| Ref | Part Number | Description |
|---|
| 1 |
340-157 |
FITTING-HYD, TEE Price: $49.83 |
| 1 |
4459J |
SUB= 6554J Price: Call Us |
| 1 |
603-04062-0637 |
CYLINDER LIFT ARM PIN Not Available Price: |
| 2 |
132673 |
PIN.CLEVIS.SHEAR Price: Call Us |
| 2 |
32121-77 |
PIN-ROLL Price: $1.29 |
| 2 |
903-0964 |
CENTER LINK ASSEMBLY- Not Available This part replaces 603-0964. Price: |
| 3 |
340-16 |
FITTING-HYD, 90 DEG Price: $54.23 |
| 3 |
603-0965 |
LINK ASSEMBLY-LOWER HI Not Available Price: |
| 4 |
105-7377 |
PUMP ASM Price: Call Us |
| 4 |
3146R |
RETAINER.SPRING Price: Call Us |
| 4 |
903-0970 |
FIXED LIFT LINK ASSEMBLY Not Available This part replaces 603-0970. Price: |
| 5 |
132727 |
HUB&PLATE ASM LH Price: Call Us |
| 5 |
603-0971A-0637 |
HITCH BRACKET ASSEMBLY MOUNTING (POWDER BLACK) Not Available This part replaces 603-0971-0637. Price: |
| 5 |
87-7270 |
WASHER-THRUST Price: $0.89 |
| 6 |
3213-1 |
SCREW-HH Price: $1.42 |
| 6 |
603-0972-0637 |
LIFT CYLINDER MOUNTING PIN (POWDER BLACK) Not Available Price: |
| 6 |
73610600 |
SUB= 7810H Price: Call Us |
| 7 |
100-5565 |
FITTING-STR Price: $180.09 |
| 7 |
10040600 |
Washer, Lock Hvy. Hlcl. Spr. 3/8 Price: Call Us |
| 7 |
903-0973 |
ADJUSTABLE LINK ASSEMBLY Not Available This part replaces 603-0973. Price: |
| 8 |
603-0977 |
CHECK CHAIN ASSEMBLY Not Available Price: |
| 8 |
74610616 |
BOLT Price: Call Us |
| 8 |
92-7526 |
FITTING-HYD 90 SPCL Price: $119.68 |
| 9 |
354-78 |
FITTING-STR Price: $49.33 |
| 9 |
4460J |
SUB= 6555J Price: Call Us |
| 9 |
919-3095 |
UPPER HITCH ARM (LH) Not Available This part replaces 619-3095. Price: |
| 10 |
100-5521 |
HOSE ASM Price: $132.70 |
| 10 |
132728 |
HUB&PLATE ASM RH Price: Call Us |
| 10 |
919-3096 |
UPPER HITCH ARM (RH) Not Available This part replaces 619-3096. Price: |
| 11 |
340-104 |
FITTING-HYD, TEE Price: $74.38 |
| 11 |
703-4137-0637 |
REAR PTO SHIELD Not Available Price: |
| 12 |
100-4240 |
FITTING-STR Price: $14.09 |
| 12 |
703-4143-0637 |
CHECK CHAIN BRACKET Not Available Price: |
| 13 |
710-04186 |
Screw, Hex Cap Lock, 1/2-13 x 1.25 GR5 Price: $6.17 |
| 13 |
93-2242 |
FILTER-OIL Price: $290.90 |
| 14 |
340-131 |
FITTING-HYD, 90 DEG Price: $99.83 |
| 14 |
710-0514 |
Screw, Hex Cap, 3/8-16 x 1.0 GR5 Price: $3.78 |
| 15 |
340-18 |
FITTING-HYD, 90 DEG Price: $38.93 |
| 15 |
710-0599 |
Screw, Hex Wash. Hd. Tapp 1/4-20 x .5 Price: $3.86 |
| 16 |
340-6 |
FITTING-STRAIGHT Price: $18.79 |
| 16 |
710-3168 |
Screw, Carriage, 3/8-16 x 1.0 Price: $3.61 |
| 17 |
100-5616 |
FITTING Price: $50.63 |
| 17 |
710-3296 |
Screw, Hex Cap, 1/4-20 x .75 GR5 Price: $3.85 |
| 18 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 18 |
711-0469 |
Spacer, .75 x 1.25 x .5 Price: $7.14 |
| 19 |
323-5 |
SCREW-HH Price: $0.41 |
| 19 |
711-0679A |
Pin, Clevis, 3/8 x 2.015 This part replaces 711-0599. Price: $12.40 |
| 20 |
354-79 |
CAP-DUST Price: $7.81 |
| 20 |
711-1105 |
Pin, Klik Price: $10.43 |
| 21 |
711-1733 |
CLEVIS PIN 19MM x 84MM Not Available Price: |
| 22 |
911-1743 |
HITCH LIFT ARM PIN Not Available This part replaces 711-1743. Price: |
| 23 |
911-1750 |
ROCK SHAFT Not Available This part replaces 711-1750. Price: |
| 24 |
911-1753 |
CHECK CHAIN CLEVIS Not Available This part replaces 711-1753. Price: |
| 25 |
911-1761 |
CLEVIS PIN .75 Not Available This part replaces 711-1761. Price: |
| 26 |
712-0301 |
Nut, Hex Jam, 3/4-10 GR5 Price: $7.26 |
| 27 |
912-0431 |
Nut, Hex Flange Lock, 3/8-16 This part replaces 7120431. Price: $4.29 |
| 28 |
714-0117 |
Pin, Internal Cotter Price: $3.85 |
| 29 |
714-0142 |
COTTER PIN-3/16 DIA x 1.50 Not Available Price: |
| 30 |
714-0149B |
Pin, Internal Cotter Price: $3.95 |
| 31 |
715-0121 |
Pin, Spirol, 1/4 x 2.0 Price: $5.95 |
| 32 |
916-04004 |
SNAP RING Not Available This part replaces 716-04004. Price: |
| 33 |
917-3532A |
HITCH LIFT CYLINDER Not Available This part replaces 717-3532. Price: |
| 34 |
736-0255 |
Washer, Belleville, .51 x 1.14 x .04 Price: $4.02 |
| 35 |
736-0315 |
Washer, Flat, .76 x 1.5 x .12 Price: $5.94 |
| 36 |
936-0364 |
WASHER Not Available This part replaces 736-0364. Price: |
| 37 |
937-3000 |
Grease Fitting This part replaces 7373000. Price: $4.04 |
| 38 |
738-0143 |
SHOULDER SCREW .498 DIA x .340 Price: $3.93 |
| 39 |
941-04084 |
SLEEVE BEARING 1.2 Not Available This part replaces 741-04084. Price: |
