| Ref | Part Number | Description |
|---|
| 1 |
532429673 |
RB KIT.CNTL.CHUTE.ROTA.GRY.SNO This part replaces 532428274. Price: $139.99 |
| 1 |
603-0860-0637 |
UPPER SEAT PIVOT BRACKET (POWDER BLACK) Not Available Price: |
| 1 |
94-3181 |
DISCONTINUED Price: Call Us |
| 2 |
603-0866 |
SEAT TRACK ASSEMBLY W/LATCH Not Available Price: |
| 2 |
817501010 |
SCREW #10-24 X 5/8 Price: $4.99 |
| 2 |
94-3182 |
DISCONTINUED Price: Call Us |
| 3 |
703-3208 |
Track Ass'y., Seat w/o Latch Price: $64.46 |
| 3 |
93-9176 |
DIPSTICK Price: $75.61 |
| 4 |
703-3681A |
SEAT PIVOT BRACKET Not Available Price: |
| 4 |
94-3184 |
HOSE-CRANK CASE Price: $27.83 |
| 5 |
703-3711 |
SEAT BELT MOUNTING BRACKET Not Available Price: |
| 6 |
710-0376 |
Screw, Hex Cap, 5/16-18 x 1.0 GR5 Price: $3.66 |
| 7 |
710-0451 |
Screw, Carriage, 5/16-18 x .75 Price: $3.53 |
| 8 |
2412-129 |
CLAMP-HOSE Price: $2.10 |
| 8 |
710-0528 |
Screw, Hex Cap, 5/16-18 x 1.25 GR5 Price: $3.90 |
| 9 |
710-0759 |
SCREW 5/16-18 x .625 GR5 Not Available Price: |
| 10 |
710-3250 |
SCREW 5/16-18X1.5 Not Available Price: |
| 11 |
712-3004A |
HEX FLANGE NUT Price: $3.49 |
| 11 |
74-7770 |
HOSE-CASE, CRANK Price: $26.81 |
| 12 |
74-7780 |
GASKET Price: $3.22 |
| 12 |
925-3167 |
Switch, Snap Mount Normally Open (Black) This part replaces 725-3167. Price: $13.53 |
| 13 |
732-3080A |
Spring, Compression, 1.28 x 3.5 Price: $12.91 |
| 13 |
74-7790 |
DISCONTINUED Price: Call Us |
| 14 |
738-0140 |
Screw, Shoulder, .435 x .178-5/16-18 Price: $4.93 |
| 14 |
74-7800 |
PIN-SPRING This part replaces 94-3102. Price: $5.96 |
| 15 |
74-7810 |
GASKET-PLATE Price: $5.88 |
| 15 |
750-0258 |
Spacer, .315 x .750 x .375 Price: $10.00 |
| 16 |
74-7820 |
PLATE Price: $5.59 |
| 16 |
957-04006 |
EXTRA HIGH BACK SEAT Not Available This part replaces 757-04006. Price: |
| 17 |
94-3112 |
DISCONTINUED Price: Call Us |
| 18 |
74-7840 |
PLUG Price: $2.02 |
| 19 |
74-7320 |
GASKET-DRAIN PLUG, OIL Price: $3.77 |
| 20 |
74-7310 |
PLUG-DRAIN, OIL Price: $5.30 |
| 21 |
74-7380 |
DISCONTINUED Price: Call Us |
| 22 |
94-3111 |
PIN Price: $0.92 |
| 23 |
74-7300 |
OIL SUMP ASM Price: $237.10 |
| 24 |
74-7850 |
GASKET This part replaces 94-3107. Price: $5.41 |
| 25 |
74-7330 |
SCREW-HH Price: $8.91 |
| 26 |
77-3790 |
DISCONTINUED Price: Call Us |
| 27 |
74-7930 |
CAPSCREW-BEARING Price: $9.61 |
| 28 |
74-7940 |
BUSHING-SPRING Price: $2.40 |
| 29 |
74-7950 |
SCREW-PLATE Price: $12.51 |
| 30 |
74-7960 |
STUD-FILTER Price: $11.34 |
| 31 |
108-3837 |
FILTER-OIL This part replaces 74-7970. Price: $9.25 |
| 32 |
94-3180 |
SWITCH-PRESSURE Price: $49.15 |
| 33 |
74-8250 |
PIN This part replaces 74-7990. Price: $0.97 |
| 34 |
74-8000 |
PLUG Price: $3.44 |
| 35 |
74-8010 |
TUBE Price: $30.39 |
| 36 |
94-3100 |
BLOCK-CYLINDER Price: $6,955.88 |
| 37 |
74-8030 |
PIN-SPRING Price: $7.00 |
| 38 |
74-8040 |
PLUG This part replaces 94-3105. Price: $3.67 |
| 39 |
94-3183 |
DISCONTINUED Price: Call Us |
| 40 |
94-3186 |
O-RING Price: $3.33 |
| 42 |
94-3106 |
GASKET Price: $4.03 |
| 43 |
94-3104 |
PLUG-THREADED Price: $7.37 |
| 44 |
94-3103 |
PLUG-THREADED Price: $5.27 |
| 45 |
94-3110 |
STUD Price: $12.56 |
| 46 |
94-3190 |
DISCONTINUED Price: Call Us |
| 47 |
94-3192 |
HOSE-MANIFOLD Price: $95.23 |
| 48 |
94-3191 |
HOSE-VALVE, PCV Price: $34.83 |
| 777D01782 |
LABEL-MADE |
IN USA Not Available Price: 777D01782 |
| 777D04541 |
LABEL-SEAT |
BACK Not Available Price: 777D04541 |
