| Ref | Part Number | Description |
|---|
| 1 |
108-2928-01 |
BOX ASM Price: $1,031.60 |
| 1 |
532408806 |
DECAL.ENG.BS.10.5HP.PWR.277047 Price: $1.99 |
| 2 |
3230-2 |
BOLT-CARR Price: $0.47 |
| 2 |
532431985 |
DECAL.FEND.RH/LH.SET.6S.POULAN Price: $2.99 |
| 3 |
3290-355 |
PIN-HAIR Price: $2.09 |
| 3 |
532431983 |
DECAL.HOOD.ALPHA.RH/LH.POULAN Price: $5.99 |
| 4 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 4 |
580658401 |
Price: Call Us |
| 5 |
110-1376 |
PIVOT PIN ASM Price: $30.46 |
| 5 |
581579901 |
DCL.WARNING.SPARK.IGNITION.CA Price: $1.99 |
| 6 |
119-4162 |
SCREW-CARR This part replaces 323-13. Price: $1.73 |
| 6 |
532425113 |
DECAL, WARN. DEFLECT/CTFGR This part replaces 532425112. Price: $27.99 |
| 7 |
144-7097 |
TINE-SCARIFIER This part replaces 110-0259-03. Price: $55.22 |
| 7 |
532438804 |
Price: Call Us |
| 8 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 8 |
581579001 |
DECAL.WARNING.2007.ENG/FR Price: $2.99 |
| 9 |
283-60 |
PIN-CLEVIS Price: $6.45 |
| 9 |
532431986 |
DECAL.FEND.POULAN.2010 Price: $2.99 |
| 10 |
119-4162 |
SCREW-CARR This part replaces 3231-25. Price: $1.73 |
| 10 |
581579501 |
DECAL.MOWER.WARN.KEEP.HAND.AWY Price: $2.99 |
| 11 |
23-2790-01 |
BLADE-SCRAPER Price: $323.46 |
| 11 |
532431982 |
DECAL.WHEEL.STRG.STDHRS.POULAN Price: $2.99 |
| 12 |
110-1395-03 |
TOOL BAR ASM Price: $548.35 |
| 14 |
23-2770 |
ROD-ACTUATING Price: $97.95 |
| 14 |
581580004 |
DECAL.V.BELT.30" Price: $2.99 |
| 15 |
23-2740 |
PIN-ACTUATING Price: $94.46 |
| 16 |
108-2288-01 |
SUPPORT-SPRING Price: $45.53 |
| 17 |
20-9420-01 |
COMP SPRING Price: $106.49 |
| 18 |
112-1400 |
PIVOT ASM Price: $241.88 |
| 19 |
3256-7 |
WASHER-FLAT Price: $0.75 |
| 20 |
3296-53 |
NUT-LOCK, NI Price: $1.47 |
| 20 |
532145005 |
DECAL BTRY SYMBOLS Price: $3.99 |
| 21 |
62-7400 |
DECAL Price: $24.54 |
| 22 |
323-6 |
SCREW-HH Price: $0.66 |
