| Ref | Part Number | Description |
|---|
| 1 |
532134048 |
This part replaces 532800386. Price: $36.95 |
| 1 |
98-9508 |
WASHER-SHAFT, R-ARM Price: $0.47 |
| 2 |
532131094 |
CONTROL BAR Price: $12.99 |
| 2 |
98-9385 |
WASHER-FLAT Price: $1.24 |
| 3 |
585161003 |
GRIP.HANDLE.FOAM.438MM This part replaces 532850724. Price: $4.99 |
| 3 |
98-9393 |
NUT Price: $2.72 |
| 4 |
98-9503 |
NUT Price: $1.33 |
| 5 |
532800547 |
TRIM PLATE Price: $7.15 |
| 5 |
98-9501 |
ROCKER ARM ASM Price: $28.78 |
| 6 |
532125294X |
Upper Handle Price: Call Us |
| 6 |
98-9502 |
SCREW-ADJUSTING Price: $2.78 |
| 7 |
532701477 |
FASTENER Price: $2.38 |
| 7 |
98-9365 |
SCREW-SET Price: $0.99 |
| 8 |
105-3790 |
R-ARM SHAFT ASM This part replaces 98-9612. Price: $28.61 |
| 8 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 532063601. Price: $1.99 |
| 9 |
532157081 |
HANDLE.LOWER.BLACK This part replaces 532157082. Price: $54.99 |
| 9 |
98-9370 |
CLIP-CIRCULAR, EXTERNAL Price: $1.30 |
| 10 |
532183724 |
KIT.KNOB.HANDLE.SERVICE This part replaces 532131959. Price: $9.99 |
| 10 |
98-9507 |
WASHER-SHAFT, ROCKER ARM Price: $0.85 |
| 11 |
532700417 |
THROTTLE CONTROL Price: $17.99 |
| 11 |
98-9505 |
BRACKET-ARM, ROCKER Price: $22.17 |
| 12 |
98-9504 |
SPRING-ARM, ROCKER Price: $0.66 |
| 13 |
532007192 |
WIRE TIE This part replaces 532151517. Price: $7.99 |
| 13 |
98-9391 |
SCREW-SET, ROCKER ARM Price: $5.98 |
| 14 |
586122501 |
KIT.ROPE.GUIDE.T-KNOB This part replaces 532132001. Price: $7.99 |
| 14 |
99-8385 |
SEAL-STEM, VALVE This part replaces 98-9496. Price: $7.29 |
| 15 |
532183724 |
KIT.KNOB.HANDLE.SERVICE This part replaces 532136376. Price: $9.99 |
| 15 |
98-9648 |
SPRING-VALVE Price: $13.49 |
| 16 |
107-9092 |
RETAINER-SPRING This part replaces 98-9498. Price: $2.58 |
| 16 |
532059935 |
SCREW 1/4-20X1.75 Price: $2.38 |
| 17 |
117-7572 |
COLLET-SPRING, VALVE This part replaces 98-9390. Price: $9.43 |
| 17 |
532138860 |
SIDE BAFFLE Price: $3.16 |
| 18 |
532133190 |
DISCHARGE BAFFLE This part replaces 532125376. Price: $4.99 |
| 18 |
98-9497 |
CAP-VALVE Price: $8.36 |
| 19 |
98-9506 |
STUD Price: $5.98 |
| 20 |
120-2564 |
VALVE-EXHAUST This part replaces 98-9495. Price: $34.21 |
| 20 |
532128415 |
RIVET BLIND Price: $3.99 |
| 21 |
532054583 |
SCREW Price: $4.99 |
| 22 |
532156380 |
BACK PLATE This part replaces 532139734. Price: $8.99 |
| 23 |
532048283 |
KIT.SHIELD.DEBRIS.21.RWGD.EZ This part replaces 532134612. Price: $12.99 |
| 24 |
532133040 |
REAR BAFFLE This part replaces 532125348. Price: $4.99 |
| 26 |
532413160 |
SKIRT.REAR.22RD/SD.FO/VE This part replaces 532140540. Price: $11.99 |
| 27 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 532150078. Price: $4.99 |
| 29 |
532088652 |
HINGE SCREW Price: $3.99 |
| 30 |
596322601 |
Nuts This part replaces 532751592. Price: $2.99 |
| 32 |
532153029 |
HANDLE BRACKET ASSEMBLY-RIGHT Price: $2.42 |
| 33 |
532153030 |
HANDLE BRACKET ASSEMBLY - LEFT Price: $2.99 |
| 34 |
532142842 |
WHEEL ADJ BRKT RF-LR Price: $3.52 |
| 35 |
532401629 |
SPACER.HEIGHT.ADJUSTER This part replaces 532146630. Price: $3.99 |
| 37 |
532125066 |
SELECTOR SPRING Price: $4.99 |
| 38 |
532701037 |
SELECTOR KNOB Price: $4.99 |
| 39 |
532145937 |
AXLE ARM This part replaces 532151254. Price: $3.99 |
| 40 |
532062335 |
WASHER.BELLEVILLE (3 2 LB) Price: $7.99 |
| 41 |
532174719 |
BOLT SHOULDER 3/8 -16X1 This part replaces 532142748. Price: $7.99 |
| 42 |
532750550 |
WHEEL.8X2.PR.LP.RAD.GREY Price: $27.99 |
| 43 |
532428450 |
KIT.O-RING/WASHER This part replaces 532057143. Price: $3.99 |
| 44 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532083923. Price: $3.99 |
| 45 |
532157008 |
HUBCAP.8".GREY Price: $3.99 |
| 46 |
532142843 |
WHEEL ADJ BRKT RR-LF Price: $3.52 |
| 47 |
532150406 |
BOLT 3/8-16X1-1/8 Price: $4.99 |
| 48 |
532125076 |
Engine Washer Price: Call Us |
| 50 |
581579101 |
DECAL.CUTFINGER.CE.02 This part replaces 532107339. Price: $3.99 |
| 54 |
532170557 |
KIT.BAFFLE.FRT.22RD.FO.PU/FWGD This part replaces 532125345. Price: $27.99 |
| 56 |
532851084 |
SCREW, HEX HD 3/8-24 X 1-3/8 Price: $2.50 |
| 57 |
596238701 |
Washers This part replaces 532850263. Price: $3.99 |
| 58 |
532851074 |
WASHER,HARDEN Price: $3.99 |
| 59 |
532141114 |
BLADE 22" Price: $24.99 |
| 60 |
532851514 |
BLADE ADAPTOR Price: $7.99 |
| 61 |
532088614 |
CATCHER.FRAME.WALK Price: $44.99 |
| 62 |
532051793 |
HAIRPIN COTTER Price: $5.99 |
| 64 |
532151023 |
KIT.DOOR.REAR.22.STEEL.BLACK Price: $22.99 |
| 68 |
532083816 |
SCREW.HEX.HEAD.WASHER.10-16 Price: $4.99 |
| 69 |
532087677 |
HI PRO KEY PM WSL Price: $3.99 |
| 70 |
532059708 |
SCREW Price: $4.99 |
| 71 |
532084596 |
ENGINE.PULLEY.FWG Price: $27.99 |
| 73 |
532150050 |
SCREW.HXTAP.10-24 Price: $2.99 |
| 74 |
532166649 |
PLUG.MULCH.22RD This part replaces 532125368. Price: $27.99 |
| 75 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 532063601. Price: $1.99 |
| 77 |
532150654 |
COMBI-CUT DOOR Price: $13.99 |
| 78 |
532147286 |
ROD.HINGE.COMBI-C Price: $6.99 |
| 79 |
532152186 |
SPRING HINGE Price: $4.99 |
| 80 |
532147775 |
BRACKET.HINGE ASM.W/FIN Price: $3.99 |
| 82 |
532145285 |
CLIP-ON DISCHARGE DEFLECTOR This part replaces 532150653. Price: $8.99 |
| 532157012 |
56SF |
OPER MANUAL NLA Price: $5.06 532157012 |
