| Ref | Part Number | Description |
|---|
| 2 |
52-2860 |
WASHER Price: $0.84 |
| 3 |
109-9158 |
IDLER ARM ASM This part replaces 109-5276. Price: $120.52 |
| 4 |
116-6317 |
SPRING-EXTENSION This part replaces 103-3330. Price: $26.99 |
| 5 |
1-603384 |
BUSHING-PIVOT, IDLER Price: $8.74 |
| 6 |
3231-11 |
SCREW-CARR Price: $4.09 |
| 7 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 8 |
1-413113 |
BUSHING-IDLER Price: $3.28 |
| 9 |
109-8891 |
SHEAVE AND BEARING ASM This part replaces 109-3658. Price: $23.06 |
| 10 |
3231-31 |
SCREW-CARR Price: $1.29 |
| 11 |
109-6572 |
BUSHING-IDLER Price: $9.85 |
| 12 |
132-4718 |
PULLEY-IDLER, FLAT This part replaces 1-603843. Price: $22.69 |
| 13 |
109-6868 |
BOLT-CARRIAGE Price: $2.79 |
| 14 |
109-3723-01 |
STRUT-DECK Price: $132.38 |
| 15 |
103-3900 |
SPACER-STRUT Price: $5.32 |
| 16 |
3231-28 |
SCREW-CARR Price: $1.92 |
| 17 |
109-3449 |
SHIELD-BELT Price: $20.98 |
| 18 |
3230-23 |
SCREW-CARR Price: $0.89 |
| 19 |
78-7170 |
RING-RETAINING Price: $0.90 |
| 20 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 21 |
109-5498-03 |
BAFFLE-DISCHARGE Price: $17.59 |
| 22 |
322-2 |
SCREW-HH Price: $0.69 |
| 23 |
110-6691 |
DECAL-DANGER Price: $2.93 |
| 24 |
109-6459 |
DECAL-WARNING, BELT SHIELD Price: $2.79 |
| 26 |
109-6035 |
DECAL-ROUTING, BELT Price: $4.38 |
| 27 |
109-6036 |
DECAL-ROLLER, ANTI-SCALP Price: $6.19 |
| 28 |
93-7009 |
DECAL-DANGER Price: $6.79 |
