| Ref | Part Number | Description |
|---|
| 1 |
108-3282 |
HOSE-FUEL This part replaces 92-7522. Price: $36.93 |
| 1 |
9858M1 |
KEY Price: Call Us |
| 2 |
66-8121 |
STANDPIPE Price: $23.18 |
| 2 |
7563R |
WASHER T Price: Call Us |
| 3 |
104-5228 |
FITTING-ELBOW, 90 DEG Price: $17.50 |
| 4 |
46-6560 |
BUSHING Price: $2.94 |
| 5 |
73680600 |
SUB= 73690600 Price: Call Us |
| 5 |
93-3102 |
CAP-FUEL Price: $24.02 |
| 6 |
105-7949 |
TANK-FUEL Price: $768.96 |
| 6 |
76020412 |
COTTER PIN Price: Call Us |
| 7 |
149176 |
SUB= 149176X431 Price: Call Us |
| 7 |
240-11 |
BUSHING-FLANGE Price: $5.32 |
| 8 |
12000034 |
KLIP RING Price: Call Us |
| 8 |
63-8410 |
WASHER Price: $1.76 |
| 9 |
140080 |
BOLT.HUB.WHL.REAR Price: Call Us |
| 9 |
33105-025 |
SCREW-HHF Price: $1.56 |
| 10 |
142509 |
BRAKE.DISC. Price: Call Us |
| 10 |
62-7650 |
GASKET Price: $4.28 |
| 11 |
136927 |
YOKE BRAKE DISC Price: Call Us |
| 11 |
63-7640 |
SENDER-FUEL Price: $94.22 |
| 12 |
3253-15 |
WASHER-LOCK Price: $1.49 |
| 13 |
139419 |
WASHER SPECIAL Price: Call Us |
| 13 |
32122-24 |
SCREW-PTH Price: $0.27 |
| 14 |
110-4102 |
HOSE-FUEL This part replaces 75-4700. Price: $39.17 |
| 14 |
138901 |
BUSHING LEVER BKT Price: Call Us |
| 15 |
19131316 |
WASHER Price: Call Us |
| 15 |
2412-108 |
CLAMP-WORM Price: $1.29 |
| 16 |
143012 |
SCREW SET 1/4-20 Price: Call Us |
| 18 |
137104 |
LEVER BRAKE GT Price: Call Us |
| 19 |
136926 |
CAM BRAKE DISC GT Price: Call Us |
| 21 |
23260412 |
SCREW FLT 1/4X28 Price: Call Us |
| 22 |
633A109 |
GEAR SHFT LVR T Price: Call Us |
| 23 |
121466X |
KNOB Price: Call Us |
| 24 |
136925 |
SUPPORT PUCK BRKE Price: Call Us |
| 25 |
136923 |
PUCK BRAKE TOP Price: Call Us |
| 26 |
137552 |
SPRING RET BRAKE Price: Call Us |
| 27 |
17490528 |
SCREW HX WASH Price: Call Us |
| 28 |
73350600 |
NUT Price: Call Us |
| 29 |
137213 |
ROD BRAKE ZINC GT Price: Call Us |
| 30 |
19131616 |
WASHER HYT Price: Call Us |
| 34 |
124236X |
CAP Price: Call Us |
| 35 |
137648 |
ROD BRAKE PART GT Price: Call Us |
| 36 |
149412 |
SPRING.GRND.DRIVE Price: Call Us |
| 37 |
121749X |
WASHER Price: Call Us |
| 38 |
150035 |
BUSHING.NYLINER Price: Call Us |
| 39 |
74321016 |
SCREW Price: Call Us |
| 40 |
5304J |
ACT-SWITCH T Price: Call Us |
| 41 |
73631000 |
SUB= 69180 Price: Call Us |
| 42 |
8883R |
PEDAL COVER T Price: Call Us |
| 46 |
145170 |
RETAINER.SPRING Price: Call Us |
| 47 |
138228 |
ROD.CLUTCH Price: Call Us |
| 48 |
72110612 |
BOLT.3/8-16X1.50 Price: Call Us |
| 50 |
131494 |
FLAT IDLER PULLEY Price: Call Us |
| 51 |
73680600 |
SUB= 73690600 Price: Call Us |
| 52 |
139123 |
PULLEY.IDLER.V.GR Price: Call Us |
| 53 |
207J |
WASHER T Price: Call Us |
| 54 |
161590 |
CLUTCH.ARM.ASM Price: Call Us |
| 56 |
137153 |
BELTV.GR.DR.83. Price: Call Us |
| 57 |
141756 |
BRACKET.ROD.SHIFT Price: Call Us |
| 59 |
122253X |
ROD SHIFT HI LO Price: Call Us |
| 60 |
122268X |
CONNECTING LINK Price: Call Us |
| 61 |
137524 |
SUB= 532137524 Price: Call Us |
| 62 |
10040700 |
LOCKWASHER Price: Call Us |
| 63 |
74760720 |
BOLT Price: Call Us |
| 64 |
154752 |
SHAFT-BRAKE/CLUTC Price: Call Us |
| 65 |
67609 |
AXLE BOLT Price: Call Us |
| 66 |
140296 |
WASHER.HARD.BLADE Price: Call Us |
| 67 |
19131312 |
WASHER Price: Call Us |
| 68 |
5142H |
ROLL PIN STD Price: Call Us |
