Carburetor Parts
Parts (69)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 49-2640 | SEAL-SHAFT Price: $14.83 |
| 2 | 56-6710 | O-RING Price: $3.82 |
| 3 | 60-5890 | WASHER Price: $4.68 |
| 4 | 94-3011 | PLUG Price: $14.66 |
| 5 | 120-7576 | WASHER-SEALING This part replaces 94-8160. Price: $27.14 |
| 6 | 95-4362 | PLATE-FRONT Price: $403.21 |
| 7 | 95-4363 | BACKPLATE Price: $310.18 |
| 8 | 95-4364 | BODY Price: $106.81 |
| 9 | 95-4365 | GEAR-DRIVE Price: $341.00 |
| 10 | 95-4366 | GEAR-IDLER Price: $127.03 |
| 11 | 95-4368 | PLATE-WEAR This part replaces 95-4367. Price: $109.69 |
| 12 | 95-4368 | PLATE-WEAR Price: $109.69 |
| 13 | 95-4368 | PLATE-WEAR This part replaces 95-4369. Price: $109.69 |
| 14 | 95-4370 | SCREW-CAP Price: $18.02 |
| 15 | 95-4371 | PLATE-ADAPTOR Price: $448.65 |
| 16 | 95-4372 | KEY Price: $20.53 |
| 17 | 95-4373 | GEAR-FIT, SLIP Price: $69.20 |
| 501466901 | 501466901 | SCREW Price: $7.99 |
| 501468401 | 501468401 | SPRING Price: $6.99 |
| 501468501 | 501468501 | BALL Price: $6.99 |
| 501468701 | 501468701 | SCREW Price: $6.99 |
| 501666101 | 501666101 | FUEL INLET SCREEN Price: $12.99 |
| 501666901 | 501666901 | GASKET, PUMP SIDE Price: $14.99 |
| 501667701 | 501667701 | SPRING Price: $7.99 |
| 501667801 | 530035121 | IDLE SCREW SPRING This part replaces 501667801. Price: $2.99 |
| 501668301 | 501668301 | LEVER Price: $14.99 |
| 502254701 | 502254701 | PUMP DIAPHRAGM Price: $19.99 |
| 503122601 | 503122601 | WASHER Price: $0.40 |
| 503281811 | 503281811 | CARBURETOR HD-30 WALBRO Price: $148.99 |
| 503563401 | 503563401 | INLET NEEDLE Price: $14.99 |
| 503564501 | 503564501 | WASHER Price: $32.99 |
| 503574201 | 503574201 | WELCH PLUG Price: $6.99 |
| 503799601 | 503799601 | LEVER Price: $3.99 |
| 503799801 | 503799801 | COVER Price: $5.99 |
| 503799901 | 503799901 | SHAFT Price: $11.99 |
| 503800001 | 503800001 | THROTTLE FLAP Price: $4.99 |
| 503800801 | 503800801 | SCREW Price: $19.99 |
| 503800901 | 503800901 | SPRING Price: $8.99 |
| 503801401 | 503801401 | TUBE Price: $3.99 |
| 503855801 | 503855801 | CHOKE FLAP Price: $3.99 |
| 503855901 | 503855901 | RP NIPPLE Price: $17.99 |
| 503868301 | 503868301 | O-RING Price: $1.00 |
| 503868401 | 503868401 | Washer Price: $0.39 |
| 503868501 | 503868501 | O-Ring Price: $0.36 |
| 503913601 | 503913601 | Clip Price: $2.12 |
| 503913901 | 503913901 | LIMITER CAP Price: $2.99 |
| 503914001 | 503914001 | LIMITER CAP Price: $4.99 |
| 503915401 | 503915401 | CAP Price: $7.99 |
| 503943601 | 503943601 | JET Price: $4.99 |
| 503943701 | 503943701 | SPRING Price: $0.56 |
| 503944001 | 503944001 | JET Price: $9.99 |
| 504130905 | 504130905 | GASKET Price: $2.99 |
| 505316717 | 505316717 | SCREW Price: $6.99 |
| 505316748 | 505316748 | SPACER Price: $1.99 |
| 505520125 | 505520125 | FULCRUM PIN Price: $6.99 |
| 530035015 | 530035015 | SCREW SHUTTERS Price: $2.99 |
| 537001501 | 537001501 | COVER Price: $3.99 |
| 537001801 | 537001801 | GASKET Price: $4.99 |
| 537001901 | 537001901 | DIAPHRAGM Price: $8.99 |
| 537002001 | 537002001 | SCREW Price: $0.39 |
| 537002301 | 537002301 | NEEDLE HIGH SPEED Price: $9.99 |
| 537002401 | 537002401 | LOW SPEED NEEDLE Price: $4.99 |
| 537002601 | 537002601 | BRACKET Price: $2.23 |
| 537002701 | 537002701 | PLATE Price: $5.99 |
| 537018901 | 537018901 | LEVER Price: $3.99 |
| 537019001 | 537019001 | SPRING Price: $8.99 |
| 537047801 | 537047801 | GASKET SET Price: $5.99 |
| 537181201 | 537181201 | CHOKE SHAFT Price: $9.99 |
| 537181301 | 537181301 | WASHER Price: $2.99 |
