| Ref | Part Number | Description |
|---|
| 1 |
532166627 |
STEERING WHEEL Price: $64.99 |
| 2 |
532178557 |
AXLE.FRONT.CAST.MACHINE.W/ZERK Price: $179.99 |
| 3 |
532183226 |
FITTING.GREASE.TAPERED Price: $4.99 |
| 4 |
532161849 |
SPINDLE ASSY LH Price: $27.99 |
| 5 |
532161848 |
SPINDLE ASM RH Price: $24.99 |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 7 |
532121748 |
WASHER Price: $3.99 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 10 |
131-6557 |
ALTERNATOR ASM This part replaces 98-9474. Price: $443.05 |
| 10 |
874781044 |
Bolt, Hex 5/8 -11 x 2 - 3/4 Gr. 5 Price: $3.99 |
| 11 |
532136518 |
TUBE, PIVOT AXLE Price: $7.99 |
| 12 |
583612401 |
LOCKNUT M This part replaces 873901000. Price: $2.99 |
| 13 |
532121749 |
WASHER Price: $2.99 |
| 14 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 16 |
532186814 |
SHAFT ASM, STEERING Price: $79.99 |
| 18 |
532175572 |
DRAGLINK, BALL JOINT (3SPG1401 Price: $64.99 |
| 19 |
532156011 |
SUPPORT ASM., STEERING VGT Price: $22.99 |
| 20 |
532163887 |
BOOT.STEERING.BLACK.STEALTH This part replaces 532177592. Price: $5.99 |
| 20 |
98-9453 |
PULLEY-DYNAMO Price: $138.04 |
| 21 |
532159945 |
STEERING WHEEL ADAPTOR Price: $6.99 |
| 22 |
532155108 |
KIT.BUSHING.STEERING. This part replaces 532155105. Price: $6.99 |
| 23 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 26 |
532172092 |
INSERT.CAP.STRG.WH (3 2) (L B) This part replaces 532166626. Price: $12.99 |
| 27 |
532003366 |
BEARING.STEERING.COLUMN This part replaces 532124937. Price: $3.99 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 29 |
532104239 |
BEARING-FLANGE GT Price: $9.99 |
| 30 |
98-7708 |
NUT Price: $7.76 |
| 31 |
532138136 |
BUSHING.NYLINER. Price: $8.99 |
| 32 |
819111610 |
WASHER Price: $4.99 |
| 33 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 34 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 874780512. Price: $3.99 |
| 35 |
531165701 |
SERVICE KIT GEAR.ASM.SECT This part replaces 532138059. Price: $49.99 |
| 36 |
532186799 |
ROD.TIE.NON-ADJUSTABLE Price: $59.99 |
| 40 |
98-7709 |
COLLAR Price: $8.79 |
| 41 |
532155246 |
BRACKET INTERLOCK Price: $4.99 |
| 42 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 44 |
532160135 |
EXT.STEERING.PREM.BLACK This part replaces 532177593. Price: $4.99 |
| 45 |
819182411 |
Washer 9/16 ID x 1 1/2 OD 11 Ga. Zin Price: $4.99 |
| 46 |
819131610 |
WASHER PM Price: $4.99 |
| 47 |
529846001 |
SERVICE.KIT BRKT.ASM.IDLER.STA This part replaces 532179471. Price: $7.99 |
| 49 |
596481401 |
Pulleys This part replaces 532175820. Price: $22.99 |
| 50 |
107-0136 |
ROTOR ASM Price: $268.62 |
| 50 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 51 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 52 |
532175553 |
CLIP.STEERING Price: $9.99 |
| 53 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 60 |
98-7711 |
COVER-BEARING Price: $7.32 |
| 70 |
107-0138 |
BEARING-BALL Price: $48.37 |
| 80 |
98-7713 |
WASHER-THRUST Price: $4.49 |
| 90 |
107-0139 |
DRIVE END FRAME ASM Price: $446.71 |
| 100 |
98-7715 |
PLATE-RETAINER Price: $9.38 |
| 110 |
98-7716 |
SCREW-HEAD, ROUND Price: $0.91 |
| 120 |
98-7717 |
BOLT-THROUGH Price: $9.75 |
| 130 |
133-2811 |
BEARING Price: $46.67 |
| 140 |
107-9087 |
FRAME-END Price: $183.56 |
| 150 |
107-0140 |
COVER-END Price: $34.95 |
| 160 |
98-7721 |
RECTIFIER ASM Price: $486.45 |
| 170 |
98-7722 |
BUSHING-INSULATION Price: $28.44 |
| 180 |
107-0141 |
BRUSH HOLDER ASM Price: $107.10 |
| 190 |
98-7724 |
BRUSH Price: $12.41 |
| 200 |
98-7725 |
SPRING-BRUSH Price: $4.32 |
| 210 |
98-7726 |
SCREW-HEAD, ROUND Price: $0.42 |
| 220 |
98-7727 |
SCREW-HEAD, ROUND Price: $0.94 |
| 230 |
98-7728 |
SCREW-HEAD, ROUND Price: $0.70 |
| 240 |
98-7729 |
BOLT Price: $2.35 |
| 250 |
98-7730 |
NUT Price: $1.31 |
| 260 |
98-7731 |
BOLT Price: $3.94 |
| 270 |
98-7732 |
NUT Price: $1.45 |
