| Ref | Part Number | Description |
|---|
| 1 |
9194R |
DRILLED RIVET RT Price: Call Us |
| 1 |
99-8346 |
GASKET Price: $1.43 |
| 2 |
74760520 |
BOLT Price: Call Us |
| 2 |
98-9417 |
BOLT-JOINT, EYE Price: $12.10 |
| 3 |
115-4126 |
BOLT-JOINT, EYE This part replaces 98-9418. Price: $12.34 |
| 3 |
74760512 |
BOLT Price: Call Us |
| 4 |
73220500 |
NUT.HEX.5/16-18 Price: Call Us |
| 4 |
98-9419 |
OIL PIPE ASM Price: $64.29 |
| 5 |
10040500 |
LOCKWASHER Price: Call Us |
| 5 |
108-4422 |
GASKET This part replaces 98-9435. Price: $1.48 |
| 6 |
138-1238 |
KIT-PIPE, OIL This part replaces 98-9461. Price: $212.76 |
| 6 |
73800600 |
NUT Price: Call Us |
| 7 |
4921H |
SPRING.RETAINER Price: Call Us |
| 7 |
98-7568 |
BOLT Price: $0.84 |
| 8 |
1952J500 |
SUPPORT STAKE RH Price: Call Us |
| 8 |
98-9591 |
PIN-BAND Price: $6.96 |
| 9 |
122233X |
SUB= 2582J Price: Call Us |
| 9 |
98-9601 |
CLAMP-PIPE Price: $6.61 |
| 10 |
326J |
SUB= 4929H Price: Call Us |
| 10 |
98-9714 |
CLAMP-HOSE Price: $2.66 |
| 11 |
74780628 |
BOLT Price: Call Us |
| 11 |
98-9721 |
PIPE-OIL Price: $14.77 |
| 12 |
104-5159 |
HOLDER ASM Price: $120.58 |
| 12 |
74760524 |
BOLT.HEX.5/16-1.5 Price: Call Us |
| 13 |
1951J500 |
SUPPORT STAKE LH Price: Call Us |
| 13 |
98-9724 |
PIPE-COOLER, OIL Price: $31.43 |
| 14 |
120958X |
WASHER Price: Call Us |
| 14 |
98-9578 |
PIPE-RETURN, WATER Price: $11.28 |
| 15 |
5388J |
STAKE SPRING TI Price: Call Us |
| 15 |
98-9579 |
BAND-PIPE Price: $5.22 |
| 16 |
121117X |
BOLT SHOULDER Price: Call Us |
| 16 |
98-9727 |
COLLAR Price: $9.86 |
| 17 |
104-5158 |
OIL COOLER ASM Price: $456.20 |
| 17 |
9188R |
SUB= 107644X Price: Call Us |
| 18 |
19131311 |
WASHER Price: Call Us |
| 18 |
98-9729 |
O-RING Price: $6.27 |
| 19 |
9190R500 |
BRACKET.WHL.PNT. Price: Call Us |
| 19 |
99-8383 |
OIL PIPE ASM Price: $63.74 |
| 20 |
73680600 |
SUB= 73690600 Price: Call Us |
| 21 |
74760516 |
SUB= 77394 Price: Call Us |
