| Ref | Part Number | Description |
|---|
| 1 |
603-04283 |
UPPER ROPS ASSEMBLY Not Available This part replaces 603-0716. Price: |
| 1 |
76-4950 |
NUT-FLANGE Price: $12.75 |
| 2 |
603-0717 |
ROPS ASSEMBLY-UPPER FOLDABLE Not Available Price: |
| 2 |
76-4940 |
PULLEY-PUMP Price: $196.38 |
| 3 |
603-0858 |
ROPS MOUNTING ASSEMBLY (RH) Not Available Price: |
| 3 |
94-3220 |
DISCONTINUED Price: Call Us |
| 4 |
603-0861 |
MOUNTING ASSEMBLY (LH) ROPS Not Available Price: |
| 4 |
94-3225 |
SCREW-HH Price: $2.10 |
| 5 |
710-0376 |
Screw, Hex Cap, 5/16-18 x 1.0 GR5 Price: $3.66 |
| 5 |
76-4930 |
WASHER Price: $0.93 |
| 6 |
710-0515 |
Screw, Hex Cap, 1/2-20 x 3.5 GR5 Price: $10.13 |
| 6 |
94-3165 |
NUT-HEX Price: $2.34 |
| 7 |
710-3032 |
Screw, Hex Cap, 1/2-13 x 1.25 GR5 Price: $5.66 |
| 7 |
74-8610 |
PIN-SPRING Price: $2.73 |
| 8 |
710-3131 |
Screw, Hex Cap, 1/2-13 x 1.0 GR5 Price: $4.69 |
| 8 |
74-8630 |
BUSHING-FLANGE Price: $6.93 |
| 9 |
711-1610 |
CLEVIS PIN .50 x 3.5 Not Available Price: |
| 9 |
94-3224 |
WASHER-PLATE Price: $0.57 |
| 10 |
712-3046 |
Nut, Hex Jam, 5/16-18 Price: $6.06 |
| 10 |
94-3164 |
WASHER-SPRING Price: $1.20 |
| 11 |
912-3058 |
Hex Lock Nut, 1/2-20 This part replaces 712-3058. Price: $4.92 |
| 11 |
94-3221 |
SCREW-HH Price: $9.64 |
| 12 |
74-8650 |
PACER Price: $2.36 |
| 12 |
912-3066 |
Hex Nut, 1/2-20 This part replaces 712-3066. Price: $6.01 |
| 13 |
74-8670 |
FUEL INLET ASM Price: $66.08 |
| 13 |
914-3003 |
INTERNAL COTTER PIN Not Available This part replaces 714-3003. Price: |
| 14 |
725-3280 |
HAZARD LAMP ASSEMBLY Not Available Price: |
| 14 |
74-8680 |
GASKET Price: $5.51 |
| 15 |
48-7880 |
NUT-HEX This part replaces 94-3251. Price: $0.25 |
| 15 |
736-0921 |
Washer, Lock, 1/2 Price: $3.90 |
| 16 |
3255-10 |
WASHER-LOCK / EXT This part replaces 74-8710. Price: $0.25 |
| 17 |
98-8806 |
SOLENOID VALVE This part replaces 93-5856. Price: $251.17 |
| 18 |
94-3274 |
O-RING Price: $4.19 |
| 19 |
94-3219 |
DISCONTINUED Price: Call Us |
| 20 |
94-3222 |
KEY Price: $5.03 |
| 21 |
74-8870 |
DISCONTINUED Price: Call Us |
| 22 |
94-3249 |
TUBE-OUTLET Price: $52.36 |
| 23 |
94-3250 |
SCREW Price: $78.40 |
| 24 |
94-3161 |
DISCONTINUED Price: Call Us |
| 25 |
94-3223 |
SCREW-HH Price: $11.01 |
| 26 |
76-4910 |
STUD Price: $1.24 |
| 27 |
94-9969 |
SCREW-CONNECTION Price: $16.10 |
| 503214425 |
503214425 |
SCREW Price: $3.99 |
| 503906101 |
503906101 |
MUFFLER COVER Price: $22.99 |
| 503979901 |
503979901 |
PROTECTOR Price: $37.99 |
