| Ref | Part Number | Description |
|---|
| 1 |
117-8982 |
TANK-HYDRAULIC This part replaces 104-9254. Price: $1,846.02 |
| 1 |
532170771 |
Control Throttle Price: $22.99 |
| 2 |
539990071 |
HCS.1/4-20.X1/2 This part replaces 817720408. Price: $1.99 |
| 2 |
68-6150 |
BREATHER Price: $27.22 |
| 3 |
61-2790 |
FILTER-SCREEN Price: $49.91 |
| 4 |
532149723 |
Muffler Price: $45.99 |
| 4 |
94-9411 |
DIPSTICK Price: $42.51 |
| 5 |
532191548 |
Exhaust Tube LH Price: $63.99 |
| 5 |
98-3917-01 |
BRACKET-FILTER Price: $45.78 |
| 6 |
532191549 |
Exhaust Tube RH Price: $64.99 |
| 6 |
93-7498 |
PLUG-PLASTIC Price: $25.26 |
| 7 |
340-91 |
FITTING-STR Price: $36.83 |
| 8 |
32144-14 |
SCREW-HWHTF Price: $4.29 |
| 8 |
532171877 |
Bolt 5/16-18 unc x 3/4 Price: $3.99 |
| 9 |
23-8910 |
STEM-BARB-90 Price: $153.60 |
| 10 |
104-7546 |
TANK STRAINER ASM Price: $170.48 |
| 10 |
532434017 |
SHIELD.HEAT.MUFFLER This part replaces 532146629. Price: $11.99 |
| 11 |
353-508 |
PLUG-HH Price: $7.96 |
| 12 |
33104-020 |
SCREW-HHF Price: $2.07 |
| 13 |
532165391 |
Gasket Price: $9.99 |
| 13 |
92-8020 |
ADAPTER-BREATHER Price: $10.50 |
| 14 |
532148456 |
Tube Drain Oil Easy Price: $2.99 |
| 14 |
93-7588 |
COVER-TANK Price: $37.60 |
| 15 |
2412-34 |
CLAMP-HOSE Price: $2.14 |
| 16 |
93-7499 |
GASKET Price: $5.91 |
| 17 |
817060624 |
Screw 3/8-16 x 1-1/2 Price: $3.99 |
| 17 |
98-3931 |
HOSE-FORMED Price: $80.81 |
| 18 |
237-101 |
O-RING Price: $2.80 |
| 19 |
353-550 |
PLUG-HYD, HH Price: $10.71 |
| 20 |
2412-93 |
CLAMP-R Price: $1.02 |
| 22 |
32144-10 |
SCREW-HWH Price: $4.29 |
| 23 |
323-4 |
SCREW-HH Price: $1.02 |
| 23 |
532169837 |
Shield Browning/Debris Guard Price: $7.99 |
| 24 |
33105-025 |
SCREW-HHF Price: $1.56 |
| 25 |
532161729 |
Control Choke Price: $22.99 |
| 25 |
63-8410 |
WASHER Price: $1.76 |
| 26 |
75-6870 |
HOSE-INLET, PUMP Price: $50.00 |
| 26 |
873920600 |
Nut Keps 3/8-24 unf Price: $3.99 |
| 27 |
240-11 |
BUSHING-FLANGE Price: $5.32 |
| 28 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 29 |
532137180 |
Kit Spark Arrestor (Flat Scrn) Price: $128.99 |
| 31 |
532179022 |
Tank Fuel Price: $89.99 |
| 32 |
532182902 |
CAP.ASM.FUEL.BLACK This part replaces 532181803. Price: $21.99 |
| 33 |
532123487 |
Clamp Hose Black Price: $3.99 |
| 37 |
532008543 |
Line Fuel 54" This part replaces 532142158. Price: $7.99 |
| 38 |
532428287 |
VALUE.OIL.DRAIN This part replaces 532181654. Price: $11.99 |
| 41 |
532139277 |
Stem Tank Fuel Price: $5.99 |
| 45 |
817000612 |
Screw Hex Wsh Thdr 3/8-16 x 3/4 Price: $2.99 |
| 72 |
532183906 |
Screw Socket Head 5/16-18 x 1 Price: $3.99 |
| 81 |
873680400 |
Nut Crownlock 1/4-20 unc This part replaces 873510400. Price: $2.69 |
