| Ref | Part Number | Description |
|---|
| 1 |
02003505 |
SCREW-FLAT HEAD CA Price: $2.65 |
| 2 |
02003749 |
PLATE-LIFT WEAR Price: $29.56 |
| 3 |
980-00537 |
LEFT HAND STEERING GEAR ASSEMBLY Price: $130.55 |
| 4 |
980-00538 |
RIGHT HAND STEERING GEAR ASSEMBLY Price: $130.55 |
| 6 |
680-01674 |
AXLE ASSEMBLY Price: $539.95 |
| 12 |
703-10546 |
LOWER GEAR SPACER PLATE Price: $16.77 |
| 15 |
710-0395 |
HEX SCREW 5/16-18 x 2.25 GR5 Price: $4.08 |
| 16 |
710-05189C |
HEX HEAD SCREW (1-14 x 7 GR5) Price: $52.11 |
| 17 |
710-05388 |
SCREW 3/4-16 x 9.00 GR5 Price: $28.22 |
| 18 |
710-1194 |
SCREW #10-24 x 1.00 GR5.1 Price: $3.33 |
| 19 |
710-1880 |
SCREW 5/16-18 x .750 Price: $4.02 |
| 20 |
710-3005 |
SCREW 3/8-16 x 1.25 GR5 Price: $3.61 |
| 21 |
710-3032 |
SCREW 1/2-13 x 1.25 GR5 Price: $5.66 |
| 22 |
711-04585 |
CLEVIS PIN .25 x 1.00 Price: $6.06 |
| 23 |
712-0161 |
HEX NUT Price: $4.02 |
| 24 |
712-04065 |
NUT Price: $3.68 |
| 25 |
712-04150 |
NUT Price: $3.74 |
| 26 |
712-04338A |
FLANGE LOCK NUT 3/4-16 TOP LOCK Price: $7.02 |
| 27 |
712-05159 |
CASTLE NUT 1.0-14 GR5 Price: $27.62 |
| 28 |
712-3004A |
HEX FLANGE NUT Price: $3.49 |
| 29 |
912-3027 |
LOCK NUT 1/4 Price: $3.85 |
| 31 |
714-04040 |
BOW TIE COTTER PIN 1/4-5/16 Price: $1.28 |
| 32 |
917-04822 |
STEERING GEAR YOKE Price: $62.99 |
| 33 |
721-04953 |
AXLE CAP 2.5" Price: $17.65 |
| 34 |
726-04072A |
RATCHET CLIP Price: $3.15 |
| 35 |
735-0246A |
END PLUG Price: $5.01 |
| 36 |
735-05159 |
AXIAL BUMPER Price: $43.32 |
| 37 |
736-0253 |
Bell-Wash. .345" I.D. x .88" This part replaces 936-0253. Price: $3.58 |
| 38 |
736-05033A |
WAVE WASHER Price: $4.19 |
| 39 |
736-05782 |
FLAT WASHER 1.005 x 1.570 x 0.125 Price: $4.69 |
| 40 |
738-04149 |
SCREW Price: $3.89 |
| 41 |
741-05950 |
BALL BEARING 30x52x20 Price: $39.53 |
| 42 |
741-0941A |
BALL BEARING (1.0 x 52 x 15) Price: $15.71 |
| 43 |
750-05297 |
SPACER Price: $3.74 |
| 44 |
750-05600 |
SPACER Price: $6.49 |
