| Ref | Part Number | Description |
|---|
| 1 |
49-5430 |
ROD-CONTROL Price: $75.94 |
| 1 |
532439740 |
WHEEL.STEER.HUSQ.SR.498.OVMLD This part replaces 532416480. Price: $69.99 |
| 2 |
3220-2 |
NUT-JAM Price: $0.50 |
| 2 |
532413591 |
AXLE.SVC.ASM CAST IRON.TEX This part replaces 532195968. Price: $119.99 |
| 3 |
282-2 |
YOKE Price: $30.04 |
| 4 |
283-61 |
PIN-YOKE Price: $1.56 |
| 4 |
596873601 |
SPINDLE.WELDED.LH.15"TEX.X431 This part replaces 532403087. Price: $14.99 |
| 5 |
44-0870 |
CAM SHAFT ASM Price: $213.32 |
| 5 |
538691201 |
SPINDLE.WLDMT.RH.15INTIRE.X431 This part replaces 532403088. Price: $19.99 |
| 6 |
3234-1 |
SCREW-HHF Price: $1.62 |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 7 |
27-2320 |
BEARING Price: $15.22 |
| 7 |
532121748 |
WASHER Price: $3.99 |
| 8 |
283-57 |
PIN-CLEVIS Price: $1.15 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
49-6220 |
BRACKET-ARM, CONTROL Price: $28.06 |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 10 |
256-251 |
BUSHING Price: $2.46 |
| 11 |
233-48 |
KNOB Price: $10.92 |
| 12 |
93-9934 |
TRACTION HANDLE ASM Price: $86.68 |
| 13 |
3272-4 |
PIN-COTTER Price: $0.25 |
| 13 |
532121749 |
WASHER Price: $2.99 |
| 14 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 14 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 15 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 16 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 16 |
587738904 |
KIT.SRVC.STEERINGSHAFT.2HISHFT This part replaces 532408219. Price: $34.99 |
| 17 |
57-6220 |
LINK-CONNECTING Price: $6.01 |
| 18 |
3254-6 |
WASHER-LOCK, INTERNAL Price: $0.31 |
| 19 |
3211-2 |
SCREW-HH Price: $2.17 |
| 19 |
531169101 |
SERVICE KIT PLATE PLATE.STEER. This part replaces 532194729. Price: $19.99 |
| 20 |
HY2562 |
DISCONTINUED This part replaces 256-2. Price: Call Us |
| 21 |
49-6260 |
PIVOT ASM Price: $79.73 |
| 21 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 532186737. Price: $7.99 |
| 22 |
3296-4 |
NUT-LOCK Price: $0.25 |
| 22 |
587738901 |
KIT.SRVC.STEERINGSHAFT.LWRBSHG This part replaces 532194845. Price: $14.99 |
| 23 |
74-9110 |
PAD-PEDAL, REVERSE Price: $13.49 |
| 24 |
83-0540-01 |
TRACTION PEDAL ASM This part replaces 83-0540. Price: $70.97 |
| 25 |
74-9100 |
PAD-PEDAL, FORWARD Price: $27.08 |
| 26 |
256-155 |
BUSHING-FLANGE Price: $1.76 |
| 26 |
532439743 |
INSERT.CAP.WHL.STRG.HUSQ.PREM This part replaces 532415987. Price: $8.99 |
| 27 |
32128-20 |
NUT-HF Price: $0.99 |
| 28 |
32121-45 |
PIN-SPRING Price: $0.27 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 29 |
83-0630 |
ARM-PIVOT, TRACTION Price: $25.47 |
| 30 |
2411-42 |
JOINT-BALL, LH Price: $19.07 |
| 31 |
3220-20 |
NUT-JAM Price: $0.92 |
| 32 |
83-0580 |
ROD-CONTROL, TRACTION Price: $53.72 |
| 33 |
2411-43 |
JOINT-BALL Price: $21.40 |
| 34 |
17-9420 |
SCREW-HANDLE Price: $3.49 |
| 35 |
49-6250 |
BRACKET-PIVOT Price: $22.09 |
| 35 |
532194732 |
GEAR.SECTOR.PLATE.DDL. Price: $27.99 |
| 36 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 37 |
49-6290 |
PIVOT SHAFT ASM Price: $25.43 |
| 38 |
12-3270 |
SCREW Price: $3.09 |
| 39 |
32121-6 |
PIN-ROLL, SLOTTED Price: $0.28 |
| 40 |
47-5320-01 |
LEVER This part replaces 47-5320. Price: $84.02 |
| 41 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 42 |
49-6440-03 |
PEDAL-FORWARD This part replaces 49-6440. Price: $84.90 |
| 43 |
32121-51 |
PIN-ROLL Price: $0.70 |
| 44 |
93-9936 |
BRACKET-RETURN, TRACTION Price: $6.79 |
| 45 |
819183812 |
WASHER 9/16"ID, 2 3/8"OD Price: $7.99 |
| 45 |
93-9937 |
TRACTION CABLE ASM Price: $28.43 |
| 46 |
283-62 |
PIN-CLEVIS Price: $0.61 |
| 47 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 51 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 53 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 57 |
532197246 |
BRKT.UPSTOP.GT/LT.TEX Price: $5.99 |
| 58 |
532194747 |
BOLT.SHOULDER.SECTOR.P Price: $7.99 |
| 59 |
532194748 |
WASHER.THURST.SECTOR.S Price: $4.99 |
| 60 |
583612801 |
NUT.FLANGE.LOCK.5/8-11 This part replaces 873971000. Price: $3.99 |
| 61 |
597047802 |
Links This part replaces 532194740. Price: $11.99 |
| 62 |
597047902 |
Links This part replaces 532194741. Price: $11.99 |
| 63 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 64 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $4.99 |
| 66 |
871020748 |
BOLT HEX FGHD 7/16-14 X 3 SERR Price: $4.99 |
| 67 |
529496302 |
BUSHING, AXLE This part replaces 532194737. Price: $2.99 |
| 68 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 69 |
532199162 |
WASHER.1.5X.505X.118 Price: $4.99 |
