.35 |
| 5 |
510185102 |
EZT MOUNT, REAR, BLACK Price: $32.99 |
| 6 |
539101721 |
HCS 5/16C X 2-3/4 Price: $3.99 |
| 6 |
84-8520-01 |
BRACKET-SWITCH, PTO This part replaces 84-8520. Price: $11.07 |
| 7 |
283-42 |
PIN-CLEVIS Price: $40.05 |
| 7 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 539990188. Price: $2.99 |
| 8 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 8 |
596583702 |
Nuts This part replaces 539990717. Price: $2.99 |
| 9 |
43-3860 |
SHAFT-PIVOT, PTO Price: $55.10 |
| 9 |
596434201 |
Bolts This part replaces 539990637. Price: $3.99 |
| 10 |
302-10 |
FITTING-GREASE Price: $2.64 |
| 10 |
596238701 |
Washers This part replaces 539990118. Price: $3.99 |
| 11 |
3257-5 |
KEY-WOODRUFF Price: $5.13 |
| 11 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 539990122. Price: $2.99 |
| 12 |
106-4383 |
BELT-V, BANDED This part replaces 53-9660. Price: $40.02 |
| 12 |
539976938 |
CAPSCREW Price: $3.99 |
| 13 |
21-0230 |
PULLEY-PTO Price: $409.71 |
| 13 |
580624201 |
ROD MOTION CONTROL This part replaces 522945001. Price: $3.99 |
| 14 |
3256-28 |
WASHER-FLAT Price: $0.48 |
| 14 |
579764601 |
JOINT.HEIM.FEML.5/16.RH.THREAD This part replaces 539115729. Price: $7.99 |
| 15 |
3254-7 |
WASHER-LOCK, INT Price: $4.82 |
| 15 |
596718601 |
Coupling This part replaces 539116689. Price: $2.99 |
| 16 |
3219-7 |
NUT-HEX Price: $1.53 |
| 16 |
588692502 |
ROD.END.MALE.LH.THREAD This part replaces 539116690. Price: $8.99 |
| 17 |
3272-22 |
PIN-COTTER Price: $0.61 |
| 17 |
596040901 |
Hardware This part replaces 539990223. Price: $2.99 |
| 18 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 18 |
596584101 |
Nuts This part replaces 539991073. Price: $2.99 |
| 19 |
3-8812 |
SPACER-SPRING, ANCHOR Price: $15.47 |
| 19 |
596580801 |
Bolts This part replaces 539990209. Price: $2.99 |
| 20 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 20 |
539120785 |
HG_HYDRO FAN 51365 Price: $29.99 |
| 21 |
5-1747 |
SPRING-ADJUSTMENT Price: $5.76 |
| 21 |
522941102 |
Links This part replaces 522941101. Price: $4.99 |
| 22 |
596930401 |
Links This part replaces 574030501. Price: $6.99 |
| 22 |
92-5727 |
SCREW-LOCK, PATCH Price: $0.92 |
| 23 |
596930701 |
Links This part replaces 574030502. Price: $5.99 |
| 23 |
92-5723 |
BUSHING-FORK, PTO Price: $4.74 |
| 24 |
110-9681-03 |
FORK-PTO This part replaces 92-4060. Price: $195.34 |
| 24 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 539976934. Price: $3.99 |
| 25 |
27-7370 |
PTO BRAKE ASM Price: $218.20 |
| 25 |
596040801 |
Hardware This part replaces 539976977. Price: $2.99 |
| 26 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 539976978. Price: $1.99 |
| 26 |
93-3769 |
PIN-CLEVIS Price: $4.14 |
| 27 |
3296-28 |
NUT-LOCK, NI Price: $0.61 |
| 27 |
596582301 |
Washers This part replaces 539990055. Price: $2.99 |
| 28 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 28 |
539108535 |
SCR #10-24 X 3/4 Price: $2.99 |
| 29 |
3246-3 |
SCREW-HSH Price: $12.70 |
| 29 |
596299801 |
Springs This part replaces 539110342. Price: $2.99 |
| 30 |
596580601 |
Pins This part replaces 539976988. Price: $3.99 |
| 30 |
92-4058-01 |
ARM PTO This part replaces 92-4058. Price: $136.94 |
| 31 |
100-6599 |
PTO PIVOT ASM This part replaces 43-5500. Price: $780.32 |
| 31 |
539120080 |
HG_DISC COG BRAKE 51635 Price: $29.99 |
| 32 |
43-5550 |
SHAFT-ACTUATOR, PTO Price: $143.65 |
| 32 |
539120079 |
HG_KIT BRAKE ARM (EZT) Price: $32.99 |
| 33 |
3219-3 |
NUT-HEX Price: $0.34 |
| 33 |
575507001 |
HG_KIT, HYDRO-GEAR HUB Price: $279.99 |
| 34 |
3296-6 |
NUT-LOCK Price: $1.49 |
| 35 |
27-7900 |
SCREW-ADJUSTING Price: $21.70 |
| 36 |
3256-41 |
WASHER Price: $1.18 |
| 37 |
5-0652 |
SPACER Price: $5.35 |
| 38 |
43-5570-01 |
ARM-ACTUATOR This part replaces 43-5570. Price: $164.96 |
| 39 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 40 |
251-252 |
BEARING Price: $98.35 |
| 41 |
251-234 |
COLLAR-LOCKING Price: $17.04 |
| 42 |
32120-22 |
RING-SNAP, INTERNAL Price: $2.29 |
| 43 |
43-5540 |
SHAFT-PTO Price: $846.33 |
| 44 |
100-6564 |
DRIVESHAFT ASM This part replaces 62-4260. Price: $924.10 |
| 46 |
3245-1 |
SCREW-SET, HSH Price: $0.54 |
| 47 |
256-113 |
BUSHING-FLANGE Price: $5.58 |
| 48 |
21-0400-01 |
SPRING-COMPRESSION This part replaces 21-0400. Price: $20.88 |
| 49 |
32121-9 |
PIN-ROLL, SLOTTED Price: $2.56 |
| 50 |
21-1830 |
SPRING-EXTENSION Price: $34.62 |
| 51 |
43-5630 |
YOKE-PTO Price: $80.75 |
| 52 |
5-0701 |
ANCHOR Price: $4.07 |
| 53 |
212-93 |
CLAMP-CASING Price: $3.46 |
| 54 |
21-1600 |
CLAMP-LEVER, PTO Price: $279.65 |
| 55 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 56 |
32104-6 |
SCREW-HH, TAP Price: $3.19 |
| 66 |
43-8600 |
SPRING-COMPRESSION Price: $3.03 |
| 67 |
43-8860 |
PLUNGER-SWITCH Price: $11.85 |
| 68 |
43-8620 |
PIN-GUIDE, SWITCH Price: $88.57 |
| 69 |
237-7 |
O-RING Price: $8.82 |
| 70 |
218-461 |
NUT-HH Price: $2.50 |
| 71 |
43-8870 |
BOOT-SWITCH Price: $47.92 |
| 72 |
321-4 |
SCREW-HH Price: $0.99 |
| 73 |
86-7050 |
BRACKET-SWITCH, ACTUATOR Price: $16.28 |
| 74 |
3296-16 |
NUT-LOCK, NI Price: $1.39 |
| 75 |
75-9890 |
WASHER-SHIM Price: $3.18 |
