| Ref | Part Number | Description |
|---|
| 1 |
115-8047-01 |
NO. 3 LIFT ARM ASM This part replaces 92-9291-01. Price: $1,059.77 |
| 1 |
138788 |
TRANSAX. PRLES. Price: Call Us |
| 2 |
110422X |
SUB= 146682 Price: Call Us |
| 2 |
68-6480 |
BUSHING-FLANGE Price: $3.19 |
| 3 |
121327X |
PULLEY TRANSAXLE Price: Call Us |
| 3 |
325-17 |
SCREW-HH Price: $2.90 |
| 4 |
12000004 |
RING Price: Call Us |
| 4 |
323-7 |
SCREW-HH Price: $0.65 |
| 5 |
123776X |
BRKT TRANS RH Price: Call Us |
| 6 |
52-6180 |
SPACER Price: $1.65 |
| 7 |
60-3250 |
WASHER Price: $5.21 |
| 8 |
123781X |
SUB= 141002 Price: Call Us |
| 8 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 9 |
3256-56 |
WASHER-FLAT Price: $1.15 |
| 10 |
76020416 |
PIN COTTER 1/8 Price: Call Us |
| 10 |
92-9246-03 |
A-FRAME Price: $525.35 |
| 11 |
105701X |
WASH-SHFT PLT LT Price: Call Us |
| 11 |
325-7 |
SCREW-HH Price: $1.53 |
| 12 |
115-8046-01 |
NO. 2 LIFT ARM ASM This part replaces 92-9290-01. Price: $933.22 |
| 13 |
71040412 |
SUB= 74550412 Price: Call Us |
| 14 |
19091216 |
WASHER PM Price: Call Us |
| 14 |
60-1280 |
PIN Price: $3.53 |
| 15 |
58-4380 |
PIN Price: $25.11 |
| 15 |
74780544 |
BOLT HEX Price: Call Us |
| 17 |
115-8017 |
REEL MOTOR KIT This part replaces 93-1412. Price: $1,999.51 |
| 17 |
123780X |
BRKT TRANS LH Price: Call Us |
| 18 |
17490512 |
SCREW Price: Call Us |
| 18 |
3246-17 |
SETSCREW-HSH Price: $0.47 |
| 19 |
3296-48 |
NUT-LOCK, NI Price: $0.37 |
| 20 |
323-14 |
SCREW-HH Price: $1.34 |
| 21 |
106279X |
CONTROL KNOB LT Price: Call Us |
| 21 |
324-6 |
SCREW-HH Price: $0.81 |
| 22 |
123786X |
ROD BRAKE Price: Call Us |
| 23 |
73800600 |
NUT Price: Call Us |
| 24 |
73350600 |
NUT Price: Call Us |
| 26 |
340-87 |
FITTING-ELBOW, 45 DEG Price: $18.39 |
| 27 |
76020412 |
COTTER PIN Price: Call Us |
| 28 |
133261 |
BRAKE PARK ROD Price: Call Us |
| 29 |
7733J |
SUB= 71673 Price: Call Us |
| 30 |
123787X |
STRAP TORQUE Price: Call Us |
| 31 |
115-8011 |
CYLINDER-HYD This part replaces 104-5225. Price: $784.12 |
| 31 |
123791X |
KEEPER BELT LH Price: Call Us |
| 32 |
74760612 |
SUB= 74780612 Price: Call Us |
| 32 |
93-7331 |
DECAL-WARNING Price: $10.35 |
| 34 |
122424X |
SUB= 149001 Price: Call Us |
| 34 |
325-34 |
SCREW-HH Price: $2.37 |
| 35 |
120183X |
NYLON BEARING Price: Call Us |
| 36 |
19211616 |
WASHER LT Price: Call Us |
| 37 |
1572H |
SUB= 2882J Price: Call Us |
| 37 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 38 |
123674X |
PULLEY.IDLER.FLAT Price: Call Us |
| 39 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 39 |
74760644 |
BOLT Price: Call Us |
| 40 |
4470J |
SPACER T Price: Call Us |
| 41 |
109070X |
BELT KEEPER LT Price: Call Us |
| 42 |
19131316 |
WASHER Price: Call Us |
| 45 |
110812X |
WASHER LT Price: Call Us |
| 46 |
12000039 |
KLIP RING Price: Call Us |
| 47 |
127783 |
SUB= 139245 Price: Call Us |
| 48 |
123789X |
ARM IDLER Price: Call Us |
| 49 |
123205X |
RETAIN BELT Price: Call Us |
| 50 |
74760624 |
SUB= 74930624 Price: Call Us |
| 51 |
73680600 |
SUB= 73690600 Price: Call Us |
| 57 |
123796X |
BELT.GRDRV.94.75 Price: Call Us |
| 59 |
140312 |
KEEPER BELT CNTSP Price: Call Us |
| 60 |
17490612 |
SCREW Price: Call Us |
| 62 |
8883R |
PEDAL COVER T Price: Call Us |
| 63 |
136906 |
PULLEY ENGINE Price: Call Us |
| 64 |
71170768 |
SUB= 150280 Price: Call Us |
| 66 |
121218X |
KEEPER BELT ENGLH Price: Call Us |
| 67 |
74760616 |
BOLT Price: Call Us |
| 68 |
19131312 |
WASHER Price: Call Us |
| 69 |
73800500 |
NUT Price: Call Us |
| 74 |
108097X |
SPACER HYT Price: Call Us |
| 75 |
123800X |
WASHER Price: Call Us |
| 76 |
12000053 |
E RING HYT Price: Call Us |
| 77 |
9396E |
SQ KEY STD Price: Call Us |
| 79 |
2228M |
SUB= 2228M1 Price: Call Us |
| 83 |
19171216 |
WASHER Price: Call Us |
| 85 |
73530400 |
NUT 1/4-28 Price: Call Us |
| 86 |
71208 |
BUSHING Price: Call Us |
| 87 |
19212016 |
WASHER D Price: Call Us |
| 88 |
12000008 |
KLIP RING Price: Call Us |
| 89 |
139992 |
CONSOLE SHIFTER Price: Call Us |
| 90 |
124346X |
NUT Price: Call Us |
| 96 |
4497H |
RETAINER M Price: Call Us |
| 100 |
19111216 |
WASHER M Price: Call Us |
| 102 |
2751R |
CLIP T Price: Call Us |
| 107 |
72140506 |
BOLT Price: Call Us |
| 109 |
137141 |
BRACKET.ASM.MTG Price: Call Us |
| 110 |
137140 |
SUB= 142600 Price: Call Us |
| 111 |
19111012 |
WASHER T Price: Call Us |
