| Ref | Part Number | Description |
|---|
| 1 |
130-7092-03 |
TANK SADDLE ASM Price: $1,847.88 |
| 1 |
532126470 |
CLIP,INSULATOR Price: $3.99 |
| 2 |
117-8005 |
TANK ASM Price: $2,772.40 |
| 3 |
136-2289-03 |
SUPPORT-VALVE Price: $459.42 |
| 3 |
596437001 |
Screws This part replaces 871110408. Price: $2.99 |
| 4 |
104-7102 |
PAD-BATTERY Price: $3.53 |
| 4 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 5 |
3256-27 |
WASHER-FLAT Price: $0.47 |
| 5 |
532145187 |
CLUTCH LEVER Price: $5.69 |
| 6 |
327-4 |
SCREW-HH Price: $2.20 |
| 6 |
532106451 |
BOLT, SHOULDER LT Price: $2.99 |
| 7 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 7 |
532135371 |
ASSEMBLY MOWER CLUTCH ARM Price: $7.93 |
| 8 |
32128-50 |
NUT-FLANGE Price: $1.78 |
| 8 |
874760636 |
BOLT Price: $4.99 |
| 9 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 9 |
532121930 |
BELLCRANK,LIFT Price: $11.99 |
| 10 |
596029501 |
Pins This part replaces 876020412. Price: $2.99 |
| 11 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 12 |
132-4297 |
BYPASS HOSE ASM Price: $229.84 |
| 12 |
532122027 |
GRIP HANDLE Price: $5.72 |
| 13 |
108-0069 |
VALVE-BALL Price: $154.28 |
| 13 |
532139352 |
LIFT HANDLE ASSY Price: $15.88 |
| 14 |
110-5224 |
FITTING-BARBED, STRAIGHT Price: $5.40 |
| 14 |
532123496 |
SPRING COMPRESSIO Price: $2.99 |
| 15 |
2412-34 |
CLAMP-HOSE Price: $2.14 |
| 16 |
532004921 |
COTTER PIN This part replaces 532124961. Price: $4.99 |
| 17 |
532127359 |
LINK LIFT FRT Price: $19.99 |
| 18 |
532142028 |
TRUNNION.ADJUSTABLE.3/8-16 Price: $3.99 |
| 19 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873680400. Price: $3.99 |
| 20 |
32104-32 |
SCREW-HWH Price: $1.99 |
| 20 |
874760644 |
BOLT Price: $3.99 |
| 21 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 22 |
2412-147 |
CLAMP-R Price: $2.51 |
| 23 |
132-7787 |
COUPLER-QUICK Price: $17.17 |
| 23 |
596029601 |
Pins This part replaces 876020416. Price: $1.99 |
| 24 |
32128-26 |
NUT-FLANGE Price: $5.89 |
| 24 |
596040101 |
Washers This part replaces 819171612. Price: $2.99 |
| 25 |
532121933 |
TUBE SPACER Price: $4.28 |
| 26 |
532141470 |
LIFT ROD Price: $14.65 |
| 27 |
532121466 |
KNOB Price: $3.99 |
| 28 |
532004497 |
RETAINER M This part replaces 532124788. Price: $4.99 |
| 29 |
532131655 |
LINK MOWER CLUTCH Price: $4.99 |
| 30 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 873350600. Price: $4.99 |
| 31 |
596134901 |
GSPH This part replaces 819132012. Price: $2.99 |
| 43 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
