| Ref | Part Number | Description |
|---|
| 1 |
323-6 |
SCREW-HH Price: $0.66 |
| 1 |
532132566 |
Link, Drag (AYP part number) Price: $32.99 |
| 2 |
874780828 |
Bolt, Fin Hex 1/2-13 x 1-3/4 (AYP part number) Price: $2.99 |
| 3 |
112-6967 |
O-RING Price: $2.70 |
| 4 |
120-5118 |
SHAFT-ADJUSTER Price: $44.64 |
| 5 |
106-5344 |
BUSHING-FLANGE, KEYED Price: $2.37 |
| 5 |
532121926 |
Gear, Sector (AYP part number) Price: $29.99 |
| 6 |
119-4067 |
SCREW-HH Price: $0.81 |
| 6 |
532121927 |
Bushing (AYP part number) Price: $17.99 |
| 7 |
873350800 |
NUT.HEX.JAM.1/2-13 This part replaces 873030800. Price: $1.99 |
| 7 |
99-2097 |
DETENT Price: $12.71 |
| 8 |
120-5116 |
WASHER-WAVE Price: $9.17 |
| 8 |
532126472 |
Clip, Insulated (AYP part number) Price: $2.45 |
| 9 |
108-0015 |
WASHER-FLAT Price: $0.39 |
| 9 |
873350800 |
NUT.HEX.JAM.1/2-13 This part replaces 873680800. Price: $1.99 |
| 10 |
137-6130 |
SCREW-ADJUSTER, BEDBAR This part replaces 115-7039. Price: $25.42 |
| 10 |
876020412 |
Pin, Cotter 1/8 x 3/4 (AYP part number) Price: $3.99 |
| 11 |
119-4155 |
WASHER-HARDENED Price: $4.16 |
| 11 |
819131316 |
Washer, 13/32 x 13/16 x 16 Ga. (AYP part number) Price: $2.99 |
| 12 |
120-5120 |
SPRING-COMPRESSION Price: $2.89 |
| 12 |
532126847 |
Bushing (AYP part number) Price: $2.99 |
| 13 |
119-4039 |
NUT-HEX, NI Price: $0.28 |
| 13 |
539976934 |
HCS 5/16C X 3/4 This part replaces 874760512. Price: $1.99 |
| 14 |
734116541 |
WASHER - 25X8.5X2.3 This part replaces 819111416. Price: $3.99 |
| 15 |
107-3273-01 |
BEDBAR Price: $303.02 |
| 15 |
872110606 |
Bolt, Carriage 3/8-16 UNC x 3/4 (AYP part number) Price: $2.99 |
| 16 |
119-4151 |
SCREW-BEDKNIFE Price: $0.41 |
| 17 |
137-6094 |
BEDKNIFE-EDGEMAX (RM 22IN) This part replaces 108-9095. Price: $166.88 |
| 17 |
532137096 |
Support, Front Axle (AYP part number) Price: $12.99 |
| 20 |
873680600 |
Nut, Crownlock 3/8-16 Price: $1.99 |
| 24 |
61-1950 |
WASHER-PLASTIC Price: $0.55 |
| 25 |
56-9520 |
BUSHING-FLANGED Price: $2.15 |
| 26 |
69-8980 |
WASHER Price: $0.58 |
| 27 |
106-9623 |
BOLT-BEDBAR Price: $18.27 |
| 28 |
3296-33 |
NUT-LOCK, NI Price: $2.39 |
| 29 |
127-4284 |
WASHER-SPECIAL Price: $5.88 |
| 30 |
115-5258 |
SPRING-WIRE, FLAT Price: $3.40 |
| 31 |
140-5510 |
BEARING-SEALED, STAINLESS This part replaces 115-3296. Price: $28.48 |
| 32 |
115-3299 |
SEAL-FLOCKED Price: $13.85 |
| 34 |
137-8445 |
EDGE SERIES REEL+ 7IN FAIRWAY(22IN)8 BLADE LOW DRAG (RADIALREEL) This part replaces 131-6805. Price: $801.61 |
| 37 |
127-7111 |
INSERT-THREADED, 7 INCH (LH) Price: $42.48 |
| 38 |
127-7109 |
INSERT-THREADED, 7 INCH (RH) Price: $42.48 |
