| Ref | Part Number | Description |
|---|
| 1 |
142671 |
HOUSING UPPER TRN Price: Call Us |
| 1 |
76-5610 |
PINION-OUTPUT Price: $436.03 |
| 2 |
2274J |
SUB= 74760412 Price: Call Us |
| 3 |
134400 |
SUB= 68003 Price: Call Us |
| 3 |
76-5630 |
GEAR-SPUR Price: $109.36 |
| 4 |
76-5640 |
GASKET-CASE & COVER Price: $57.02 |
| 6 |
138235 |
KIT SHIFTER ASM Price: Call Us |
| 6 |
95-7236 |
PIN - DOWEL This part replaces 76-5660. Price: $3.56 |
| 7 |
134399 |
SHIFTER BOOT Price: Call Us |
| 7 |
76-5670 |
SEAL-OIL Price: $27.67 |
| 8 |
134791 |
SCREW TAP W/SEAL Price: Call Us |
| 8 |
76-5680 |
WASHER-THRUST Price: $13.21 |
| 8A |
76-5650 |
WASHER-THRUST Price: $4.91 |
| 9 |
138241 |
SQUARE RING Price: Call Us |
| 9 |
76-5690 |
WASHER-THRUST Price: $7.71 |
| 10 |
142672 |
SUB= 2225J Price: Call Us |
| 10 |
76-5700 |
BEARING-THRUST Price: $21.09 |
| 11 |
134793 |
ASM KIT SHIM 4689 Price: Call Us |
| 11 |
76-5710 |
PLUG-DRAIN, MAGNETIC Price: $9.38 |
| 12 |
142673 |
BEARING FLAN-DANA Price: Call Us |
| 12 |
76-5720 |
SCREW-HWHTF Price: $3.07 |
| 13 |
120415X |
WASHER T Price: Call Us |
| 14 |
142674 |
KEY WOODRUFF-DANA Price: Call Us |
| 14 |
76-6040 |
PLUG-PIPE Price: $3.65 |
| 15 |
138234 |
AS KIT INPUT SHFT Price: Call Us |
| 15 |
92-0639 |
TRANSAXLE CASE ASM Price: $1,083.47 |
| 16 |
110078X |
PINION 14T T Price: Call Us |
| 16 |
76-5760 |
TRANSAXLE COVER ASM Price: $1,125.72 |
| 17 |
92-0642 |
GEAR-OUTPUT Price: $362.07 |
| 18 |
76-5780 |
GEAR-SPUR Price: $158.15 |
| 19 |
105911X |
BEARING.FLNG.5510 Price: Call Us |
| 19 |
92-0644 |
GEAR-CLUSTER Price: $570.98 |
| 20 |
142675 |
GEAR SPUR 14 TTH Price: Call Us |
| 20 |
92-0641 |
SHAFT-COUNTER Price: $258.16 |
| 21 |
138246 |
COLLAR CLUTCH Price: Call Us |
| 21 |
92-0645 |
SHIFTER-GEAR & SHAFT Price: $633.78 |
| 22 |
138236 |
ASM KIT CLTCH KEY Price: Call Us |
| 22 |
76-5820 |
SCREW-HHF Price: $4.40 |
| 23 |
73810500 |
NUT.LOCK.5/16-24 Price: Call Us |
| 23 |
76-5830 |
BALL-STEEL Price: $3.25 |
| 24 |
142676 |
SHAFT INTERM DANA Price: Call Us |
| 24 |
95-7202 |
SPRING This part replaces 76-5840. Price: $5.26 |
| 25 |
2244J |
WOODRUFF KEY Price: Call Us |
| 25 |
76-5850 |
DISCONTINUED Price: Call Us |
| 26 |
76-5860 |
BEARING-NEEDLE Price: $48.93 |
| 27 |
120470X |
SPROCKET 18T T Price: Call Us |
| 27 |
76-5870 |
BEARING-NEEDLE Price: $46.51 |
| 28 |
110070X |
SPACER YT Price: Call Us |
| 28 |
92-0640 |
DISCONTINUED Price: Call Us |
| 29 |
142677 |
GEAR SPUR 37 TTH Price: Call Us |
| 30 |
142681 |
GEAR SPUR 35 TTH Price: Call Us |
| 30 |
76-5890 |
RING-RETAINING Price: $6.21 |
| 31 |
120405X |
SUB= 124644X Price: Call Us |
| 32 |
108980X |
GEAR 25T LT Price: Call Us |
| 33 |
120406X |
GEAR SPUR 22 TT Price: Call Us |
| 34 |
134796 |
SPUR GEAR 19T Price: Call Us |
| 35 |
76-5900 |
FORK-SHIFT Price: $38.25 |
| 36 |
2232J |
WASHER 025 Price: Call Us |
| 36 |
92-0647 |
ROD-SHIFT, HI-LOW Price: $12.09 |
| 37 |
108978X |
SPACER Price: Call Us |
| 38 |
110079X |
ASSM GEAR COMB Price: Call Us |
| 39 |
124639X |
SHAFT IDLER Price: Call Us |
| 40 |
120472X |
SPACER T Price: Call Us |
| 41 |
105928X |
SPROCKET 9T LT Price: Call Us |
| 41 |
76-5960 |
CARRIER-DIFFERENTIAL Price: $278.78 |
| 42 |
104-0195 |
BEARING-BALL, HI-CAP This part replaces 92-0646. Price: $63.13 |
| 42 |
110084X |
SUB= 167148 Price: Call Us |
| 43 |
134394 |
ASM KIT SHIM Price: Call Us |
| 43 |
76-5980 |
SCREW-HHF Price: $13.37 |
| 44 |
120473X |
SHAFT T Price: Call Us |
| 44 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 45 |
142678 |
GEAR SPUR 12 TTH Price: Call Us |
| 45 |
76-5990 |
CARRIER-DIFFERENTIAL Price: $290.15 |
| 46 |
142679 |
GEAR SPUR 15 TTH Price: Call Us |
| 47 |
120407X |
SUB= 124641X Price: Call Us |
| 49 |
120408X |
GEAR 28T T Price: Call Us |
| 49 |
76-6010 |
SPACER Price: $18.94 |
| 51 |
2226J |
WASHER 060 Price: Call Us |
| 51 |
76-6030 |
SEAL-OIL Price: $17.61 |
| 52 |
134401 |
NEOPRENE WASHER Price: Call Us |
| 52 |
76-5680 |
WASHER-THRUST Price: $13.21 |
| 53 |
2264J |
WASHER 031 Price: Call Us |
| 54 |
120474X |
SUB= 154658 Price: Call Us |
| 55 |
110081X |
GEAR 15T T Price: Call Us |
| 57 |
110071X |
SUB= 120478X Price: Call Us |
| 58 |
120952X |
SHAFT T Price: Call Us |
| 59 |
110082X |
GEAR 1ST T Price: Call Us |
| 60 |
120475X |
SUB= 154659 Price: Call Us |
| 61 |
142680 |
HOUSING LOWER TNS Price: Call Us |
| 62 |
120961X |
PUCK T Price: Call Us |
| 63 |
7294J |
BRAKE DISC. T Price: Call Us |
| 64 |
108989X |
SPACER LT Price: Call Us |
| 65 |
120953X |
SUB= 918120953X Price: Call Us |
| 66 |
120954X |
PIN T Price: Call Us |
| 67 |
134799 |
TAP SCREW Price: Call Us |
| 68 |
138244 |
SUB= 108992X Price: Call Us |
| 69 |
108996X |
WASHER LT Price: Call Us |
| 70 |
120956X |
NLA Price: Call Us |
| 72 |
120951X |
PUCK T Price: Call Us |
